Related Manuals for Amprobe ACD-21SW
Summary of Contents for Amprobe ACD-21SW
- Page 1 ACD-20SW ACD-21SW ACD-21SWC Digital Clamp Meter Users Manual For detailed specifications and ordering info go to www.TestEquipmentDepot.com...
- Page 2 ACD-20SW ACD-21SW ACD-21SWC Digital Clamp Meter Users Manual September 2009, Rev.2 ©2009 Amprobe Test Tools. All rights reserved. Printed in Taiwan...
- Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 ACD-20SW ACD-21SWC 1. Current Jaws 9. NCV Push button function 2. Jaw Opening Lever 10. NCV Sensor 3. NCV LED indicator 11. Hand/Finger Barrier to indicate 4. Function Selector Knob the limits of safe access of the 5. Range push button selector meter during measurement 6.
-
Page 5: Table Of Contents
HOLD Button ....................5 RANGE Button....................5 Measuring DC Voltage...................5 Measuring AC Voltage...................5 AC Current Measurement ................5 Capacitance Measurement (ACD-21SW / ACD-21SWC only) .......6 Resistance .......................6 Continuity Testing ..................6 Diode Testing (ACD-20SW) ................7 Temperature Measurement (ACD-21SW / ACD-21SWC only) .....7 Non-Contact Voltage Indicator ..............7 Auto Power off ....................8... -
Page 6: Symbols
Canadian Standards Association (NRTL/C) Safety Information • The ACD-20SW, ACD-21SW and ACD-21SWC swivel Clamp meters conform to EN61010-1:2001; EN61010- 2-032:2002; CAT III 600 V, class II; pollution deg.2 and EN61326-1 (EMC compliance) • This instrument is EN61010-1 certified for Installation Category III (600V). - Page 7 • Inspect the Clamp meter, test leads and accessories before every use. Do not use any damaged part. • Never ground yourself when taking measurements. Do not touch exposed circuit elements or test probe tips. • Do not operate the instrument in an explosive atmosphere. •...
-
Page 8: Unpacking And Inspection
INTRODUCTION The ACD-20SW, ACD-21SW and ACD-21SWC clamp-On meters come with a new patented rotating head design that allows easy viewing of the measurements in tight or inconvenient to reach places. Simply rotate the body of the meter to get an unobstructed view of the LCD display. -
Page 9: Operation
OPERATION HOLD Button Data hold freezes the reading present on the LCD at the moment the button is pressed.To use this menu feature, set up the meter for the type of measurement and range desired. Connect the test leads to the circuit / component to be measured and then press “HOLD”... -
Page 10: Capacitance Measurement (Acd-21Sw / Acd-21Swc Only)
Capacitance Measurement (ACD-21SW / ACD-21SWC only) When testing a capacitor that is part of a circuit, if “dS.C” is displayed on the screen, a voltage is present. Discharge the capacitor before testing. 1. Sett the Function Switch to “ E ” position. -
Page 11: Diode Testing (Acd-20Sw)
6. If the diode is open, “OL” is displayed in both directions. 7. Audible Indication: Less than 0.25V. Temperature Measurement (ACD-21SW / ACD-21SWC only) 1. Verify that the location being tested is not electrically energized. 2. Set the Function Switch to Temp position. -
Page 12: Auto Power Off
Altitude: 6561.7 Feet (2000m). Jaw opening capability: 30mm conductor. Power: 1.5 volt battery x2, R03/SIZE AAA. Battery life:75 hours typical with carbon-zinc (ACD-21SW /ACD-21SWC) 75 hours typical with carbon-zinc (ACD-20SW) Dimensions: 240 × 70 × 41 mm (9.5 x 2.8 x 16 IN). -
Page 13: Dc Volts
DC Volts Ranges Resolution Accuracy 400mV, 4V, 40V, 400V, 600V 0.1mV ±(0.5% rdg + 2 dgts) Input impedance: 400mV: >100Me; 4V: 10Me; 40V ~ 600V: 9.1Me Overload protection: 600VDC or AC rms AC Volts (50Hz - 500Hz) Ranges Resolution Accuracy 4V, 40V, 400V ±(1.2% rdg + 5 dgts) on 4V to 400V ranges 600V... -
Page 14: Capacitance (Acd-21Sw / Acd-21Swc Only)
Capacitance (ACD-21SW / ACD-21SWC only) Ranges Resolution Accuracy 4μF ±(3.0% rdg + 15 dgts) 40μF, 400μF ±(3.0% rdg + 5 dgts) ±(5.0% rdg + 20 dgts) Minimum input range: >100nF 4nF, 40nF, 400nF ranges unspecified When the capacitor to be tested is connected, if “dS.C” symbol indicates on LCD, it means there is voltage existing in the tested capacitor and need to be discharged before testing. -
Page 15: Diode Test (Acd-20Sw Only)
Diode Test (ACD-20SW only) Test current: 0.8mA (approximate) Accuracy: ±(3.0% rdg + 3 dgts) Resolution: 10mV Open circuit volts: 3.0Vdc typical Audible indication: < 0.25V Overload protection: 600VDC or AC rms Battery Replacement • Power is supplied by 1.5 volt battery x2 (LR03/SIZE AAA ). •... - Page 16 ACD-20SW Fig.2 Measuring AC Voltage Fig.1 Measuring DC Voltage Fig.3 Measuring AC Current Fig.4 Measuring Capacitance...
- Page 17 Fig.5 Measuring Resistance Fig.6 Measuring Temperature Fig.7 Non-Contact voltage (NCV) Measurement...
