USER'S MANUAL
ACD-30P, ACD-31P,
& ACD-41PQ
1000A Clamp-on Power
Meters
For detailed specifications and ordering info go to
www.TestEquipmentDepot.com

Advertisement

Table of Contents
loading

Summary of Contents for Amprobe ACD-30P

  • Page 1 USER'S MANUAL ACD-30P, ACD-31P, & ACD-41PQ 1000A Clamp-on Power Meters For detailed specifications and ordering info go to www.TestEquipmentDepot.com...
  • Page 2: Terms In This Manual

    1) SAFETY This manual contains information and warnings that must be followed for operating the instrument safely and maintaining the instrument in a safe operating condition. If the instrument is used in a manner not specified by the manufacturer, the protection provided by the instrument may be impaired.
  • Page 3: International Electrical Symbols

    WARNING To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. The meter is intended only for indoor use. To avoid electrical shock hazard, observe the proper safety precautions when working with voltages above 60 VDC or 30 VAC rms. These voltage levels pose a potential shock hazard to the user.
  • Page 4: Product Description

    3) PRODUCT DESCRIPTION This user's manual uses only representative model(s) for illustrations. Please refer specification details for function availability to each model. 1) Transformer Clamp Jaws for AC current magnetic field pick up 2) Jaw marking lines for ACA (& thus Power) position error indication 3) Hand/Finger Barrier to indicate the limits of safe access to the jaws during...
  • Page 5: Operation

    4) OPERATION AutoVA function Set the slide-switch function-selector to the position. ●With no input, the meter displays “Auto” when it is ready. ●With no ACA current input via the jaws but a voltage signal above the nominal threshold of DC 2.4V or AC 30V (40Hz ~ 500Hz) up to the rated 600V is present on V-COM terminals, the meter displays the voltage value in appropriate DC or AC, whichever larger in peak magnitude.
  • Page 6 around only one single conductor of a circuit for load current measurement. Make sure the jaws are completely closed, or else it will introduce measurement errors. Enclosing more than one conductor of a circuit will result in differential current (like identifying leakage current) measurement.
  • Page 7 Line-level Frequency function When ACV or ACA function is auto-selected or manual-selected, press Hz button momentarily toggles to Line-level Frequency function. Frequency trigger levels vary automatically with function ranges. Peak-rms mode Peak-rms compares and displays the maximum RMS value of surge voltage or current with durations as short as 65ms.
  • Page 8 Notes on Displacement Power Factor & True Power Factor ●Introduction: Power is the rate of change of energy with respect to time (in terms of voltage V and current A). Instantaneous (real) power w = vi where v is the instantaneous voltage and i the instantaneous current.
  • Page 9 ●PF (Total Power Factor) displays simultaneously in the secondary mini display. Denoting efficiency, absolute PF value is adopted. ●“A-lags” LCD annunciator turns on to indicate an inductive circuit, or Current A lags Voltage V (i.e., phase-shift angle θ is “+”). On the contrary, together with significant PF values, WITHOUT “A-lags”...
  • Page 10 ●Measuring 3-Phase 4-Wire (3 4W) Power Parameters: In both un-balanced and balanced load cases, 3-Phase 4-Wire (3 4W) systems, measure the phase-to-neutral powers kW and kW of each phase separately as illustrated. System (total) power kW is the summation of all three phase-to-neutral Total powers.
  • Page 11 ●Measuring 3-Phase 3-Wire (3 3W) Power Parameters: In both un-balanced and balanced load cases, 3-Phase 3-Wire (3 3W) systems, measure the power components kW and kW separately as illustrated. System (total) power kW is the summation of the two measured power components. That is: Total = kW + kW...
  • Page 12 Temperature function (models ACD-31P & ACD-41PQ only) Set the slide-switch function-selector to the F position. Default at last selected function. Press SELECT button to toggle between C and F measurement functions. Be sure to insert the banana-plug type-K temperature bead probe TPK-59 at correct polarities.
  • Page 13: Maintenance

    Disabling Auto-Power-Off (APO) Press-and-hold the HOLD button while sliding the function-selector to a (designated) function-selector position. This disables the Auto-Power-Off feature of the functions on that particular function-selector position. The LCD displays “ ” & “ ” to confirm activation right after the HOLD button is released. Slide the function-selector to any other positions then resumes Auto-Power-Off feature.
  • Page 14 Cleaning and Storage Periodically wipe the case with a damp cloth and mild detergent; do not use abrasives or solvents. If the meter is not to be used for periods of longer than 60 days, remove the batteries and store them separately Battery replacement The meter uses standard 1.5V AAA Size (NEDA 24A or IEC LR03) battery X 2 Loosen the 2 captive screws from the battery cover case.
  • Page 15 Update Rate : Power function: 1 per second nominal Voltage, ACA clamp-on, Ohm, Hz & Temperature functions: 4 per second nominal Polarity : Automatic Low Battery : Below approx. 2.4V Operating Temperature : 0 C to 40 Relative Humidity : Maximum relative humidity 80% for temperature up to 31 decreasing linearly to 50% relative humidity at 40 Altitude : Operating below 2000m Storage Temperature : -20...
  • Page 16 Accessories : Test leads (MTL-90B), batteries installed, user's manual, soft carrying pouch, & TPK-59 banana plug type-K thermocouple (model ACD-31P & ACD-41PQ only) Optional accessories : RS-232 KIT2 interface kit Electrical Specifications Accuracy is ±(% reading digits + number of digits) or otherwise specified, at 23 C ±5 &...
  • Page 17 PEAK-rms HOLD (ACA & ACV only) Response: 65ms to 90% Ohms RANGE Accuracy 1.0% + 6d 999.9Ω Open Circuit Voltage : 0.4VDC typical Audible Continuity Tester Audible threshold: between 10Ω and 300Ω. Response time: 250µs ACA Current (Clamp-on) RANGE Accuracy 1) 2) 50Hz / 60Hz 40.00A, 400.0A, 1000A...
  • Page 18 Temperature (model ACD-31P & ACD-41PQ only) RANGE Accuracy C ~ 300 2.0% + 3 F ~ 572 2.0% + 6 Type-K thermocouple range & accuracy not included Add 3 C (or 6 F) to specified accuracy @ -20 C ~ -50 C (or @ -4 F ~ -58 Frequency...
  • Page 19 Power RANGE Accuracy 1) 2) 0 ~ 600.0kVA F ~ 10th 11th ~ 46th 47th ~ 51st @ PF = 0.99 ~ 0.1 2.0%+6d 3.5%+6d 5.5%+6d RANGE Accuracy 1) 3) 0 ~ 600.0kW / kVAR F ~ 10th 11th ~ 25th 26th ~ 46th 47th ~ 51st @ PF = 0.99 ~ 0.70...
