INSTALLATION GUIDE
Switch System
Boardroom
Size: 2400mm x 1200mm
Tools Required: Power screwdriver.
Special Note: No pre-drilled holes or nut inserts are provided.
Wood screws will be required to be drilled directly into underside of desk top.
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Page 1 of 4
Advertisement
Table of Contents
Related Manuals for Jason.L Switch System Boardroom
Summary of Contents for Jason.L Switch System Boardroom
- Page 1 www.jasonl.com.au INSTALLATION GUIDE Switch System Need help! Call us on Boardroom 1300 527 665 Size: 2400mm x 1200mm Tools Required: Power screwdriver. Special Note: No pre-drilled holes or nut inserts are provided. Wood screws will be required to be drilled directly into underside of desk top. Page 1 of 4...
- Page 2 www.jasonl.com.au INSTALLATION GUIDE Switch System Need help! Call us on Boardroom 1300 527 665 Size: 2400mm x 1200mm COMPONENTS Table Top x2 (1200x1200mm) Leg x4 Leg Bracket x4 Beam Bracket x8 Switch Long Beam x2 (2000mm) Switch Short Beam x2 (800mm) L-Bracket x10 SCREWS Hex Nut x4...
- Page 3 www.jasonl.com.au INSTALLATION GUIDE Switch System Need help! Call us on Boardroom 1300 527 665 Size: 2400mm x 1200mm Join Leg Brackets to each Leg using screws to secure them, as follow. Join 3 L-Bracket through each Long Beam and 2 L-Bracket through each Short Beam. Securely connect each Beam to each Beam Bracket.
- Page 4 www.jasonl.com.au INSTALLATION GUIDE Switch System Need help! Call us on Boardroom 1300 527 665 Size: 2400mm x 1200mm Position as presented, and proceed to screw Directly screw into table tops, using L-Bracket to ensure each corner of the frame. screws through each L-Bracket. Page 4 of 4...
