INTRODUCTION
This Installation Guide Contains the necessary information to Connect the Wireless Modems to the EMR³
Interconnect Box and the Office Computer for running the EMR³ Datalink Program. For Specific
Instructions on Running the Program itself, refer to the Program Manual that is included on the Software
Disk and the Quick Start Guide that is included with the Office Kit.
THE INSTALLATION INSTRUCTION VARY BY MODEM TYPE – FOLLOW THE INSTRUCTIONS FOR
THE SPECIFIC MODEM YOU HAVE.
DESCRIPTION:
The Wireless Kits come in three types:
Kit Number
Description
0846000-030
Office Kit - XTend 900 MHZ -
Americas
0846000-031
Truck Kit with Keypad - XTend
900 MHZ - Americas
0846000-032
Truck Kit - XTend 900 MHZ –
Americas
0846000-033
Optional High Gain Antenna Kit
XTEND 900 MHZ WIRELESS MODEM
For use with VEEDER-ROOT EMR³ DATALINK
INSTALLATION INSTRUCTIONS
Manual 577013-859, Rev. C
General Contents and Comments
The office kit includes:
•
Wireless USB modem with standard
antenna,
•
Regular USB Cable for connecting the
modem to the office PC,
•
Quick Start Guide,
•
Installation Guide
•
Program Disc. The Program Disc includes
the USB Drivers and the full Program
Manual as a .pdf file.
The Truck Kit with Keypad includes:
•
Wireless modem with standard antenna,
•
Special RS-232 Cable for Connecting to
Interconnect Box
•
Cord grip and Velcro patch
•
Installation Guide
•
Optional Keypad for EMR³ Register Head
The Truck Kit without Keypad includes:
•
Wireless modem with standard antenna,
•
Special RS-232 Cable for Connecting to
Interconnect Box
•
Cord grip and Velcro patch
•
Installation Guide
The Optional High Gain Antenna Kit includes:
•
High Gain Antenna
•
Mounting bracket
•
20 feet of cable with connectors
Page 1 of 13
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Digi XTend-PKG
Summary of Contents for Digi XTend-PKG
- Page 1 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C INTRODUCTION This Installation Guide Contains the necessary information to Connect the Wireless Modems to the EMR³ Interconnect Box and the Office Computer for running the EMR³ Datalink Program. For Specific Instructions on Running the Program itself, refer to the Program Manual that is included on the Software Disk and the Quick Start Guide that is included with the Office Kit.
- Page 2 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C INDIVIDUAL MODEM UNIQUE ADDRESS - IMPORTANT Each Modem has a Unique Address assigned by Veeder-Root. This number is on the label on the Modem Itself, and on the Modem Box. For each Truck / Interconnect Box, this number is your traceability from the Specific Truck to the Office Software.
- Page 3 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C 3. Mount the modem to the back window of the vehicle or other surface of the vehicle using the Velcro patch provided, or the modem can be attached with screws or bolts using the tabs on the modem.
- Page 4 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C For XTend Modem: Green is RX, Black is TX, White is Ground, Red is V+ RS-232 Connect: Green RX Black TX White Ground Red V+ Red to V+ from...
- Page 5 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C FOR XTEND 900 MHZ OFFICE USB MODEMS XTEND OFFICE KIT INSTALLATION: 1. Screw the antenna into the modem and hand tighten. The antenna should point upwards. If using the High Gain Antenna, it connects to the same location.
- Page 6 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C INSTALLING USB MODEM DRIVERS The Modem is a “plug-and-play” device that should automatically be detected by your PC. “Found New Hardware Wizard” dialog box appears 1.
- Page 7 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C Finding the communications port for using the USB Modem with the DataLink Program Start, Control Panel Double Click on System to get the System Properties Window to the left Page 7 of 13...
- Page 8 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C Click on the Hardware Tab Click on Device Manager Device Manager Screen: Page 8 of 13...
- Page 9 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C Click on the “+” of Ports and you will find the MaxStream USB Modem Communication Port. When you click on the “+” of Ports, you will find the MaxStream PKG-U Modem and the computer assigned Com port...
- Page 10 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C OPTIONAL KEYPAD INSTALLATION: In order to install the optional Keypad, the Display will need to be disconnected from the wiring and gently removed from the housing. 1.
- Page 11 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C 6. Connect the keypad wires per this diagram: Page 11 of 13...
- Page 12 MAY NOT APPLY IN ALL CASES. This warranty provides specific legal rights. Other rights which vary from state to state may also apply. MODEM CERTIFICATIONS: Extracted From MaxStream XTend-PKG-R™ RF Modem Product Manual v2.x4x and 9XTend-PKG RF Modems Datasheet 2005. Certifications: FCC Part 15.247...
- Page 13 XTEND 900 MHZ WIRELESS MODEM For use with VEEDER-ROOT EMR³ DATALINK INSTALLATION INSTRUCTIONS Manual 577013-859, Rev. C NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
