INSTALLATION GUIDE
Switch System
Boardroom
Size: 3600mm x 1200mm
3
4

COMPONENTS

1
Table Top x3 (1200x1200mm)
2
Leg x8
3
Leg Bracket x8
4
Beam Bracket x16
5
Switch Beam x2 (1135mm)
6
Switch Beam x4 (970mm)
7
Switch Beam x4 (800mm)
8
L-Bracket x20

SCREWS

9
Hex Nut x8
10
L-Bracket screws x20
11
Hex Head screws x20
12
M8x25mm Dome Head x8
8
10
6
4
9
