  • Page 1 Winmate FM10 Vehicle Mounted Computer ® ® Microsoft Windows 7 Professional for Embedded System ® ® Microsoft Windows Embedded 8.1 Industry Pro Quick Start Guide...

  • Page 2: Table Of Contents

    Standby / Wakeup Behavior vi. Defroster vii. Antenna Installation viii. RAM Mounts Installation a. Component of RAM Mounts kits b. RAM Mounts assembly Keyboard Mounting Installation For more detail information about this device, please refer to the FM10 User Manual available at http://www.winmate.com/...

  • Page 3: Features

    FM10 Quick Start Guide Features The integrated keypad contains 10 programmable keys, the F1 through F10 keys are user programmable. Key mapping is configured via the hot tab option in the control panel. See programmable key to remap these keys. The default values for these keys are:...
  • Page 4 FM10 Quick Start Guide...

  • Page 5: Unpacking

    FM10 Quick Start Guide ii. Unpacking  Computer FM10  Dock with latch locking key  Power cable (5 m) with 2 x fuse kit  USB Cable (0.3 m)  Stylus Kit with Screw  Cable clamp kit  2 x WiFi External Antenna ...

  • Page 6: Cabling Installation

    1. Place the device on the vehicle dock and make sure the device is Off 2. Connect the CN2 to the FM10 vehicle dock by aligning the connector pins and then push it, twist to fasten the connection.

  • Page 7: Connecting The Power Cable On The Vehicle

    FM10 Quick Start Guide * The Positive (+) and Ignition is connected inside the cable 4. Switch the power switch On, located on the back of the vehicle dock 5. Press the On button, the device is ready for testing b.
  • Page 8 FM10 Quick Start Guide Do not perform the installation on a moving or live electric Warning forklift 1. Remove the vehicle battery before connecting the power cable Wire (Ground) to the vehicle’s chassis (grounding), which can also 2. Connect the Green be negative pole of the battery.
  • Page 9 FM10 Quick Start Guide 6.2 The ignition cable (Blue cable) must be connected to the battery positive if the customer does not want to have ignition function , as following Diagram 6.2 Without Ignition Function 7 Secure the power cable to the device using cable clamps and place the device in the dock.

  • Page 10: Power On Behavior

    The Power button is located at lower right of the FM10 Note • The FM10 need to be docked in a powered vehicle dock or UPS battery has a sufficient charge to power the device. • If no external power available and the UPS...

  • Page 11: Standby / Wakeup Behavior

    FM10 Quick Start Guide Power Button Action Button Indicator Backlight Press the On button for “2 seconds” Turn On until the battery indicator On (solid green) and then release the button b. Standby / Wakeup Behavior Power Button Action Button...

  • Page 12: Defroster

    FM10 Quick Start Guide vi. Defroster The defroster is always disable when the device is operating Warning from UPS battery power 1. To show the defroster status tap and this screen below shows the information about the defroster 2. The default status of Defroster is Enabled in the auto on mode 3.

  • Page 13: Antenna Installation

    Antenna Installation The FM10 vehicle dock is equipped with SMA Connector for additional external antenna (WiFi or optional WWAN), to install the Antenna please perform the following: 1. Remove the rubber cap on the SMA connector before installing the antenna 2.

  • Page 14: Ram Mounts Installation

    FM10 Quick Start Guide viii. RAM Mounts Installation a. Component of RAM Mounts kits The docking of this device is designed to be mounted to RAM Mount solutions, which provides various types of mount types to fit any industrial use or vehicle. Each mounting kit consists of:...

  • Page 15: Keyboard Mounting Installation

    FM10 Quick Start Guide Step 2. Install RAM Ball base to vehicle dashboard / other surface 2.1 Please make sure that the surface is flat and rigid 2.2 Attach the RAM ball base to the vehicle and fix it using bolt or fasteners.
  • Page 16 FM10 Quick Start Guide Winmate Part RAM Mounts Component Description Number Part Number RAM Clamp Mounts - on Clamp base with 9B000000007T RAM-D-247U-4 2.25” Ball the forklift Arm for 2.25” Ball RAM Arm 9B000000007S RAM-D-201U (Length:8.375”) RAM Ball on the device...
  • Page 17 If the customer discovers a defect, Winmate Communication Inc. will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period, with transportation charges prepaid.
