Parts List (Replacement Parts / Exploded View) - Code 3 LED X 2100 Installation & Operation Manual

(Reference numbers identify items shown in Figures on previous pages)
Ref No. Description
#8 x .250" Sheet Metal Screw
#8 x .270" Sheet Metal Screw
#8 x .375" Sheet Metal Screw
5/16" Cable Clamp
1/2" Cable Clamp
3/8" Cable Clamp
S795 27W 12V Halogen Lamp
S795 20W 12V Halogen Lamp
1156 28W 12V Incandescent Lamp
Lens Clip
LED X™ 2100 22.5" Upper Beacon Lens (Clear)
LED X™ 2100 22.5" Lower Beacon Lens (Clear)
22.5" Upper Excalibur Lens (Clear)
22.5" Upper Excalibur Lens (Red)
22.5" Upper Excalibur Lens (Blue)
22.5" Upper Excalibur Lens (Amber)
1 Bottom Outboard Lens - Clear
2 Bottom Center Lens - Clear
3 20W Halogen Stationary or alley Module
27W Halogen Stationary or alley Module
28W Incandescent Stationary or alley Module
4 28W Incandescent Arrowstik Module
5 Halogen Lower Light Head Filter
Green
Clear
Red
Blue
Amber
External D.O.T. Strip Assembly
6 LED flashing light head single
Red
Blue
Amber
LED steady light head single
Red
Blue
Amber
7 LED Corner light head dual Driver Side
Red
Blue
LED Corner light head dual Passenger Side
Red
Blue
8 Outboard Lens Cap
Clear
Red
Blue
Amber
9 Center Lens Cap
Clear
Red
Blue
Amber
10 MR11 35W Stationary Module
11 MR11 35W Alley Module For LED X™
MR11 35W Alley Module For OPTIX™
12 MR11 Heat Shield For LED X
MR11 Heat Shield For OPTIX
Parts List
13
Part No.
T05029
T01215
T00243
T00346
T00903
T00938
T05093
T05092
T01538
T01777
T07971
T07961
T07951
T07952
T07953
T07954
T02361
T02371
S50849M
S50850M
S50851M
S50848M
T05170
T05171
T05179
T05173
T05174
S50838M
T03271
T03272
T03273
T03274
T03281
T03282
T03283
T03284
S51174M
S95943M
S95289
T03293
T07076
