INSTALLATION GUIDE
Switch System
Boardroom
Size: 1200mm x 1200mm
Tools Required: Power screwdriver.
Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your particular
table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame is su ciently rigid.
Failure to do this may a ect stability once the tops are attached.
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Page 1 of 4
