  • Page 1 Roger Access Control System CPR32-NET network controller User manual Firmware version: 1.0.4 or newer Hardware version: 1.0 Document version: Rev. B...

  • Page 2: Table Of Contents

    4.3 CPR32-NET operation with memory cards ................. 18 4.4 Secure communication with CPR32-NET ................18 4.4.1 Encrypted communication ................... 18 4.4.2 Communication with CPR32-NET from dedicated host ........... 19 4.5 Full memory reset of CPR32-NET ..................19 4.6 Firmware update ......................20 5.

  • Page 3: Introduction

    Roger company. Note: The CPR32-NET requires PR Master software in version 4.5.4 or newer. Note: Default, free of charge licence for CPR32-NET enables operation with 2 door locks of SALLIS system and 2 alarm zones of INTEGRA alarm panel.

  • Page 4: Installation

    Two RS485 communication ports Ethernet port 10BASE-T 10/100Mb communication port Distances Between CPR32-NET and controller (RS485): max. 1200m Environmental class Class I, indoor general conditions, temperature: +5°C to +40°C, relative humidity: 10 to 95% (no condensation) (acc. to EN 50131-1)
  • Page 5 IN1 input line RS485-1 communication bus (controllers) IN2 input line RACS Clock&Data comm. bus Ground RACS Clock&Data comm. bus IN3 input line Ground IN4 input line RS485-2 communication bus (integrations) Ground RS485-2 communication bus (integrations) Page 5 of 21...
  • Page 6 Fig. 2 Typical connection diagram of CPR32-NET Page 6 of 21...

  • Page 7: Led Indicators

    20VA, but it can also be supplied with 12VDC or 24VDC. The connection of power supply is shown in fig. 4. If CPR32-NET network controller is supplied with 18VAC or 24VDC, then 12V backup battery can be connected in order to provide power supply in case of mains supply shortage.

  • Page 8: Inputs And Outputs

    In case of 12VDC power supply, backup battery cannot be directly connected to CPR32-NET and in such case backup power supply must be provided by 12VDC power supply unit. In case of maximal load at supply outputs AUX (1A) and TML (0.2A), the CPR32-NET requires 20W power output.

  • Page 9: Integration With Integra Series Alarm Panels

    Note: The operation of CPR32-NET in dedicated LAN is guaranteed by Roger. Practical tests proved that CPR32-NET works also in LAN, where multiple systems are operated as well as in WAN but in such case CPR32-NET functioning is not guaranteed by Roger because of number of possible and unpredictable network conditions.
  • Page 10 CPR32-NET webpage (see fig 5) opened with web browser e.g. Internet Explorer. Note: In order to connect with CPR32-NET in local area network (LAN), the computer must be in the same subnet. In case of CPR32-NET with default IP address, the IP address of computer should be 192.168.0.xxx.

  • Page 11: Configuration By Means Of Pr Master Software

    Communication port select CPR32-NET, in the field Server IP enter IP address of CPR32- NET and in the field Server Port enter UDP port of CPR32-NET. In case of operation in the same LAN subnet, IP address and port of CPR32-NET can be automatically detected by PR Master software in window shown in fig.
  • Page 12 NET must have different address. Example of RACS 4 system consisting of two subsystem is shown in fig. 8. Multiple CPR32-NET units forming multiple subsystems can operate within single RACS 4 system. Each CPR32-NET unit must have different IP address but they can use the same UDP port. Page 12 of 21...

  • Page 13: Cpr32-Net Options

    RACS 4 system. It is possible to configure some additional options by clicking CPR32-NET option in the main window of PR Master software, which results in opening of the window shown in fig. 9 with summary of CPR32-NET setup and top menu with following options and commands: Menu: Configuration->Settings...
  • Page 14 In the window opened by means of this option it is possible to assign functions to eight available inputs of CPR32-NET and specify their type (NC or NO). The list of available functions is shown in table 4. Input functions can be momentary or constant type. Depending on that property, the CPR32-NET detects only activation of input (momentary type) or activation and deactivation of the input (constant type).
  • Page 15 (doors) within subsystem. Menu: Configuration->Outputs In the window opened by means of this option it is possible to assign functions to CPR32-NET outputs. CPR32-NET is equipped with 6 transistor outputs and 2 relay outputs. Output lines can be normal or inverted type and they are configured in the same way as output lines of RACS 4 controllers.
  • Page 16 The output remains activated until the problem is eliminated. [77] CPR on The output signals that CPR32-NET is switched on by PR Master software. [78] CPR off The output signals that CPR32-NET is switched off by PR Master software.
  • Page 17 CPR32-NET (e.g. select UTC+1:00 in the field Time zone). If CPR32-NET is connected in LAN then port 123 must be forwarded at router in order to enable communication of CPR32-NET with NTP. If several CPR32-NET are installed in particular access control system then one of them can be connected with NPT, while the others can synchronize their clocks with mentioned CPR32-NET.

  • Page 18: Cpr32-Net Operation With Memory Cards

    CPR32-NET network controller can operate with optional memory card, which can be purchased from Roger. Such card enables recording of 30 million events. The socket for card is shown in fig. 1 and it is located under CR2032 battery.

  • Page 19: Communication With Cpr32-Net From Dedicated Host

    Fig. 12 Encrypted communication in PR Master 4.4.2 Communication with CPR32-NET from dedicated host It is possible to limit communication with CPR32-NET to dedicated host with particular IP address in order to increase security of communication. This is can be configured by means of CPR32-NET webpage in the menu Networks, in the field Dedicated host, where IP address of such authorized computer can be entered.

  • Page 20: Firmware Update

    CPR32-NET firmware can be updated by means of CPR32-NET webpage or through RS485-1 port. In both cases, it is necessary to upload *.frg firmware file to the CPR32-NET. Firmware update by RS485-1 port is considered as emergency update, which needs to be applied when CPR32-NET webpage cannot be accessed by any reason.

  • Page 21: Product History
