HARDWARE

1. MULTIPAK:

a. Normal Operation
Plug the MULTIPAK input power cord into a properly grounded and compatible branch circuit outlet;
the green "System On" LED will illuminate.
b. Wiring Fault
When connected to an incorrectly wired branch circuit outlet, the Red LED will be illuminated.
c. Abnormal Voltage
When the magnitude of the branch circuit outlet voltage is not acceptable*, the MULTIPAK will
disconnect power to its outlets; refer to Section IV: Diagnostic Software for more information).
d. Clearing Memory
The MULTIPAK is able to timestamp the 60 most recent power quality events (information stored in
microcontroller non-volatile memory). The microcontroller memory contents can be cleared at any
time by following this method:
© 2017 AMETEK Electronic Systems Protection / Technical Support: 1-800-645-9721 / surgex.com
i. Diagnostic Software:
The device microcontroller memory may be cleared from within the Diagnostic Software in
the following location: "Tools/Clear Device Memory". See Section V for details.
