INSTALLATION MANUAL
MFCS05 Madrona Modern Stove Casing
CSA approved for use with Valor Models MF28 Heaters ONLY
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
Notes: This kit must be installed or serviced by a qualifi ed install-
er, service agency or gas supplier. These instructions are to be
used in conjunction with the main installation instructions
for the above listed heater models.
The application of this kit does not aff ect the venting capa-
bilities or method of preparation of the MF28 heater as de-
scribed in the MF28 heater installation manual.
MFCS05—Madrona Modern
Stove Casing, including
Barrier Screen
Overview
(MF28 sold separately)
4006571-02
© Copyright Miles Industries Ltd., 2018.
Madrona
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
MF28—Madrona Engine
INSTALLER
Leave this manual
with the appliance.
CONSUMER
Retain this manual
for future reference.
To complete the installation
of this kit you need the
following items:
• MF28 Madrona Engine
• MFCS05 Madrona Modern
Stove
Complete Stove

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Madrona and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor Madrona

  • Page 1 INSTALLATION MANUAL Madrona MFCS05 Madrona Modern Stove Casing CSA approved for use with Valor Models MF28 Heaters ONLY DANGER INSTALLER HOT GLASS WILL CAUSE BURNS. Leave this manual with the appliance. DO NOT TOUCH GLASS UNTIL COOLED. CONSUMER NEVER ALLOW CHILDREN TO TOUCH GLASS.
  • Page 2 • Install fuel bed, check appliance and complete installation as per instructions supplied with engine. • Install barrier screen on back of front • Hook front and barrier screen. Kits Contents MFCS05 Madrona Modern Stove Vent collar • Vent collar • Heat Shield Cast vent cover •...
  • Page 3: Floor Requirements

    Corner Dimensions Mobile Home Floor Fixing 31-1/4” (794 mm) minimum The Madrona stove must be fi xed to the fl oor through the fl oor when used in a mobile home. Mantel Requirements The Madrona stove may be installed with a combustible mantel provided clearances are maintained as indicated above.
  • Page 4 Installation Rear Stove Panel 6. Unpack the appliance. Front Engine Brackets 7. Remove the window from the appliance and the 1. Unpack the stove casing. content that is stored inside the appliance. 2. Locate the right hand front engine bracket. 8.
  • Page 5 Right Side Stove Panel 16. Insert the lower bracket between the engine side supports over the studs. Secure the right side with 12. Lay the right hand a washer and nut. side stove panel on the fl oor. Identify the front and the rear of the panel.
  • Page 6 21. Place the heat shield on top of the stove and Inlay Panels and Access Door secure it with 2 screws at the front. 24. Level the stove unscrewing the levelling bolts at the four lower corners of the stove if necessary. Note: If you are installing the stove in a mobile home, remove the levelling bolts and use the holes to secure the stove to the fl...
  • Page 7: Maintenance

    Window and fi replace 4 screws provided. NOTE: DO NOT use ammonia cleaner for the fi replace window. See the Owner’s Information section in the Madrona MF28 fi replace Owner’s Manual for instructions on cleaning the window and fuel bed. WARNING...
  • Page 8: Repair Parts List

    Repair Parts List MFCS05—Madrona Modern Stove Description Part Numbers Almond White Pewter (PW) Black (BK) (AW) Spun vent collar 4006568AZ 4006568AZ 4006568AZ Vent cast iron cover 4006296AZ 4006296AZ 4006296AZ Cast iron top panel 4006049AZ 4006049AZ 4006049AZ Heat shield 4006061 4006061...
  • Page 9: Directives D'installation

    DIRECTIVES D’INSTALLATION Madrona ® LE PREMIER FOYER À GAZ RADIANT MFCS05 Casier de Poêle Madrona Modern Homologué par la CSA pour utilisation avec les foyers Valor MF28 SEULEMENT DANGER INSTALLATEUR VITRE CHAUDE - RISQUE Laissez cette notice DE BRÛLURES. avec l’appareil.
  • Page 10: Étapes D'installation

    • Installez la porte d’accès. l’installer afi n de l’alléger. • Préparez le poêle pour l’évacuation. Contenu du kit MFCS05 Poêle Madrona Modern Manchon de tuyau • Manchon de tuyau • Défl ecteur de chaleur Couvercle de fonte •...
  • Page 11 Exigences pour installation dans une Dimensions—installation dans un coin maison mobile 31-1/4” (794 mm) minimum Le poêle Madrona doit être fi xé au plancher lorsqu’installé dans une maison mobile. Exigences pour le manteau de cheminée Le Poêle Madrona Modern peut être installé avec un manteau de cheminée combustible à...
  • Page 12: Installation

    Installation Panneau arrière du poêle 6. Déballez l’appareil. Supports avant de l’appareil 7. Enlevez la fenêtre de l’appareil de même que les 1. Déballez le casier du poêle. articles à l’intérieur de la boîte de foyer. 2. Repérez le support avant droit de l’appareil. 8.
  • Page 13 Panneau droit du poêle 16. Placez le support du bas entre les montants de l’appareil. Fixez le bout droit du support et l’appareil 12. Placez le panneau au goujon du panneau droit avec une rondelle et un droit du poêle à écrou.
  • Page 14 21. Placez le défl ecteur de chaleur sur le dessus du Panneaux de pattes et porte d’accès poêle et fi xez-le aux montants de l’appareil à l’avant 24. Nivelez le poêle en dévissant les boulons aux avec une vis de chaque côté. quatre coins du bas du poêle si nécessaire.
  • Page 15: Entretien

    Consultez la section Information à l’intention du con- sommateur dans le Guide d’installation et du consom- mateur du foyer Madrona MF28 pour les directives concernant le nettoyage de la fenêtre et de l’intérieur du foyer.
  • Page 16: Liste De Pièces

    Liste de pièces MFCS05—Poêle Madrona Modern Description de pièces Blanc amande Étain (PW) Noir (BK) (AW) Manchon de tuyau 4006568AZ 4006568AZ 4006568AZ Couvercle de fonte 4006296AZ 4006296AZ 4006296AZ Panneau du dessus en fonte 4006049AZ 4006049AZ 4006049AZ Défl ecteur de chaleur...
