FM07
Vehicle Mount Computer
Intel® Celeron® N3350
Microsoft® Windows® 10 IoT Enterprise
User Guide
Version 1.2
Document Part Number: 9152111I109C
Please read this instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM07 and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate FM07

Summary of Contents for Winmate FM07

  • Page 1 FM07 Vehicle Mount Computer Intel® Celeron® N3350 Microsoft® Windows® 10 IoT Enterprise User Guide Version 1.2 Document Part Number: 9152111I109C Please read this instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    FM07 Vehicle Mount Computer User Guide TABLE OF CONTENTS READ ME FIRST ..............................5 (FR) ..........................6 NFORMATIONS DE SÉCURITÉ (EN) ............................6 AFETY NFORMATION ..............................6 BOUT UIDE CHAPTER 1: INTRODUCTION ..........................7 1.1 I ..............................7 NTRODUCTION 1.2 P .............................
  • Page 3 Warranty Winmate Inc. warrants that each of its products is free from material and workmanship defect for a period of one year starting from the invoice date. If the customer discovers a defect, Winmate Inc. will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period, with transportation charges prepaid.
  • Page 4 FM07 Vehicle Mount Computer User Guide FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions:  This device may not cause harmful interference.  This device must accept any interference received including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a class "B"...

  • Page 5: Read Me First

    Read Me First Read Me First Follow and adhere to all warnings and instructions in this manual. For your safety, please read all safety and operating instructions before using the product. Keep this manual for future reference. Attention: Pour réduire le risque d’incendie ou de choc électrique ne pas exposer l’appareil à la pluie ou à...

  • Page 6: Informations De Sécurité (Fr)

    About This Guide This User Guide provides instruction for the system administrator to follow when configuring and using the FM07 Vehicle Mount Computer. This User Guide has been developed for a FM07 with Windows® 10 IoT Enterprise...

  • Page 7: Chapter 1: Introduction

    1024 x 600 pixel resolution. The FM07 delivers flexibility and mobility in a vehicle mounted computer form factor. FM07 is designed to be mounted on the vehicle and supports 9~36V DC wide power input with ignition. The programmable function keys on the front panel designed for easy access for some of the most important functions or application.

  • Page 8: Package Contents

    FM07 Vehicle Mount Computer User Guide 1.2 Package Contents Standard Before using this device, make sure that all the items listed below are present in your package:    FM07 Computer User Guide Driver CD P/N: 9171111I103X Varies by product specifications P/N: 9152111I109C ...

  • Page 9: Components

    Chapter 1: Introduction 1.3 Components 1.3.1 Front View Item Description 7-inch Touch Acts as one of the inputs for the device Screen Function Keys 5 programmable function keys that can be configured by Win-Set ® Utility Power LED indicator On: Power is on Off: Power is off LED Indicators Storage LED indicator...
  • Page 10 FM07 Vehicle Mount Computer User Guide 1.3.2 Rear View Item Description 1 Watt Speaker Emits sound RAM Mount RAM base dimensions: 38.1 x 30 mm VESA Mount VESA dimensions : 75 x 75 mm...
  • Page 11 Chapter 1: Introduction 1.3.3 Side View Left Side Right Side Item Description USB Connector (DB9) that supports a connection of two USB USB Connector devices. SIM Card Slot is located under protection cover secured with 4 SIM Card Slot screws Press Reset button to clear the memory and reboot the device Reset Button forcibly.
  • Page 12 FM07 Vehicle Mount Computer User Guide 1.3.4 Top and Bottom View Top Side Bottom Side Item Description WWAN Antenna For WWAN antenna (Optional). GPS Antenna For GPS antenna (Optional). Wi-Fi Antenna (Main) For Wi-Fi antenna. Power Button Press power button to start the system.

  • Page 13: Chapter 2: Hardware

    This chapter describes system hardware of FM07 Vehicle Mount Computer. 2.1 System Hardware 2.1.1 Central Processing Unit The FM07 is running on Intel® Celeron N3350 (Apollo Lake), 2M Cache, and the operating system of this device is Windows 10 IoT Enterprise. 2.1.2 Input and Output Connectors The FM07 device supports the following I/O connectors: •...

  • Page 14: Power

    2.3 Power Control 2.3.1 Power Button Power button is located on the top of the device. When the FM07 is connected to the external power and the power button is ON, the device can be powered on. 2.3.2 Ignition Control The FM07 supports power ignition function.
  • Page 15 Chapter 2: Hardware 2.4.1 Connector Description 2.4.1.1 Power Connector The FM07 has M12 type 4 pin power input connector which accepts 9-36V DC power input. Use power cable (supplied with FM07) to connect the FM07 to the source of power. Warning!/ Avertissement! This procedure requires a trained service personnel only, improper installation can cause serious damage to the vehicle or the device.
  • Page 16 FM07 Vehicle Mount Computer User Guide 2.4.1.2 LAN Connector The FM07 has M12 type 12 pin LAN connector. Use LAN cable (supplied with FM07) to connect the FM07 to the Ethernet. Pin Assignment and signal names of LAN Cable 2.4.1.3 RS232 Connector The FM07 has DB-9 RS-232 connector.
  • Page 17 Chapter 2: Hardware 2.4.1.5 DIDO &CANBus Connector The DIDO & CANBus connector is a DB-15 male connector located on the bottom side of the device. The connector supports a CANBus cable or a DIDO cable. Pin Assignment and signal names of DIDO &CANBus Connector and Cable Signal Signal CN1-1...
  • Page 18 FM07 Vehicle Mount Computer User Guide 2.4.1 6 USB 2.0 Connector The FM07 has DB-9 USB 2.0 connector located on the side that can support two USB devices such as printer or scanner. Pin Assignment and signal names of USB 2.0 (D-9 Female) Connector and Cable...

  • Page 19: Antenna Connections

    Chapter 2: Hardware 2.5 Antenna Connections The FM07 is equipped with an 802.11 radio and can be ordered with external remote mount antennas. GPS and WWAN require external remote mount antennas. 1. WWAN External Antenna Connectors (Optional). 2. GPS External Antenna Connector.

  • Page 20: Chapter 3: Software

    This section includes the software and hardware installation, the FM07 configuration, the wireless communication, and some other optional features. Since the FM07 configuration varies by your order, utility programs for its configurations and operations, the examples describe in this section are to be used as a guideline only; therefore, the function configuration of the device might vary.
  • Page 21 Chapter 3: Software 3.2.2 Display In the Windows 10 IoT Enterprise, user can adjust the resolution or adjust brightness. All this functions are managed through the control panel. Start > Control Panel > Appearance and Personalization > Display 3.2.3 Power Options Select a Power Plan Windows 10 IoT Enterprise contains two standard options for power plan: Balanced and Power saver.
  • Page 22 FM07 Vehicle Mount Computer User Guide 3.2.4 Region and Language The instruction for installing, changing and uninstalling language in this section are applicable to FM07 with Windows 7 Professional for Embedded System. Start > Control Panel > Clock, Region and Language > Language 3.2.5 Sounds...

  • Page 23: Winset Introduction

    Chapter 3: Software 3.3 Winset Introduction Winset provides quick access to the tablet’s functions and features, such as setting up shortcuts, using camera, powering on/off built-in devices, programming function key, and changing power management. To launch the Winset, double-tap on Winset Utility Icon .Operations and functions on each menu options is explained in detail in the coming section.

  • Page 24: Using The Wireless Wan (3G/Lte)

    FM07 Vehicle Mount Computer User Guide 3.3.3 DIDO Controller 3.4 Using the Wireless WAN (3G/LTE) The FM07 supports data 4G/LTE connection. Before using the data connection program, please insert the Micro-SIM card to your vehicle mount computer. Caution/ Attention Please power off the tablet before installing the Micro SIM card, or the device might be damaged by the incorrect installation behaviors.

  • Page 25: Using Recovery Wizard To Restore Computer

    3.5 Using Recovery Wizard to Restore Computer The FM07 Vehicle Mount Computer has a dedicate recovery partition stored on the hard drive of the vehicle computer to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to each device.

  • Page 26: Chapter 4: Vehicle Mounting

    FM07 Vehicle Mount Computer User Guide Chapter 4: Vehicle Mounting This chapter describes how to mount the FM07 Vehicle Mount Computer. The FM07 is designed to be mounted inside the vehicle with RAM mount or VESA mount. 4.1 Vehicle Mount Instruction Make sure that the FM07 does not obstruct the driver’s vision and ensures safe driving.
  • Page 27 SUS304 M5 x 12mm Screw 913511101149 Screw Washer 91351110111Y M5 Washer 4.2.2 Mounting Kit 2 - Drill Solution You can order Mounting Kit 2 from Winmate, Part Number: 98K000A0006P Component Winmate Part RAM Mounts Description Quantity Number Part Number RAM round base mounts - 3.68"...
  • Page 28 2. Fasten the keyboard adapter (F) on the other end of the RAM mount ball. 3. Fasten the RAM mount ball (E) screws 4. Fasten screws to attach Winmate Keyboard adapter plate to the FM07, so all mounting parts fastens together.

  • Page 29: Vesa Mount Installation

    The rear cover of the FM07 supports VESA mount (75 x 75 mm). VESA Mounting Installation Instructions: 1. Attach the VESA Plate to the rear cover of the FM07 using 4 x M4 mm Phillips screws 2 .Follow instructions provided by VESA mount parts supplier.

  • Page 30: Appendix A: Product Specifications

    FM07 Vehicle Mount Computer User Guide Appendix A: Product Specifications FM07- 7-inch Vehicle Mount Computer Item Specifications System Processor Intel® Celeron N3350, 2M Cache System Memory 2GB SODIMM DDR3L-1600 (up to 8GB) Storage 64GB M.2 MLC solid state drive SSD Operating System Windows®...
  • Page 31 Appendix A: Product Specifications Environment Considerations Operating Temperature -20°C to 60°C (-4° to 140° F) Humidity 10% to 95% RH, non-condensing IP Rating IP65 Shock MIL-STD-810G Method 516.6 Procedure I, 30 g for 18 ms, 300 m/s2 Vibration MIL-STD-810G Method 514.6 Procedure I, 1.60/ 1.96/ 2.18 g rms for XYZ/ 5- 500 Hz Power Management Power Input...
  • Page 32 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
