Tuning Notes:
The O2 optimizer for this bike model controls the stock closed loop area. This
area is represented by the highlighted cells shown in Figure M. The optimizer
is designed to achieve a target AFR of 13.6 : 1. To use this optimzer you must
retain your stock O2 sensor, (even when using Auto-tune).
It is not necessary to input values in the highlighted area of the fuel table. If
using Auto-tune do NOT input values in this area of the Target AFR table.
The Optimizer will blink while the sensor is being heated up. The units are not
functioning until the light is lit up solid.
FIG.M
