TLK1501 Serdes EVM Kit
Setup and Usage
User's Guide
June 2000
Mixed Signal Products
SLLU008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TLK1501 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Texas Instruments TLK1501

Summary of Contents for Texas Instruments TLK1501

  • Page 1 TLK1501 Serdes EVM Kit Setup and Usage User’s Guide June 2000 Mixed Signal Products SLLU008...
  • Page 2 IMPORTANT NOTICE Texas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue any product or service without notice, and advise customers to obtain the latest version of relevant information to verify, before placing orders, that information being relied on is current and complete. All products are sold subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those pertaining to warranty, patent infringement, and limitation of liability.
  • Page 3 Preface Read This First About This Manual This manual should be used to determine how to set up and use the TLK1501 evaluation module in order to evaluate the TLK1501 device. How to Use This Manual This document contains the following chapters: Chapter 1 —...
  • Page 4 This syntax shows that .byte must have at least one value parameter, but you have the option of supplying additional value parameters, separated by commas. Trademarks TI is a trademark of Texas Instruments Incorporated. NetLight and SpeedBlaster are trademarks of Lucent Technologies Inc.

  • Page 5: Table Of Contents

    ..............TLK1501 EVM Kit Contents .
  • Page 6 Configuration Changes Necessary for DC-Coupling of the High-Speed Signals ..3–1 TLK1501 EVM TTL Bus PCB Transmission Line Characteristics ....3–2 TLK1501 Differential Pair PCB Transmission Line Characteristics .

  • Page 7: Introduction

    Introduction The Texas Instruments (TI) TLK1501 serdes evaluation module (EVM) board is used to evaluate the TLK1501 device(VQFP) and associated optical inter- face (NetLight ) for point-to-point data transmission applications. The board enables the designer to connect 50 Ω parallel buses to both transmitter and receiver connectors.

  • Page 8: Introduction

    The board can be used to evaluate device parameters while acting as a guide for high-speed board layout. The evaluation board can be used as daughter boards that are plugged into new or existing designs. Since the TLK1501 operates over a wide range of frequencies, the designers will need to optimize their design for the frequency of interest.

  • Page 9: Tlk1501 Evm Board Configuration

    L3 that is installed in the default configuration. Thus, only the VDD connection is necessary to energize the TLK1501 device in the default configuration. In all sections of the board, the ground planes are common and each ground plane is tied together at every component ground connection.

  • Page 10: Default Transceiver Board Configuration As Shipped

    The board is normally delivered in a default configuration that requires external clock and data inputs. The TLK1501 is shipped with jumpers for default operation. Table 2–1 shows the default configuration for sending data. Table 2–1. Default Transceiver Board Configuration as Shipped...

  • Page 11: Typical Test And Setup Configurations

    Figure 2–1. The serial loopback allows the designer to evaluate most of the functions of both transmitter and receiver sections of the TLK1501 device. To test a system, a parallel bit error rate tester (BERT) generates a predefined parallel bit pattern. The pattern is connected to the transmitter through parallel connectors TD0–TD15.

  • Page 12: Tlk1501 Serial Loop-Back Test Configuration

    A typical configuration is shown in Figure 2–3. The dashed lines represent optional connections that can be made monitoring eye patterns and measuring jitter. Figure 2–2. TLK1501 Serial Loop-Back Test Configuration Jumper Selection TESTEN HP83480 or...

  • Page 13: Tlk1501 Serial Prbs Bert Test Configuration

    Evaluation Board A board-to-board communication link is a practical method of evaluating the TLK1501 in a system-like environment as shown in Figure 2–4. A Parallel BERT or a logic analyzer can be used to provide and monitor signals to and from the transceiver pairs.

  • Page 14: Tlk1501 Serial Prbs Bert Test Configuration

    Typical Test and Setup Configurations Figure 2–4. TLK1501 Serial PRBS BERT Test Configuration Jumper Selection EVM #1 EVM #2 TESTEN TESTEN PRBSEN PRBSEN LCKREFN LCKREFN HP8133A Pulse Generator ENABLE ENABLE (Asynchronous to BERT) TX_ER TX_ER EXT INPUT Trigger LOOPEN LOOPEN...

  • Page 15: Optical Interfacing And Configuration

    Direct connection is achieved only if the optical interface supports the current mode logic levels of the TLK1501 device (VDD – 1 V). If the optics module does not support or can not be biased to the CML levels then ac-coupling must be used.
  • Page 16 Optical Interfacing and Configuration TLK2500 EVM Board Configuration...

  • Page 17: Pcb Construction And Characteristics

    Chapter 3 PCB Construction and Characteristics The PCB characteristics are calculated and based on the layer construction and trace width of the board. This should be useful in determining the proper interface to the EVM and establishing system timing. PCB Construction and Characteristics...

  • Page 18: Tlk1501 Evm Ttl Bus Pcb Transmission Line Characteristics

    Table 3–1. TLK1501 EVM TTL Bus PCB Transmission Line Characteristics Device Connector Trace Width Length Capacitance Inductance Impedance Line Delay Pin No./Des. Pin Label (inches) (inches) (pF) (nH) (Ω) (ps) 62 – TXD0 0.0118 1.887 14.1 51.9 272.1 63 – TXD1 0.0118...

  • Page 19: Tlk1501 Evm Layer Construction

    Figure 3–1. TLK1501 EVM Layer Construction Top 50 Ω Layer 1 14 Mil GND1 Layer 2 5 Mil Layer 3 V DD1 21 Mil V DD2 Layer 4 05 Mil Layer 5 GND2 07 Mil Solder 50 Ω Layer 6 Notes: 1) All cores consist of 1 oz.

  • Page 21: Schematics, Board Layouts, And Suggested Optics And Cable Assembly Specifications

    Appendix A Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications This appendix contains schematics and corresponding bill of materials for the TLK1501EVM transceiver board along with board layouts. Specifications for the NetLight 1417K4A 1300 nm laser assembly are also included. Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...

  • Page 22: Tlk1501 Evm Transceiver Schematic

    Figure A–1. TLK1501 EVM Transceiver Schematic 0.01 0.01 VDDA2 VDDA1 VDDA2 VDDA1 0.01 0.01 0.01 0.01 0.01 0.01 0.01 0.01 VDDA2 0.01 0.01 0.01 100p 49.9 49.9 100p 49.9 49.9 0.01 100p 0.01 VDDA2 100p 0.01 100p 10k 10k 10k 10k 10k 10k 10k...

  • Page 23: Optical Transceiver Schematic

    Figure A–2. Optical Transceiver Schematic Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...

  • Page 24: Tlk1501 Evm Transceiver Bill Of Materials

    Table A–1.TLK1501 EVM Transceiver Bill of Materials Item Mfg / Dist. Mfg Part No. Ref Des Description Value or Function Digi-Key S2011–02–ND 2 2 HEADER 0.1 x 0.1 Centers Digi-Key S2011–07–ND 2 7 HEADER 0.1 x 0.1 Centers Digi-Key ECS–T1DX475R...

  • Page 25: Top Layer

    Figure A–3. Top Layer 1 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...

  • Page 26: Gnd Layers 2 And

    Figure A–4. GND Layers 2 and 5...

  • Page 27: Power Plane

    Figure A–5. Power Plane 1 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...

  • Page 28: Bottom Layer

    Figure A–6. Bottom Layer 6...

  • Page 29: Bottom Layer

    Figure A–7. Bottom Layer 7 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...
  • Page 30 A-10 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...
  • Page 31 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications A-11...
  • Page 32 A-12 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...
  • Page 33 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications A-13...
  • Page 34 A-14 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...
  • Page 35 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications A-15...
  • Page 36 A-16 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...
  • Page 37 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications A-17...
  • Page 38 A-18 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...
  • Page 39 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications A-19...
  • Page 40 A-20 Schematics, Board Layouts, and Suggested Optics and Cable Assembly Specifications...

  • Page 41: Netlight 1417K4A 1300 Nm Laser 2.5 Gbits/S Speedblaster

    Appendix B NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s SpeedBlaster Transceiver The document shown in this appendix is an advanced information data sheet from Lucent Technologies Inc. Topic Page NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s Speedmaster Transceiver Data Sheet .
  • Page 43 NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s SpeedBlaster Transceiver...
  • Page 45 NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s SpeedBlaster Transceiver...
  • Page 47 NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s SpeedBlaster Transceiver...
  • Page 49 NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s SpeedBlaster Transceiver...
  • Page 50 B-10...
  • Page 51 NetLight 1417K4A 1300 nm Laser 2.5 Gbits/s SpeedBlaster Transceiver B-11...
  • Page 52 B-12...
