2 Technical data

Protocol
Interface to controller
Operating voltage
Power consumption
Tamper protection
Card technology
Card compatibility
Reading distance
Indicators
Keypad
Display
Operating temperature
IP rating
IK class
Housing
Color
Dimensions (W x H x D)
Approvals
* Only applicable for surface mounted readers. Back box mounted readers are specified from -10°C to +55°C.
** Only applicable for surface mounted readers. Back box mounted readers are specified to IP3X.
Siemens Switzerland Ltd
AR10S-MF Mifare card reader
standard
OSDP
RS485
8.5 – 30.0 VDC
DC 12V 43mA Peak 168mA
DC 24V 26mA Peak 100mA
Yes
Mifare
Mifare Classic
Mifare Plus
Mifare DESfire EV1
Up to 6 cm
3 x LED (red/yellow/green)
1 x Buzzer
Multicolor light frame
No
No
- 40°C to + 55°C*
IP55**
08
Zinc casted metal bezel with
polycarbonate plastic front
Black, matt chrome
Surface mounted: 85 x 114 x 22
Back box mounted: 85 x 114 x 14
CE according to Radio
Equipment Directives, FCC
Certified
AR40S-MF Mifare card reader
standard with keypad and display
OSDP
RS485
8.5 – 30.0 VDC
DC 12V 60mA Peak 220mA
DC 24V 40mA Peak 125mA
Yes
Mifare
Mifare Classic
Mifare Plus
Mifare DESfire EV1
Up to 6 cm
3 x LED (red/yellow/green)
1 x Buzzer
Multicolor light frame
Yes
Yes, graphic monochrome OLED
- 40°C to + 55°C*
IP55**
08
Zinc casted metal bezel with
polycarbonate plastic front
Black, matt chrome
Surface mounted: 85 x 114 x 22
Back box mounted: 85 x 114 x 14
CE according to Radio
Equipment Directives, FCC
Certified
2   Technical data
5
2017-07-14
