IBM Tower UPS
T1.0kVA and T1.5kVA
Installation and User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5595-1AX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBM 5595-1AX

Summary of Contents for IBM 5595-1AX

  • Page 1 IBM Tower UPS T1.0kVA and T1.5kVA Installation and User's Guide...
  • Page 3 IBM Tower UPS T1.0kVA and T1.5kVA Installation and User's Guide...
  • Page 4 Before using this information and the product it supports, read the general information in Appendix C, “Notices,” on page 41; and read the IBM Safety Information and the IBM Systems Environmental Notices and User Guide on the IBM Documentation CD.

  • Page 5: Table Of Contents

    Getting help and information from the World Wide Rear panels . Web . . 38 Control panel . How to send DSA data to IBM . . 38 LCD description . Software service and support . 38 Display functions .
  • Page 6 Installation and User's Guide...

  • Page 7: Safety

    Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information. Avant d'installer ce produit, lisez les consignes de sécurité. Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. © Copyright IBM Corp. 2014...

  • Page 8: Guidelines For Trained Service Technicians

    This section contains information for trained service technicians. Inspecting for unsafe conditions ® Use this information to help you identify potential unsafe conditions in an IBM product that you are working on. Each IBM product, as it was designed and manufactured, has required safety items to protect users and service technicians from injury.

  • Page 9: Guidelines For Servicing Electrical Equipment

    Make sure that the insulation is not frayed or worn. 4. Remove the cover. 5. Check for any obvious non-IBM alterations. Use good judgment as to the safety of any non-IBM alterations. 6. Check inside the system for any obvious unsafe conditions, such as metal filings, contamination, water or other liquid, or signs of fire or smoke damage.

  • Page 10: Safety Statements

    v Never assume that power has been disconnected from a circuit. Check it to make sure that it has been disconnected. v If you have to work on equipment that has exposed electrical circuits, observe the following precautions: – Make sure that another person who is familiar with the power-off controls is near you and is available to turn off the power if necessary.
  • Page 11 L001 DANGER Hazardous voltage, current, or energy levels are present inside any component that has this label attached. Do not open any cover or barrier that contains this label. (L001) Safety...
  • Page 12 Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v If IBM supplied a power cord(s), connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.
  • Page 13 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call.
  • Page 14 C022 CAUTION: This product might be equipped with a hard-wired power cable. Ensure that a licensed electrician performs the installation per the national electrical code. (C022) Installation and User's Guide...
  • Page 15 R001 Important: The following general safety information should be used for all rack-mounted devices: DANGER Observe the following precautions when working on or around your IT rack system: v Heavy equipment—personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet.

  • Page 16: Product Safety

    CAUTION: v Do not install a unit in a rack where the internal rack ambient temperatures will exceed the manufacturer’s recommended ambient temperature for all your rack-mounted devices. v Do not install a unit in a rack where the air flow is compromised. Ensure that air flow is not blocked or reduced on any side, front, or back of a unit used for air flow through the unit.
  • Page 17 The upstream circuit breaker for Normal AC and Bypass AC must be easily accessible. The unit can be disconnected from AC power source by opening this circuit breaker. This circuit breaker is used for backfeed protection and must comply with IEC/EN 62040-1 (the creepage and clearance distances shall meet the basic insulation requirements for pollution degree 2).
  • Page 18 Installation and User's Guide...

  • Page 19: Chapter 1. Introduction

    To discover the entire range of IBM products and the options available for the IBM UPS device, we invite you to visit our web site at www.ibm.com or contact your IBM representative.

  • Page 20: Environmental Protection

    CD. End of life IBM will process products at the end of their service life in compliance with local regulations. IBM works with companies in charge of collecting and eliminating our products at the end of their service life.
  • Page 21 The battery pack can be removed to comply with regulations and in view of correct disposal. With the IBM UPS device, you can eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and...
  • Page 22 Installation and User's Guide...

  • Page 23: Chapter 2. Presentation

    17.5 x 5.9 x 9.1 / 445 x 150 x 5595-1KX 24.4 / 11.5 13.6 x 5.9 x 9.1 / 345 x 150 x 5595-2KX 35.2 / 16.2 17.5 x 5.9 x 9.1 / 445 x 150 x © Copyright IBM Corp. 2014...

  • Page 24: Rear Panels

    (ROO) control or Remote Power Off (RPO) control Outlets for connection of critical equipment (Primary outlet group) Outlet Group 1: programmable Figure 1. 5595-1AX outlets for connection of equipment Outlet Group 2: programmable outlets for connection of equipment Attached 6 ft. (1.8m) input power...

  • Page 25: Control Panel

    USB communication port RS232 communication port Slot where UPS Network Management Card is installed Connector for Remote On/Off (ROO) control or Remote Power Off (RPO) control Outlets for connection of critical equipment (Primary outlet group) Outlet Group 1: programmable Figure 3. 5595-1KX outlets for connection of equipment Outlet Group 2: programmable outlets for connection of equipment...

  • Page 26: Lcd Description

    Power On On Battery Alarm Indicator Indicator Indicator (green) (yellow) (red) Normal mode 100% 100% 720W 10mi n 800VA Efficiency: ~98% Escape Down Enter On/Off button The following table shows the indicator status and description: Indicator Status Description The UPS is operating Green normally.
  • Page 27 Operation status Normal mode 100% 100% Load/equipment status 720W 10min Battery status 800VA Efficiency: ~98% Efficiency and load group information The following table describes the status information provided by the UPS. Note: If an other indicator appears, see Chapter 7, “Troubleshooting and maintenance,”...

  • Page 28: Display Functions

    Operation status Cause Description The UPS is on Battery mode This warning is approximate, End of backup time and the battery packs are and the actual time to shut running low. down might vary significantly. Depending on the UPS load, the "Battery Low"...

  • Page 29: User Settings

    User settings The following table displays the options that can be changed by the user. Submenu Available settings Default settings Local settings Language [language_name] [English] Select the desired User selectable when language from the UPS is powered for list. Menus, status, the first time.
  • Page 30 Submenu Available settings Default settings In/Out settings Output voltage [100 V][120 V][125 User selectable when V][200 V][208 V][220 UPS is powered for V][230 V][240 V] the first time. Input thresholds [Normal mode] [Normal mode] [Extended mode] Extended mode reduces lower input voltage to 70 V before UPS transfers to battery power.
  • Page 31 Submenu Available settings Default settings In/Out settings Load segments - [No Delay] [1 s] [2 Outlet Group 1: [3 s] (continued) Auto start delay s]...[65354 s] Outlet Group 2: [6 s] The connected load is powered after the specified delay. Load segments - [Disabled] [0s] [1 s] Outlet Group 1:...
  • Page 32 Submenu Available settings Default settings ON/OFF settings Cold start [Enabled] [Disabled] [Enabled] Enables the product to be started on battery power. First cold start is always disabled. Forced reboot [Enabled] [Disabled] [Enabled] If mains recover during a shutdown sequence: If Enabled, shutdown sequence will complete and wait 10 seconds prior to...
  • Page 33 Submenu Available settings Default settings ON/OFF settings Energy saving [Enabled] [Disabled] [Disabled] (continued) If Enabled, UPS will shut down after 5 min. of back-up time, if no load is detected on the output. Sleep mode [Enabled] [Disabled] [Disabled] If Disabled, LCD and communication will turn OFF immediately after...
  • Page 34 Submenu Available settings Default settings Battery settings Automatic battery Every week (in [No test] [Every day] test constant charge) [Every week] [Every otherwise following month] Available only if battery charge mode is set to constant charge. Low battery warning [1 %] [2 %] ... [100 %] [20%] The alarm triggers when the set...

  • Page 35: Chapter 3. Installation

    IBM UPS RS232 communication cable USB communication cable 2 connection cables for the protected equipments (5595-1AX and 5595-2AX models) Documentation and software kit Note: Packing materials must be disposed of in compliance with all local regulations concerning waste. Recycling symbols are printed on the packing materials to facilitate sorting.

  • Page 36: Installation Of Tower Models

    Remove the front panel. Connect the battery module (never pull on the wires). Attach the front panel. Installation of tower models Figure 5. Setup for tower installation Installing the communication card About this task Note: It is not necessary to shut down the UPS before installing the UPS Network Management Card.
  • Page 37 1. Remove the connector panel blank ( which is secured by two screws. 2. Insert the UPS Network Management Card into the slot. 3. Secure the panel by tightening the two screws. Chapter 3. Installation...
  • Page 38 Installation and User's Guide...

  • Page 39: Chapter 4. Communication

    USB port on the computer equipment. 2. Connect the other end of the communication cable to the USB or RS232 communication port on the UPS. The UPS can now communicate with IBM power management software. © Copyright IBM Corp. 2014...

  • Page 40: Replacing The Communication Card

    Replacing the communication card About this task Follow these steps to replace the UPS Network Management Card. 1. Turn off the UPS. 2. Disconnect the network cable. 3. Remove the connector panel blank ( which is secured by two screws. 4.

  • Page 41: Chapter 5. Operation

    To start the UPS: Procedure 1. Verify that the UPS power cord is plugged in. 2. The UPS front panel display illuminates and shows the IBM logo. 3. Verify that the UPS status screen shows 4. Press the button on the UPS front panel for at least 3 seconds.

  • Page 42: Shutting Down The Ups

    (unless the restart function has been disabled) and the load is supplied again. UPS remote control functions The IBM UPS offers a choice between two remote control functions. Remote Power Off (RPO): allows a remote contact to be used to disconnect all the equipment connected to the UPS.

  • Page 43: Remote Control Connection And Test

    These functions are obtained by opening a contact connected between the appropriate pins of connector on the rear panel of the UPS (see the figures in “Remote control connection and test”). Remote control connection and test Procedure 1. Check that the UPS is OFF and disconnected from the AC input source. 2.
  • Page 44 Table 1. Operating modes (continued) High Mode Online Battery Standby Efficiency* Protection features: Power failure Power sag Power surge Under voltage Over voltage Note: (*) High Efficiency mode introduces a delay between loss of input power and switching to battery power. Installation and User's Guide...

  • Page 45: Chapter 6. Ups Maintenance

    Remove watches, rings, bracelets and all other metal objects from the hands and arms v Use tools with an insulated handle Removing the battery tray on tower models About this task This operation must be performed when the UPS is switched OFF. Remove the front panel. © Copyright IBM Corp. 2014...

  • Page 46: Mounting The New Battery Pack

    Carry out the instructions in “Removing the battery tray on tower models” on page 27 in reverse order. Note: To ensure safety and high performance, use only battery packs supplied by IBM. Important: Take care to firmly press together the two parts of the connector during remounting.

  • Page 47: Chapter 7. Troubleshooting And Maintenance

    RPO contact has been activated to shut down the UPS and now prevents restart. An internal failure occurred. UPS fault Record the alarm message and the UPS serial number, then contact your service representative. © Copyright IBM Corp. 2014...

  • Page 48: Service And Support

    Service and support If you have any questions or problems with the UPS, call your Local Distributor or your local service representative and ask for a UPS technical representative. Have the following information ready when you call for service: v Equipment type and model number v Serial number v Firmware version number v Date of failure or problem...

  • Page 49: Chapter 8. Parts Listing

    – Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1 CRU at your request without a service – Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or request IBM to install it, at no additional charge, under the type of warranty service that is designated for your product.
  • Page 50 Installation and User's Guide...

  • Page 51: Appendix A. Technical Specifications

    Storage temperature: -15 to +50 °C (5 to 122 °F) Relative humidity: 0 to 90 % (without condensation) Noise level: < 40 dBA (1) Adjustable to 100/120/125 V, must be set to the identical AC power source value. © Copyright IBM Corp. 2014...
  • Page 52 Important: To reduce the risk of fire, the unit connects only to a circuit provided with branch circuit overcurrent protection as described in this manual, in accordance with the National Electric Code, ANSI/NFPA 70. This product is designed for IT power distribution systems. 5595-1KX 5595-2KX Output Power @ 230 V...
  • Page 53 5595-1KX 5595-2KX Environment 0 to +35 °C 0 to +40 °C v Operating temperature range -15 to +50 °C v Storage temperature range 20 to 90 % (without condensation) v Relative humidity < 40 dBA v Noise level (1) Adjustable to 200/208/220/230/240 V, must be set to the identical AC power source value. When the appliance is used in the EU, use an external circuit breaker in front of line with rating 16 A, 250 V which is IEC/EN 60898-1 standard compliant.
  • Page 54 Installation and User's Guide...

  • Page 55: Appendix B. Getting Help And Technical Assistance

    Appendix B. Getting help and technical assistance If you need help, service, or technical assistance or just want more information about IBM products, you will find a wide variety of sources available from IBM to assist you. Use this information to obtain additional information about IBM and IBM products, determine what to do if you experience a problem with your IBM system or optional device, and determine whom to call for service, if it is necessary.

  • Page 56: Using The Documentation

    The troubleshooting information or the diagnostic programs might tell you that you need additional or updated device drivers or other software. IBM maintains pages on the World Wide Web where you can get the latest technical information and download device drivers and updates.

  • Page 57: Ibm Taiwan Product Service

    To locate a reseller authorized by IBM to provide warranty service, go to http://www.ibm.com/partnerworld/pwhome.nsf/weblook/index_us.html and click Business Partner Locator. For IBM support telephone numbers, see http://www.ibm.com/planetwide. In the U.S. and Canada, call 1-800-IBM-SERV (1-800-426-7378). In the U.S. and Canada, hardware service and support is available 24 hours a day, 7 days a week.
  • Page 58 Installation and User's Guide...

  • Page 59: Appendix C. Notices

    Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.

  • Page 60: Important Notes

    IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM. Some software might differ from its retail version (if available) and might not include user manuals or all program functionality.

  • Page 61: Telecommunication Regulatory Statement

    If IBM determines that the levels of particulates or gases in your environment have caused damage to the device, IBM may condition provision of repair or replacement of devices or parts on implementation of appropriate remedial measures to mitigate such environmental contamination.

  • Page 62: Federal Communications Commission (Fcc) Statement

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.

  • Page 63: Germany Class A Statement

    Klasse A ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der IBM verändert bzw.

  • Page 64: Japan Vcci Class A Statement

    Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse Japan VCCI Class A statement This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which case the user may be required to take corrective actions.

  • Page 65: Taiwan Class A Compliance Statement

    Taiwan Class A compliance statement Appendix C. Notices...
  • Page 66 Installation and User's Guide...

  • Page 67: Appendix D. Glossary

    Appendix D. Glossary Advanced Battery Management (ABM) A three-stage charging system designed to prolong the service life of IBM UPS batteries. By charging the batteries only when necessary, battery life is significantly improved. Charging stage one: quickly recharges battery to approximately 90% of capacity.
  • Page 68 Installation and User's Guide...
  • Page 70 Part Number: 47C9195 Printed in USA (1P) P/N: 47C9195...
