- Page 1 INSTALLATION AND OPERATIONS SUPPLEMENT 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
-
Page 2: Limited Warranty
LIMITED WARRANTY Rose Electronics warrants the MultiVideo ™ to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below. -
Page 3: System Overview
If your system demands are greater than a single unit can provide, the MultiVideo can be easily expanded to connect up to 64 computers by chaining units together with expansion cables. All MultiVideo models can easily be expanded by chaining the units together and configuring the system. - Page 4 - Connects to the previous CPU Switches* + Connects to the next CPU * The - and + switches are used when: upgrading the firmware resetting the unit to factory defaults running diagnostics. Table 1. Front panel MULTIVIDEO INSTALLATION AND OPERATIONS MANUAL...
- Page 5 “M” Chassis (2U2V) “B” Chassis (4U2V) “C” Chassis (2U4V) “C” Chassis (4U4V) “C” Chassis (8U2V) Figure 2. Rear panel NOTE: DB9 (LINK) connector on Video expansion units only Power connector not used on Video expansion unit. MULTIVIDEO INSTALLATION AND OPERATIONS MANUAL...
- Page 6 Master to Slave unit cables In systems needing additional CPUs, the MultiVideo can be cascaded to other MultiVideos. To cascade a MultiVideo to other “Slave” units, you will need one DB25M to DB25M, switch-to-switch cable for each cascaded unit. The MultiVideo can also be expanded to add additional Video ports. A DB9M to DB9M, switch-to-switch cable is used with the MultiVideo video expansion units.
-
Page 7: Installation - Single Unit
Figure 3. 4U2V Unit installation Installation – Cascading units Slave#2 Master Dual video CPUs 5-8 KVM Station Slave#1 Two additional “Slave” units can be added to this configuration. Dual video CPUs 1-4 Figure 4. Cascading units MULTIVIDEO INSTALLATION AND OPERATIONS MANUAL... - Page 8 Applications VIDEO 8 VIDEO 1 MULTIVIDEO INSTALLATION AND OPERATIONS MANUAL...
- Page 9 Installation – Video Expansion system The MultiVideo can be custom configured to expand the number of video ports. The example below can have up to 16 separate video sources and up to 8 video outputs. The KVM station can switch the video by simple keyboard commands, the push-button switches on the front panel, or from the on-screen display.
-
Page 10: Appendix B. Parts And Cables
Where x = chassis size, M (mini), B (low), C (high) Where y = number of CPUs (2, 4, or 8) Where z = number of monitors (2 or 4) The MultiVideo Video expansion model part numbers are: MPC – 2U4V/MV (Master unit) MPC – 2U4V/SL (Slave unit) Connectors Power –... -
Page 11: Appendix E. Rack Mount Illustration
Appendix E. Rack mount illustration MULTIVIDEO INSTALLATION AND OPERATIONS MANUAL... - Page 12 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 WWW.ROSE.COM...
