- Page 1 PINK FOLDING RECUMBENT BIKE SF-RB1117 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly. It is your responsibility to ensure that all users of the equipment are informed of all warnings and precautions. -
Page 3: Exploded Diagram
EXPLODED DIAGRAM HARDWARE PACKAGE #14 Φ8x1.5 4pcs #13 M8 x 65mm 4pcs #18 M8 x 35mm 2pcs #15 Φ8x1.5 4pcs #27 Φ6.5 x 1.5 4pcs #26 M6 x 40mm 4pcs #16 M8 4pcs #20 S5 1pc #31 S13, 14, 15 1pc... -
Page 4: Parts List
PARTS LIST Description Spec. Description Spec. Main Frame 20/40x1085mm Spanner S13, 14, 15 Rear Frame oval Chain Cover Φ50x395mm Rear Stabilizer Crank Guard Trim Φ50 Adjustable End Cap Φ50x285mm Front Stabilizer Self-tapping Screw M4x20mm Φ50 Front End Cap Self-tapping Screw M4x20mm 5L/R Pedal... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 1: #12 M10x105mm 1pc #16 M8 4pcs Remove Locking Pin (No. 12) from Rear #15 Φ8x1.5 4pcs Frame (No. - Page 6 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 3: #8a Φ8 x 1.5 3pcs Remove 3 Flat Washers (No. 8a) and #8b M8 3pcs 3 Nylon Nuts (No.
- Page 7 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 5: #16 M8 2pcs Remove 2 Flat Washers (No. 8a), 2 #15 Φ8 x 1.5 2pcs Dome Nuts (No.
- Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 7: #18 M8 x 35 mm 2pcs Remove 2 Allen Bolts (No. 18) and 2 #14 Φ8 x 1.5 2pcs Curved Washers (No.
-
Page 9: Adjustment Instructions
ADJUSTMENT INSTRUCTIONS HOW TO FOLD THE BIKE Pull out Locking Pin (No. 12). Fold the bike. Insert Locking Pin (No. 12) into position B. HOW TO ADJUST THE RESISTANCE To ensure smooth and efficient cycling motions, the belt tension braking system on your folding recumbent bike has been pre-tensioned by our factory during production. - Page 10 EXERCISE MONITOR INSTRUCTION TIME ...................00:00-99:59 SPEED (SPD) ..............0.0-99.9 MI/H DISTANCE (DIST)...............0.00-999.9 MI CALORIES (CAL) ...............0.0-999.9 KCAL KEY FUNCTIONS: MODE: Press to select and lock into a function. CLEAR (RESET): Resets the values to zero by pressing and holding for 3 seconds. OPERATING PROCEDURES: AUTO ON/OFF: The monitor will activate when you press any button or start pedaling.
