There are two RCM4200 production models. Table 1 summarizes their main features.
Feature
Microprocessor
Data SRAM
Fast Program-Execution
SRAM
Flash Memory (program)
Flash Memory
(mass data storage)
A/D Converter
Serial Ports
The RCM4200 is programmed over a standard PC USB port through a programming cable
supplied with the Development Kit.
NOTE: The RabbitLink cannot be used to program RabbitCore modules based on the
Rabbit 4000 microprocessor.
Appendix A provides detailed specifications for the RCM4200.
User's Manual
Table 1. RCM4200 Features
RCM4200
®
Rabbit 4000 at 58.98 MHz
512K
8 Mbytes (serial flash)
12 bits
4 high-speed, CMOS-compatible
ports:
•
all 4 configurable as asynchro-
nous (with IrDA), 4 as clocked
serial (SPI)
•
1 asynchronous clocked serial
port shared with programming
port
•
1 clocked serial port shared with
serial flash
•
1 clocked serial port shared with
A/D converter
RCM4210
®
Rabbit 4000 at 29.49 MHz
512K
—
512K
4 Mbytes (serial flash)
—
5 high-speed, CMOS-compatible
ports:
•
all 5 configurable as asynchro-
nous (with IrDA), 4 as clocked
serial (SPI), and 1 as
SDLC/HDLC
•
1 clocked serial port shared with
serial flash
•
1 asynchronous clocked serial
port dedicated for programming
