Winmate G-WIN User Manual

Rugged vehicle mount display 8.4”/ 10.4”/12.1”
Hide thumbs Also See for G-WIN:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
G-WIN Rugged
Vehicle Mount Display
8.4"/ 10.4"/12.1"
User Manual
V1.0
For more information on this and
other Winmate products, please
visit our website at:
www.winmate.com
Document Part Number: 9152111I102H
Please read this instructions before operating the device and retain them for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G-WIN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate G-WIN

Summary of Contents for Winmate G-WIN

  • Page 1 Vehicle Mount Display 8.4”/ 10.4”/12.1” User Manual V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111I102H Please read this instructions before operating the device and retain them for future reference.

  • Page 2: Table Of Contents

    Contents 1 INTRODUCTION ............................. - 7 - 1.1 F ............................- 7 - EATURES 1.2 P ........................... - 8 - ACKAGE ONTENTS 1.3 M ........................- 9 - ECHANICAL ONCEPT 1.4 D ........................- 10 - ESCRIPTION OF ARTS 1.4.1 Connector Placement ......................- 10 - 1.4.2 Physical Buttons and LED Indicators ..................

  • Page 3: Fcc Statement

    FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received  including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
  • Page 4 Warranty Winmate Inc. warranty guarantees that each of its products will be free from material and workmanship defects for a period of one year from the invoice date. If the customer discovers a defect, we will, at his/her option, repair or replace the defective product at no charge to the customer, provide it is returned during the warranty period of one year, with transportation charges prepaid.

  • Page 5: Customer Service

    Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
  • Page 6 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...

  • Page 7: Introduction

    1 INTRODUCTION Congratulations on purchasing Winmate® G-WIN Vehicle Mount Display. Winmate® G-WIN Vehicle Mount Display comes in rugged aluminum alloy housing with IP65 protection and anti-corrosion coating and great ability for shock and vibration resistance. Sunlight readable panel provide great visibility even in bright light conditions.

  • Page 8: Package Contents

    1.2 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: User Manual 3 Pin Terminal Display Touch Driver CD...

  • Page 9: Mechanical Concept

    1.3 Mechanical Concept On the picture below you can see spare parts exploded drawing of a standard G-WIN Vehicle Mount Display. - 9 -...

  • Page 10: Description Of Parts

    1.4 Description of Parts 1.4.1 Connector Placement G-WIN Display 8.4” R08T200-VMU1 № № Description Description ① ④ RS232 or USB for Touch (Optional) S-Video (Optional) ② ⑤ 9-36V DC Terminal Block (Default) Composite (Optional) ③ ⑥ DC Lockable Input (Optional)
  • Page 11 G-WIN Display 10.4” R10L600-VMP1, R10L100-VMP3 № № Description Description ① ④ 9~36V DC Terminal Block (Default) S-Video (Optional) ② ⑤ DC Lockable Input (Optional) Composite (Optional) ③ RS-232 or USB for Touch (Optional) ⑥ - 11 -...
  • Page 12 G-WIN Display 12.1” R12L100-VMM2, W12L100-VMM9 № № Description Description ① ⑤ RS-232 or USB for Touch(Optional) DVI-D(Optional) ② ⑥ S-Video(Optional) DC Lockable input(Optional) 9~36V DC Terminal ③ ⑦ Composite(Optional) Block(Default) ④ - 12 -...

  • Page 13: Physical Buttons And Led Indicators

    1.4.2 Physical Buttons and LED Indicators Physical buttons and LED indicators located in front or on the rear side of the Display. Physical Buttons Icon Button Function Enter/ Enter / Call the main OSD menu. Menu Exit / Auto Exit / Auto adjustment adjustment Increase the brightness of the display Brightness...

  • Page 14: Installation

    2 INSTALLATION 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 15: Mounting

    G-WIN Vehicle Mount Display devices come with different mounting options suitable for most of the industrial and commercial applications. 2.2.1 VESA Mounting G-WIN Vehicle Mount Display has VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). Size...

  • Page 16: Yoke Mounting

    2.2.2 Yoke Mounting Yoke Mount solution allows to mount your device on a wall or ceiling. You can purchase dash/ yoke mounting kit from Winmate as an optional accessory. Yoke Mounting Kit: Size Winmate Part Number 8.4” 99KK08Z00010 10.4” 99KK00Z00010 Yoke Mount Kit includes: ...
  • Page 17 Mounting Instruction: 1. Place the G-WIN Vehicle Mount Display on the bracket stand, aiming screw hole for each other. 2. Secure three M5x10 screws to fix the device upon the bracket stand. 3. Secure tightly locking handle to the Display.

  • Page 18: Roof Mounting

    2.2.3 Roof Mounting Roof mounting allows mounting your device on the roof. You can purchase roof mounting kit from Winmate as an optional accessory. U-Shape Mounting Kit: Size Winmate Part Number 8.4” 98K008A0000R 10.4” 98K010A00018 - 18 -...
  • Page 19 U-Shape Mounting Kit Mechanical Drawing For 8.4” G-WIN Vehicle Mount Display For 10.4” G-WIN Vehicle Mount Display - 19 -...

  • Page 20: Cable Mounting Considerations

    2.3 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the device. CAUTION/ ATTENTION Observe all local installation requirements for connection cable type and protection level. Suivre tous les règlements locaux d’installations, de câblage et niveaux de protection.

  • Page 21: Connecting Power

    2.4 Connecting Power Please refer to maximum power consumption note before connecting your display to the source of power. 8.4” 10.4” 12.1” Size Maximum power consumption 2.4.1 Connecting to DC Power Source 1. Connect the 3-pin terminal block. 2. Screw the Terminal block to fix the cable. 3.

  • Page 22: Connecting To Ac Power Source

    2.4.2 Connecting to AC Power Source IMPORTANT: Use AC Adapter to connect the device to AC power source for testing purposes only. Connect the AC adapter to the 3 pin terminal block located on the back side of the Display. Connect the power cord to AC adapter.

  • Page 23: Connecting Peripherals

    2.5.1 VGA Connector G-WIN Rugged Display uses standard 15pin D-sub connector. Plug 15-pin VGA signal cable to the VGA connector in the rear of motherboard, and plug the other end to the monitor. Secure cable connectors with hexagonal copper pillars M3x4mm.

  • Page 24: S-Video

    2.5.2 S-Video Use Mini-DIN connector to connect S-Video to the display. Pin № Pin № Signal Name Signal Name 2.5.3 Composite Use composite video cable to connect composite video input. Pin № Pin № Signal Name Signal Name Composite Video Signal 2.5.4 DVI-D Connector Use DVI-D to connector in the rear of PC system, and plug the other end to the TFT LCD...

  • Page 25: Operating The Device

    3 OPERATING THE DEVICE 3.1 Turning on the System To turn on the Display: 1. Connect the display to the source of power (Refer to Connecting Power section of this quick start guide for more details). 2. Press the power on switch to turn the display on. IMPORTANT: Use AC Adapter to connect the device to AC power source for testing purposes only.

  • Page 26: Navigating The Osd Menu

    3.2 Navigating the OSD Menu This section describes how to navigate the OSD Menu. OPTION ACTION EFFECT Display the main menu on Enter the main menu Press the MENU button the screen. Shift the item selections up or down until it is desired, Select the menu you want +/ - and then press the button...

  • Page 27: Osd Menu In Vga Mode

    3.4 OSD Menu in VGA Mode Summary Icon Description Options Icon Description Options BRIGHTNESS VOLUME ADJUST BRICONTRAST AUDIO CONTRAST SPEAK ON/OFF ANALOG DVI (Optional) H-POSITION POSITION CHANNEL CVBS (Optional) V-POSITION S-Video (Optional) HDMI (Optional) AUTO CLOCK IMAGE RECALL PHASE WHITE BALANCE USER ╘(RED/GREEN/BLUE) COLOR...
  • Page 28 IMAGE You can adjust the value of screen quality automatically.  AUTO: Use to choose the best settings for the current input signal  CLOCK: Use to adjust the value of horizontal image  PHASE: Use to adjust the phase control (Phase adjustment may be required to optimize the display quality) ...
  • Page 29 RECALL You can recall the factory default setting by selecting “YES”. Select “NO” to return the main menu. OSD EXIT You can exit the OSD menu by selecting “YES”. Select “NO” to return the main menu. - 29 -...

  • Page 30: Osd Menu In Dvi Mode

    3.5 OSD Menu in DVI Mode Summary BRIGHTNESS VOLUME ADJUST BRICONTRAST AUDIO CONTRAST SPEAK ON/OFF Not available under DVI POSITION CHANNEL mode BNCs Not available under DVI IMAGE RECALL mode USER COLOR OSD EXIT ╘(RED/GREEN/BLUE) Description of items at the navigation menu: BRICONTRAST Press "+"...
  • Page 31 COLOR You can fine tune the color temperature by USER option if necessary.  USER: Choose RED/GREEN/BLUE to set value of color temperature brightness to suit you own preference  For 9300K, 6500K, and ADC BRIGHTNESS, these functions are not available under DVI mode.

  • Page 32: Osd Menu In Av (Cvbs/S-Video) Mode

    3.6 OSD Menu in AV (CVBS/S-Video) Mode Summary: BRIGHTNESS VOLUME ADJUST BRICONTRAST AUDIO CONTRAST SPEAK ON/OFF ANALOG SHARPNESS CHANNEL CVBS SATURATION S-Video RECALL GAMMA 0 GAMMA 1 GAMMA OSD EXIT GAMMA 2 GAMMA 3 Description of items on the navigation menu: BRICONTRAST Press "+"...
  • Page 33 Press “+” to increase or “-” to obtain the desired color settings. The HUE is defined as a phase shift of the sub-carrier with respect to the burst. AUDIO (optional) You can adjust the setting of speaker, including volume and mute. ...
  • Page 34 OSD EXIT You can exit the OSD menu by selecting “YES”. Select “NO” to return the main menu. - 34 -...

  • Page 35: Troubleshooting

    4 TROUBLESHOOTING 4.1 Troubleshooting Guide If your monitor fails to operate correctly, check the following chart for possible solution before calling for repairs: Condition Check Point • Check if the signal cable is firmly seated in the socket. • The picture does not Check if the Power is ON at the computer •...

  • Page 36: Specifications

    5 SPECIFICATIONS 5.1 Hardware Specifications Model Name R08T200- R10L600- R10L100- R12L100- W12L100- VMU1 VMP1 VMP3 VMM2 VMM9 Display 8.4” 10.4” 12.1” 12.1” Size/Type 10.4” Resolution 800 x 600 800 x 600 1024 x 768 1280 x 800 640 x 480 Brightness 600 (typ.) 600 (typ.)
  • Page 37 Power Input 9-36V DC (Default) Maximum Power Consumption Mechanical Specifications Dimensions (W x 277 x 219.5 315.9 x 250.9 D x H, mm) x 59.7 x 67 VESA Mount, VESA Mount, VESA Mount, VESA Mount, VESA Mounting Yoke Mount, Yoke Mount, Yoke Mount, Yoke Mount, Mount...

  • Page 38: Appendix

    APPENDIX Appendix A: Cleaning the Monitor Before cleaning:  Make sure the device is turned off.  Disconnect the power cable from any AC outlet. When cleaning:  Never spray or pour any liquid directly on the screen or case. ...

  • Page 39: Appendix B: Frequency Table

    Appendix B: Frequency Table The choice of supported modes depends on the monitor native resolution. Refer to the table below for more information about available input signals. B-1 Separate RGB Video Signal (VGA) Input Timing Input Timing Range: H : 30-80KHz; V : 50-75Hz Mode Resolution H-Freq.
  • Page 40 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
