  • Page 1 Heavy Duty Weather Resistant Telephone Model ACT Installation & Operation ACT-30 ACT-40 P005486 Rev. G 180912 9/12/2018 10:54 AM Ph: 403.258.3100 \ email:info@guardiantelecom.com \ www.guardiantelecom.com...
  • Page 2: Table Of Contents

    Figure 4 - Electrical Connections ............5 Package Contents One (1) ACT Telephone One (1) Installation and Operation manual Models • P5422 ACT-30 with 4 foot heavy duty Coil cord • P5423 ACT-40 with 18” armored cord and handset retainer clips Options • Locking Door (LD) •...
  • Page 3: Overview

    Guardian Telecom Installation and Operation Model ACT Overview ACT Heavy Duty Telephone The ACT Heavy Duty Telephone meets the special requirements of sites prone to abuse and inclement weather. The apparatus is housed in an aluminum enclosure with a locking or non-locking door.
  • Page 4: Figure 1 - Features

    Guardian Telecom Installation and Operation Model ACT Figure 1 - Features Figure 2 - Overall Dimensions Page...
  • Page 5: Figure 3 - Mounting

    Guardian Telecom Installation and Operation Model ACT Figure 3 - Mounting Figure 4 - Electrical Connections Page...
  • Page 6: Installing The Act Telephone

    Guardian Telecom Installation and Operation Model ACT Installing the ACT Telephone • See: Government Follow all appropriate electrical codes and use only approved electrical Certification. fittings for the installation. • See: Figure 3 - Mounting Choose a wall location that is free of obstructions and permits space for conduit or wire.
  • Page 7: Specifications

    Guardian Telecom Installation and Operation Model ACT Specifications LECTRICAL ERFORMANCE 300 – 3400 H UDIBLE REQUENCY ANGE DTMF 40/60 P 10 PPS IALING ETHOD ULSE AT (TOLR) /- 3 dB RANSMIT BJECTIVE OUDNESS ATING 13.5 dB 2.7 dB S , 3 S...
  • Page 8: Replacement Parts

    : 1012-6721A NDUSTRY ANADA ERTIFICATION NUMBER Replacement Parts Part No. Description P006270 ACT-30 Faceplate Assembly C/W Coil Cord Volume Control Handset P006273 ACT-40 Faceplate Assembly C/W Armored Cord Volume Control Handset P002786 Handset Cradle P004371 Handset Retainer P007257 Handset Assembly C/W 4’ Coil Cord and Volume Control Handset P007107 Handset Assembly C/W 18”...
  • Page 9: Government Certification

    Guardian Telecom Installation and Operation Model ACT Government Certification Attached to the telephone are labels for Industry Canada and the United States Federal Communications Commission. These identify equipment certifications indicating the 60 and 70 series telephones meet certain telecommunications network protective, operational and safety requirements.
  • Page 10: Warranty

    Installation and Operation Model ACT Warranty Guardian Telecom warrants your product to be free of defects in material and workmanship for a period of three years. Guardian Telecom will repair or replace any defective unit that is under warranty free of charge.
  • Page 11: Guardian Product Return

    When a product has been installed following user manual instructions and the unit fails to operate, the user must contact Guardian Telecom to obtain authorization to return the product. This can be done by completing an RMA form online at https://www.guardiantelecom.com/support/rma/, or by calling the service telephone number given...
  • Page 12: Cleaning Tips For Guardian Telephones

    Guardian Telecom Installation and Operation Model ACT Cleaning Tips for Guardian Telephones Guardian Telephones may occasionally need to be cleaned to maintain appearance. Generally, wiping the surface with a clean, water dampened cloth will remove most films or residues. If the soiling is too stubborn for plain water, a mild detergent solution may be used.
  • Page 13 Guardian Telecom Installation and Operation Model ACT Notes: Model No. Part No. Serial No. Date of Purchase Page...
  • Page 14 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 15 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 16 Guardian Telecom, A Division of Circa Enterprises Inc. Toll-free 1-800-363-8010 Phone (403) 258-3100 Fax. (403) 253-4967 www.guardiantelecom.com E-mail: sales@guardiantelecom.com (Click to open message box) Tough. Tested. True. © Guardian Telecom 2018...
