Dynojet Power Commander V Installation Instructions Manual page 6

FIG.J
FIG.K
FIG.L
22-055 www.powercommander.com
14
15
16
TPS connect
17
Plug the PCV wiring harness in-line of the stock TPS connectors (Fig. J).
Locate the stock O2 sensor connection and unplug it (Fig. K).
It is a BLACK 4 pin connector You can follow the wires coming out of the
exhaust to this location.
Plug the O2 Optimizer in-line of the stock O2 sensor and wiring harness.
Secure the O2 optimizer to the frame using the supplied Velcro (Fig. N).
Reinstall all bodywork.
2012 Yamaha T-Max 530 PCV - 6
