CATERER
4 & 6 BURNER BBQ
Ideal heavy duty BBQ for sporting and social clubs
or anywhere large groups are entertained
Solid 5mm thick steel hotplate
Castors for easy moving
Stainless steel burners
Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Model No. BQ1051
Important: Retain these instructions for future use.
Model No. BQ1050
Removable lid that doubles as a windshield
Foldable side shelves
Universal L.P.G.
Gas Certified to Australian and New Zealand Standards
Aber Holdings Ltd - Hamilton, N.Z. www.gasmate.co.nz
03339 05/16
Advertisement
Related Manuals for Gasmate CATERER 4
Summary of Contents for Gasmate CATERER 4
- Page 1 Castors for easy moving Gas Certified to Australian and New Zealand Standards Stainless steel burners Important: Retain these instructions for future use. Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au Aber Holdings Ltd - Hamilton, N.Z. www.gasmate.co.nz 03339 05/16...
-
Page 2: Table Of Contents
CONTENTS GENERAL INFORMATION Gas Installation Codes Section Page • Barbecues must be used in accordance with the General Information installation requirements of your gas supply authority, or the appropriate installation code issued by Parts List & Hardware List Standards Australia AS 5601. •... - Page 3 Gas Cylinder Use & Safety FOR yOUR SAFETy This is a low pressure barbecue and must only be used with the hose and regulator supplied. Your barbecue is designed for use with 4.5Kg or 9Kg gas cylinders • Do not store or use petrol or other flammable certified to AS 2469.
- Page 4 WARNINGS • Do not test for gas leaks with an open flame • If this information is not followed exactly, a fire causing death or serious injury may occur. • Failure to comply with these instructions could result • Do not store a spare gas cylinder under or near in a fire or explosion which could cause serious this barbecue.
-
Page 5: Parts List & Hardware List
COMPONENTS - 4 BURNER Description Description Lid Handle Burner Lid Hook Cross Igniter Burner Support Warming Rack Heat Shield Hotplate Control Panel Assembly Side Shelf Knob Side Handle Manifold Cylinder Hook Horizontal Tube Leg Assembly Bottom Rack Castor without Brake Grease Cup Castor with Brake Grease Cup Holder... - Page 6 COMPONENTS - 6 BURNER Description Description Lid Handle Burner Lid Hook Cross Igniter Burner Support Warming Rack Heat Shield Hotplate Control Panel Assembly Side Shelf Knob Side Handle Manifold Cylinder Hook Horizontal Tube Leg Assembly Bottom Rack Castor without Brake Grease Cup Castor with Brake Grease Cup Holder...
-
Page 7: Assembly Instructions
HARdWARE M6x40mm (x12) M6x12mm (x6) M5x12mm (x8) M6 Shoulder Screws (x8) IMPORTANT: Remove any transit protection material before use. TOOLS: Phillips Head Screwdriver Adjustable Spanner ASSEMBLy INSTRUCTIONS STEP 1 Attach the legs to the body using 8 x M6x40mm screws and the lower support beams using 4 x M6x40mm long screws. - Page 8 STEP 2 Attach the handles to the top of the legs using 8 x M5x12mm long screws, then attach the cylinder hanging hook and fat cup holder as shown using 4 x M6x12mm long screws.. M6x12mm (x4) M5x12mm (x8)
- Page 9 STEP 3 Attach the folding side shelves as shown using 8 x M6 shoulder screws. M6 Shoulder Screws (x8)
- Page 10 STEP 4 Attach the handle to the lid ensuring the lid hook is oriented as shown on the underside using 2 x M6x12mm screws. The lower wire rack and warming rack can be installed as required. M6x12mm (x2)
- Page 11 STEP 5 The completed assembly. Note: Before use always leak test the connection to the gas cylinder using a soapy water solution.
-
Page 12: Care & Maintenance
CARE & MAINTENANCE GENERAL ASSEMBLy Care & Maintenance Connecting & disconnecting to Gas Source As with all appliances, proper care and maintenance will keep them in top operating condition and prolong Familiarise yourself with the general information and safety their life. Your new gas barbecue is no exception. By guidelines located at the front of this manual. -
Page 13: Lighting Procedure
LIGHTING PROCEdURE WARNINGS Burner Operation & Ignition System Check • Before connecting and disconnecting barbecue to 1. With cylinder valve in ‘OFF’ position push and turn gas source, make sure burner controls are in ‘OFF’ the far left or right control knob anti-clockwise to position. -
Page 14: Burner Operation & Operating Procedure
BURNER OPERATION & IGNITION SySTEM CHECk Problem Possible Reason Solution Valve on gas bottle closed Open valve on gas bottle Burner will Control knob is closed Turn knob to high when lighting not ignite Igniter is faulty Use a long barbecue match. Insert through the hole at side of barbecue Burner has gone out Check that the gas bottle is not empty and... -
Page 15: Safe Appliance Locations
SAFE APPLIANCE LOCATIONS Within a partial enclosure that includes an overhead cover and no more than two walls This appliance shall only be used in an above ground (see Example 2 & 3). open-air situation with natural ventilation, without Within a partial enclosure that includes an overhead stagnant areas, where gas leakage and products of cover and more than two walls, the following will apply: combustion are rapidly dispersed by wind and natural... - Page 16 For any queries or assistance call Customer Service (Australia Only) 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm EST do not return to place of purchase. Keep your purchase receipt, this will be required to make any claims under the 12 month warranty.
