Mil-Std-1553 Serial Bus Trigger Settings Panel - Tektronix 5 series Printable Help

Menus and dialog boxes

MIL-STD-1553 serial bus trigger settings panel

NOTE. Requires option SRAERO.
Field or control
Source
Trigger On
Sync
Transmit/Receive Bit
Trigger When RT Address
Parity
Address
Low Address
High Address
Subaddress/Mode
360
Description
Select the MIL-STD-1553 bus on which you want to trigger.
Select the type of information on which to trigger.
Sets to trigger on a Sync condition.
Available when Trigger On = Sync.
Sets the transmit or receive bit on which to trigger.
Available when Trigger On = Command.
Sets to trigger when the specified RT address condition occurs.
Available when Trigger On = Command or Status.
Sets to trigger on the selected parity bit logic state.
Available when Trigger On = Command, Status, or Data.
Sets the address pattern on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Command or Status.
Sets the low value of the address pattern range on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = Inside Range or Outside Range.
Sets the high address of the address pattern range on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = Inside Range or Outside Range.
Sets the subaddress or mode pattern on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Command.
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
