Summary of Contents for Bel Canto M300
-
Page 1: Power Amplifiers
User's Guide and Operating Information S300/M300 e.One Series ™ Audio Power Amplifiers Bel Canto Design, LTD. 212 Third Avenue North Minneapolis, MN 55401 Phone: (612) 317.4550 Fax: (612) 359.9358 www.belcantodesign.com Info@belcantodesign.com ©2005 Bel Canto Design, LTD... - Page 2 Bel Canto Design Statement ........
- Page 3 Get Closer Bel Canto Design audio products are designed to bring you closer to the power and beauty of your music. Our goal is simply to provide the most expressive and powerful musical experience outside of the live event and bring some of the greatest musicians and their performances into the intimacy of your home.
-
Page 4: Design Features
Design Features The e.One Series S300/M300 are single and dual-mono amplifiers designed to deliver up to 150 watts into 8 ohm loads and 300 watts into 4 ohm loads. Each amplifier contains its own dedicated regulated power supply for all amplifier stages, includ- ing the output section. - Page 5 1 – User's Guide 1 - Power Cable for connection to utility power [1.85m, 6' long] 1 – S300 or M300 Amplifier. 1 - Owner's Warranty / Registration Sheet Carefully inspect your new unit and check for shipping damage. If there is...
- Page 6 3) Output Connections: Attach your loudspeakers to the output connec- tors, insure that the polarity of each © 2005 bel canto design, Ltd. speaker is correct and the same so that no phase inversion can occur. Never Connect Either the Positive or...
- Page 7 Never Connect Either the Positive or Negative Speaker Output to Any Ground Contact! Connecting any Speaker Output on the M300 to Ground will cause the amplifier to go into protection and could damage the amplifier and void the warranty. 1) Power Switch: Power is on when the switch is toggled to the I position and off in the O position.
-
Page 8: Fuse Protection
ON again and insure that the Blue lamp is lit and that music will play. © 2005 bel canto design, Ltd. 3) The design of the amplifier reduces the chance for ground loop induced hum but we still recommend that... -
Page 9: Specifications
Weight: ................9lbs, 4Kg © 2005 bel canto design, Ltd. - Page 10 Bel Canto Design, LTD. 212 Third Avenue North Minneapolis, MN 55401 Phone: (612) 317.4550 Fax: (612) 359.9358 www.belcantodesign.com Info@belcantodesign.com ©2005 Bel Canto Design, LTD e.One™ is a trademark of Bel Canto Design, LTD...
