7. Align the four screws with the mounting holes and attach the ViVOpay Kiosk III to the
outside surface. Make sure that the cable is not pinched or binding.
Square Bezel
8. Use the four nuts to secure the ViVOpay Kiosk III to the outside surface of the kiosk. Make
sure to tighten the nuts securely so that the ViVOpay Kiosk III does not move on the
outside surface of the kiosk.
If you are installing the Angle Bezel Antenna, tighten the nuts to 5-7 in/lbs. for a good
weather seal.
9. Attach the end of the cable with the SMB connector through the right 14.0 mm (0.551 inch)
hole and attach it to the socket on the back of the ViVOpay Kiosk III antenna. The SMB
connector pushes on to the socket on the antenna.
ViVOpayKiosk III UserManual
Angle Bezel
