I. INTRODUCTION
The MULTIPAK is a state-of-the-art power protector/power conditioner engineered with real-time data acquisition
and storage.

Models:

1. This manual applies to the following MULTIPAK models:
Model Number Voltage (AC RMS)
SX-DS-154
SX-DS-156

2. Key Features:

•
Multi-Stage power protection technology
•
Normal and Common Mode EMI Noise Filter
•
Zero-Voltage Turn-On
•
Zero-Current Turn-Off
•
Inrush Current Elimination (ICE
•
Wiring Fault Detection
•
Catastrophic over/under Voltage Shutdown (COUVS
•
Under Voltage Event Recorder (up to 999 events)
•
Over Voltage Event Recorder (up to 999 events)
•
Power Outage Event Recorder (up to 999 events)
•
Surge Event Recorder (up to 999 events)
o Records surges in all three modes: Line-Neutral, Line-Ground, Neutral-Ground
•
Event Timestamp Recorder (up to 60 events)
o Records time between events
•
Additional features available when connected to a PC
(detailed in Section V: Using the Software)

3. Technical Support:

•
To download software and access further product information, visit
•
For technical support, please contact SurgeX at 1-800-645-9721
© 2017 AMETEK Electronic Systems Protection / Technical Support: 1-800-645-9721 / surgex.com
Current (AC Amps)
120 15
120 15
)
®
Receptacles Input
4 NEMA 5-15P
6 NEMA 5-15P
) with selectable thresholds
®
http://espsurgex.com/product/multipak/
User Manual
Output
NEMA 5-15R
NEMA 5-15R
3
