Lcr Meter Hm8018; Specifications - Hameg HM8018 User Manual

Display
Measuring modes: R, L, C, Θ, Q/D, |Z|
Equivalent circuits:
serial, parallel
Measuring method: 2-wire, 4-wire
Measuring ranges: R: 0.001 Ω ... 99,9 MΩ
C: 0.001 pF ... 99,9 mF
L: 0.01 µH ... 9999 H
Q: 0.0001 ... 99,9
D: 0.0001 ... 9,9999
Θ: -180.00° ... +180.00°
Basic accuracy:
0,2 %
Measuring frequencies: 100 Hz, 120 Hz, 1 kHz, 10 kHz,
25 kHz
Freq. accuracy:
±100 ppm
(except 120 Hz: 120.2 Hz ±100 ppm)
Measuring voltage: 0.5 V
Measuring rate:
2 measurements/second
Range changing: automatic, manual
DC Bias voltage: 1 V ±10%
Zero setting:
open/short circuit compensation
Compensation limits: Short:
Open:
Measurement accuracy
with D‹0.1 or Q›10: C: A
<
(A = 1 if D 0,1) L: A
d
Z: A
R: A
with D ≥ 0,1: A
e
with he parameters: C
x
A = 0.2% at f = 100 Hz, 120 Hz, 1 kHz
f
A = 0.3% at f = 10 kHz
f
A = 0.5% at f = 25 kHz
f
Parameter Auto Range
C 160 μF/f (f in kHz)
max
C 53 pF/f (f in kHz)
min
L 480 H/f (f in kHz)
max
L 0,16 mH/f (f in kHz)
min
Z , R 3 MΩ
max max
Z , R 0,5 Ω
min min
Dissipation factor
D
e
accuracy:
Quality factor
Q
e
accuracy:
Phase angle
accuracy:
Θ
LCR-MeteR HM8018
Valid at 23 degrees C after a 30 minute warm-up period
±10% (unloaded)
rms
R <10 Ω
Z <15 Ω
Z >10 kΩ
= A x A (1 + C /C + C
e f d x max min
= A x A (1 + L /L + L /L
e f d x max min
= A (1 + Z /Z + Z /Z )
e f x max min x
= A x A (1 + R /R + R
e f d x max min
√
= 1 + D 2
x
, L , Z , R = measurement value
x x x
A
e
= ± — —
100
Q 2 · D
x e
= — — — —
1 ± Q · D
x e
180 A
e
= — — · — —
π
100
Display
5-digits 7 segment LEDs with sign
Display parameters:
Value
% value
Deviation
% Offset
Miscellaneous
The inputs are short-circuit-proof and overvoltage
protected up to 100 V
consumption of 1J.
One configuration can be saved.
Operating temperature: +5 °C to +40 °C
Storage temperature: -20 °C to +70 °C
Max. relative humidity: 5%... 80% (without condensation)
Supply voltages (from HM8001-2):
Dimensions (without connector):
(W x H x D)
Weight:
/C )
x
)
x
/R )
x
Included in delivery:
LCR Meter HM8018, operating manual
Optional accessories:
HZ10S 5 x silicone test lead
(measurement connection in black)
HZ10R 5 x silicone test lead
(measurement connection in red)
HZ10B 5 x silicone test lead
(measurement connection in blue)
HZ17 Kelvin test lead (4wire) with probe tips
HZ18 Kelvin test lead (4wire) with gold
plated contacts
HZ19 Kelvin test lead (4wire) with
SMD-Test-tweezers
S p e c i f i c a t i o n s
}
Calculation from measurement
value and reference value
stored
with a maximum energy
DC
+5 V/300 mA
+5.2 V/50 mA
-5.2 V/50 mA
( = 2 W)
∑
135 x 68 x 228 mm
approx. 500 g
Subject to change without notice
17
