- Page 1 Windows Embedded 8.1 Industry Pro Quick Start Guide For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 915211101024 Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 Warranty Winmate Inc. warrants that each of its products is free from material and workmanship defect for a period of one year starting from the invoice date. If the customer discovers a defect, Winmate Inc.
-
Page 3: Fcc Regulations
Winmate FM08 Quick Start Guide FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 4 IC Regulations Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.”...
-
Page 5: Table Of Contents
Winmate FM08 Quick Start Guide Contents Components II. Unpacking a. Standard Package Content b. Optional Accessories III. Docking and Undocking the Device a. Docking the device into vehicle dock b. Undocking the device IV. Cable Installation a. Connecting the power cable for office testing b. -
Page 6: Components
Components Front View Rear View with Vehicle Dock... - Page 7 Winmate FM08 Quick Start Guide Left Side View with Vehicle Dock Right Side View with Vehicle Dock...
-
Page 8: Unpacking
Before using this device, make sure that all the items listed below are present in your package: Dock + Latch 5 m Power Cable 0.3 m USB Stylus Kit + Computer FM08 Locking Key with Fuse Kit Cable Screw 98P008A00048... -
Page 9: Optional Accessories
Winmate FM08 Quick Start Guide b. Optional Accessories Your package may include the following items based on your order: 1.2 M 120 4.2 m Adapter 2 m DC Jack Watt Adapter 1.8 m RS232 0.3 m Audio with Power Power Cable... -
Page 10: Docking And Undocking The Device
III. Docking and Undocking the Device a. Docking the device into vehicle dock To dock the device, perform the following: 1. With the device screen side facing out, align and insert the device into the guide pins on the vehicle dock. 2. -
Page 11: Cable Installation
1. Place the device on the vehicle dock and make sure the device is Off 2. Connect the CN2 to the FM08 vehicle dock by aligning the connector pins and then push it, twist to fasten the connection. -
Page 12: Connecting The Power Cable On The Vehicle
b. Connecting the power cable on the vehicle This power cable should only be used on the 12, 24, 36, or 48 Warning Volt forklifts. Select a mounting location and make sure it is not located on Warning the outside the vehicle Color Symbol VCC+... - Page 13 Winmate FM08 Quick Start Guide wire to the vehicle’s positive power source. Connect the black wire to 5. Connect the the vehicle’s negative power source. wire to the vehicle’s ignition switch for the ignition function. 6.1 Connect the blue With Ignition Function 6.2 The ignition cable...
- Page 14 7 Secure the power cable to the device using cable clamps and place the device in the dock. See Power cable routing below. Use the proper cable clamps and not to over tighten it to Warning prevent it from break 8 Press the power switch on the back of the dock See Power switch.
-
Page 15: Power On Behavior
Winmate FM08 Quick Start Guide V. Power On Behavior The Following table shows the Ignition control power scheme on the vehicle installation and office test. Vehicle Installation Power On Office Test / Evaluation Behavior With Ignition Without Ignition Default ‘”0 second”... -
Page 16: Power Button
The Power button is located at lower right of the FM08 Note • The FM08 need to be docked in a powered vehicle dock or UPS battery has a sufficient charge to power the device. • If no external power available and the UPS... -
Page 17: Standby / Wakeup Behavior
Winmate FM08 Quick Start Guide b. Standby / Wakeup Behavior Power Button Action Button Indicator Backlight Press the On button for “2 seconds” until the screen On and Standby or then release the button. The Sleep Mode battery indicator will Off after the... -
Page 18: Calibrating The Screen
VI. Calibrating the Screen Where there is a noticeable discrepancy in the placement of the stylus on the screen and the indicated position of the on screen pointer, recalibrate the screen. Long press Alpha and F6 function key to call the Screen Calibration menu. Follow the instructions on screen calibration starting from #2. -
Page 19: Defroster
Winmate FM08 Quick Start Guide VII. Defroster The defroster is always disable when the device is operating Warning from UPS battery power 1. To show the defroster status open Win-Set and go to the Defroster sub-menu to see the information about the defroster. - Page 20 4. To trigger the Defroster OFF, the Defroster off trip point needs to be in between 5 deg. C and 10 deg. C. The defroster off trip point is configurable as follow: When Defro ster is OFF, heate indica tor in lower right corne...
-
Page 21: Antenna Installation
VIII. Antenna Installation The FM08 vehicle dock is equipped with SMA Connector for additional external antenna (Wi-Fi or optional WWAN), to install the antenna please perform the following: 1. Remove the rubber cap on the SMA connector before installing the antenna. -
Page 22: Ram Mounts Installation
Component of RAM Mounts Kits The docking of this device is designed to be mounted to RAM Mount solutions, which provides various types of mount types to fit any industrial use or vehicle. Each mounting kit consists of: Winmate Part RAM Mounts Component... -
Page 23: Ram Mounts Assembly
Winmate FM08 Quick Start Guide b. RAM Mounts assembly Step 1 Install RAM Clamp to vehicle or forklift 1.1 Determine the position for mounting the RAM clamp mount according to RAM Mounts installation guide and specification. 1.2 Place the upper clamp with ball on the beam, insert the bolt. -
Page 24: Keyboard Mounting Installation
Keyboard Mounting Installation Winmate Part RAM Mounts Component Description Number Part Number 4 VESA Holes on Winmate Keyboard adapter the plate to device plate (designed by 821009131600 and 4 AMPS holes Winmate) to RAM Ball SUS304 M5 x Screw... - Page 25 Winmate FM08 Quick Start Guide This part shows the steps to install the keyboard. 1. Fasten all four screws on the RAM mount ball on the back of the keyboard 2. Fasten the keyboard adapter on the other end of the RAM mount ball.
- Page 26 NOTES __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________...
- Page 27 Winmate FM08 Quick Start Guide NOTES __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________ __________________________________________________________________...
- Page 28 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
