SOMFY RTS Receiver for SDN Operating Instructions page 2

ADDITIONAL PROGRAMMING INSTRUCTIONS
A. RTS Transmitter
PROGRAMMING ADDITIONAL RTS TRANSMITTERS: Press and hold the programming button of a Telis Transmitter previ-
ously memorized by the RTS Receiver until the LED on the receiver turns on. Press and release the programming button on
the new transmitter or channel. The LED on the receiver will turn off, indicating this transmitter has been memorized. Repeat
this procedure for each transmitter or channel, up to 5 total.
DELETING AN RTS TRANSMITTER FROM MEMORY: Press and hold the programming button of a Telis Transmitter pre-
viously memorized by the RTS Receiver, but not the one to be removed from memory. Continue holding the button until the
LED on the receiver turns on. Press and release the programming button on the transmitter or channel to be removed from
memory. The LED on the receiver will turn off, and that transmitter will no longer operate the RTS receiver.
B. SDN Addressees
CHANGING SDN GROUP ADDRESSES: Connect the RTS Receiver to a computer running the Somfy configuration software.
Select correct com port, then click on connect. Enter the RTS Receiver address next to "Get MTR Addr". Click on Single then
"Get Group Addr". New addresses can be entered in positions 1 - 5. Click on "Set" to confirm.
REMOVING ALL RTS TRANSMITTERS and GROUP ADDRESSES: Press and release the reset button on the RTS Receiver.
The LED will turn on, indicating that no transmitters or group addresses are memorized.
MOTOR COMPATIBILITY
The RTS Receiver for SDN is compatible with the following motors:
Sonesse® 50 RS485 (AC)
Sonesse® 50 RS485 (DC)
LT50 RS485 (AC)
Sonesse® 30 RS485 (DC)
NOTE: Systems that include the Sonesse 50 ILT or the LT50 ILT series motors should not use this product. Please use RTS Receiver
(for Legacy ILT Motors) Part #1822541.
Systems that include the animeo IP Building Controller should not use this product. Please use RTS Receiver for animeo IP
Part #1822447.
ORDERING INFORMATION
DESCRIPTION
RTS Receiver for SDN
USB to RS485
Bus Power Supply
SOMFY SYSTEMS INC
SOMFY NORTH AMERICAN HEADQUARTERS
121 Herrod Blvd., Dayton, NJ 08810
P: (800) 22-SOMFY (76639)
NJ: (609) 395-1300
F: (609) 395-1776
Somfy Systems, Inc. reserves the right to change, update or improve this document without prior notice.
PART NUMBER
1822294
9015260
1822440
