Roger CPR32-NET User Manual

Network controller
Hide thumbs Also See for CPR32-NET:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Roger Access Control System
User manual for
CPR32-NET network controller
Firmware version: 1.0.14 or newer
Hardware version: 1.0
Document version: Rev. F
© 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at
the
www.roger.pl
website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPR32-NET and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roger CPR32-NET

Summary of Contents for Roger CPR32-NET

  • Page 1 Hardware version: 1.0 Document version: Rev. F © 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at www.roger.pl website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).
  • Page 1 Hardware version: 1.0 Document version: Rev. E © 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at www.roger.pl website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).

  • Page 2: Table Of Contents

    4.3 CPR32-NET operation with memory card ................17 4.4 Secure communication with CPR32-NET ................18 4.4.1 Encrypted communication .................... 18 4.4.2 Communication with CPR32-NET from dedicated host ............ 19 4.5 Memory Reset ........................19 4.6 Firmware update ......................19 5. Ordering information....................20 6.

  • Page 2: Table Of Contents

    4.3 CPR32-NET operation with memory card ................17 4.4 Secure communication with CPR32-NET ................18 4.4.1 Encrypted communication .................... 18 4.4.2 Communication with CPR32-NET from dedicated host ............ 19 4.5 Memory Reset ........................19 4.6 Firmware update ......................19 5. Ordering information....................20 6.

  • Page 3: Introduction

    Roger company. Note: The CPR32-NET requires PR Master software in version 4.5.4 or newer. Note: Default, free of charge licence for CPR32-NET enables operation with 2 door locks of APERIO system and 2 alarm zones of INTEGRA alarm panel.

  • Page 3: Introduction

    Roger company. Note: The CPR32-NET requires PR Master software in version 4.5.4 or newer. Note: Default, free of charge licence for CPR32-NET enables operation with 2 door locks of APERIO system and 2 alarm zones of INTEGRA alarm panel.

  • Page 4: Installation

    Two RS485 communication ports Ethernet port 10BASE-T 10/100Mb communication port Distances Between CPR32-NET and controller (RS485): max. 1200m Environmental class Class I, indoor general conditions, temperature: +5°C to +40°C, relative humidity: 10 to 95% (no condensation) (acc. to EN 50131-1)

  • Page 4: Installation

    Two RS485 communication ports Ethernet port 10BASE-T 10/100Mb communication port Distances Between CPR32-NET and controller (RS485): max. 1200m Environmental class Class I, indoor general conditions, temperature: +5°C to +40°C, relative humidity: 10 to 95% (no condensation) (acc. to EN 50131-1)
  • Page 5 CPR32-NET User Manual.doc 2019-04-04 TML- Built-in feeder output 12VDC/0.2A Ground TML+ Built-in feeder output 12VDC/0.2A RS485 -1 communication bus (controllers) IN1 input line RS485-1 communication bus (controllers) IN2 input line not used Ground not used IN3 input line Ground IN4 input line...
  • Page 5 CPR32-NET User Manual.doc 2018-06-14 TML- Built-in feeder output 12VDC/0.2A Ground TML+ Built-in feeder output 12VDC/0.2A RS485 -1 communication bus (controllers) IN1 input line RS485-1 communication bus (controllers) IN2 input line not used Ground not used IN3 input line Ground IN4 input line...

  • Page 6: Cpr32-Net User Manual.doc 2018

    CPR32-NET User Manual.doc 2019-04-04 Fig. 2 Typical connection diagram of CPR32-NET 6/20...

  • Page 6: Cpr32-Net User Manual.doc 2018

    CPR32-NET User Manual.doc 2018-06-14 Fig. 2 Typical connection diagram of CPR32-NET 6/20...

  • Page 7: Led Indicators

    20VA, but it can also be supplied with 12VDC or 24VDC. The connection of power supply is shown in fig. 4. If CPR32-NET network controller is supplied with 18VAC or 24VDC, then 12V backup battery can be connected in order to provide power supply in case of mains supply shortage.

  • Page 7: Led Indicators

    20VA, but it can also be supplied with 12VDC or 24VDC. The connection of power supply is shown in fig. 4. If CPR32-NET network controller is supplied with 18VAC or 24VDC, then 12V backup battery can be connected in order to provide power supply in case of mains supply shortage.

  • Page 8: Inputs And Outputs

    CPR32-NET User Manual.doc 2019-04-04 In case of 12VDC power supply, backup battery cannot be directly connected to CPR32-NET and in such case backup power supply must be provided by 12VDC power supply unit. In case of maximal load at supply outputs AUX (1A) and TML (0.2A), the CPR32-NET requires 20W power output.

  • Page 8: Inputs And Outputs

    CPR32-NET User Manual.doc 2018-06-14 In case of 12VDC power supply, backup battery cannot be directly connected to CPR32-NET and in such case backup power supply must be provided by 12VDC power supply unit. In case of maximal load at supply outputs AUX (1A) and TML (0.2A), the CPR32-NET requires 20W power output.

  • Page 9: Integration With Integra Series Alarm Panels

    Note: The operation of CPR32-NET in dedicated LAN is guaranteed by Roger. Practical tests proved that CPR32-NET can be also used in LAN, where multiple systems are operated as well as in WAN but in such case CPR32-NET functioning is not guaranteed by Roger due to number of possible and unpredictable network conditions.

  • Page 9: Integration With Integra Series Alarm Panels

    Note: The operation of CPR32-NET in dedicated LAN is guaranteed by Roger. Practical tests proved that CPR32-NET can be also used in LAN, where multiple systems are operated as well as in WAN but in such case CPR32-NET functioning is not guaranteed by Roger due to number of possible and unpredictable network conditions.
  • Page 10 CPR32-NET webpage (see fig 5) opened with web browser. Note: In order to connect with CPR32-NET in local area network (LAN), the computer must be in the same subnet. In case of CPR32-NET with default IP address, the IP address of computer should be 192.168.0.xxx.
  • Page 10 CPR32-NET webpage (see fig 5) opened with web browser. Note: In order to connect with CPR32-NET in local area network (LAN), the computer must be in the same subnet. In case of CPR32-NET with default IP address, the IP address of computer should be 192.168.0.xxx.

  • Page 11: Configuration With Pr Master Software

    Communication port select CPR32-NET, in the field Server IP enter IP address of CPR32- NET and in the field Server Port enter UDP port of CPR32-NET. In case of operation in the same LAN subnet, IP address and port of CPR32-NET can be automatically detected by PR Master software as in window shown in fig.

  • Page 11: Configuration With Pr Master Software

    Communication port select CPR32-NET, in the field Server IP enter IP address of CPR32- NET and in the field Server Port enter UDP port of CPR32-NET. In case of operation in the same LAN subnet, IP address and port of CPR32-NET can be automatically detected by PR Master software as in window shown in fig.

  • Page 12: Cpr32-Net Options

    Example of RACS 4 system consisting of two network (subsystem) is shown in fig. 8. Multiple CPR32-NET units forming multiple subsystems can operate within single RACS 4 system. Each CPR32-NET unit must have individual IP address but they can use the same UDP port.

  • Page 12: Cpr32-Net Options

    Example of RACS 4 system consisting of two network (subsystem) is shown in fig. 8. Multiple CPR32-NET units forming multiple subsystems can operate within single RACS 4 system. Each CPR32-NET unit must have individual IP address but they can use the same UDP port.
  • Page 13 Menu: Configuration->Settings In the window opened by means of this option, the administrator can activate/deactivate power supply tests and internal tests of CPR32-NET unit as well as select event memory buffer i.e. internal flash memory or AX-9 memory card. Fig. 9 CPR32-NET options in PR Master Menu: Configuration->Inputs...
  • Page 13 Menu: Configuration->Settings In the window opened by means of this option, the administrator can activate/deactivate power supply tests and internal tests of CPR32-NET unit as well as select event memory buffer i.e. internal flash memory or AX-9 memory card. Fig. 9 CPR32-NET options in PR Master Menu: Configuration->Inputs...
  • Page 14 (doors) within subsystem. Menu: Configuration->Outputs In the window opened by means of this option it is possible to assign functions to CPR32-NET transistor and relay outputs as well as specify their type. Output lines can be normal or inverted type.
  • Page 14 (doors) within subsystem. Menu: Configuration->Outputs In the window opened by means of this option it is possible to assign functions to CPR32-NET transistor and relay outputs as well as specify their type. Output lines can be normal or inverted type.
  • Page 15 The output remains activated until the problem is eliminated. [77] CPR on The output signals that CPR32-NET is switched on by PR Master software. [78] CPR off The output signals that CPR32-NET is switched off by PR Master software.
  • Page 15 The output remains activated until the problem is eliminated. [77] CPR on The output signals that CPR32-NET is switched on by PR Master software. [78] CPR off The output signals that CPR32-NET is switched off by PR Master software.
  • Page 16 CPR32-NET (e.g. select UTC+1:00 in the field Time zone). If CPR32-NET is connected in LAN then port 123 must be forwarded at router in order to enable communication of CPR32-NET with NTP. If several CPR32-NET are installed in particular access control system then one of them can be connected with NPT, while the others can synchronize their clocks with mentioned CPR32-NET.
  • Page 16 CPR32-NET (e.g. select UTC+1:00 in the field Time zone). If CPR32-NET is connected in LAN then port 123 must be forwarded at router in order to enable communication of CPR32-NET with NTP. If several CPR32-NET are installed in particular access control system then one of them can be connected with NPT, while the others can synchronize their clocks with mentioned CPR32-NET.

  • Page 17: Cpr32-Net Operation With Memory Card

     Restore defaults Menu: Tools->License In the window opened by means of this option it is possible to verify current licence for CPR32-NET and read its serial number which is used for generating new license. CPR32-NET with default license is limited to maximum 2 alarm zones in case of integration with INTEGRA alarm panels and to maximum 2 wireless door locks in case of integration with APERIO system.

  • Page 17: Cpr32-Net Operation With Memory Card

     Restore defaults Menu: Tools->License In the window opened by means of this option it is possible to verify current licence for CPR32-NET and read its serial number which is used for generating new license. CPR32-NET with default license is limited to maximum 2 alarm zones in case of integration with INTEGRA alarm panels, to maximum 2 wireless door locks in case of integration with APERIO system.

  • Page 18: Secure Communication With Cpr32-Net

    4.4 Secure communication with CPR32-NET 4.4.1 Encrypted communication The communication between PR Master software and CPR32-NET as well as between CPR32-NET units in RACS 4 system unit is encrypted by means of AES128 CBC algorithm. By default null password (empty) is used but it is recommended to specify own communication password during configuration of CPR32-NET.

  • Page 18: Secure Communication With Cpr32-Net

    4.4 Secure communication with CPR32-NET 4.4.1 Encrypted communication The communication between PR Master software and CPR32-NET as well as between CPR32-NET units in RACS 4 system unit is encrypted by means of AES128 CBC algorithm. By default null password (empty) is used but it is recommended to specify own communication password during configuration of CPR32-NET.

  • Page 19: Communication With Cpr32-Net From Dedicated Host

    CPR32-NET firmware can be updated by means of CPR32-NET webpage or through RS485-1 port. In both cases, it is necessary to upload *.frg firmware file to the CPR32-NET. Firmware update by RS485-1 port is considered as emergency update which needs to be applied when CPR32-NET webpage cannot be accessed by any reason.

  • Page 19: Communication With Cpr32-Net From Dedicated Host

    CPR32-NET firmware can be updated by means of CPR32-NET webpage or through RS485-1 port. In both cases, it is necessary to upload *.frg firmware file to the CPR32-NET. Firmware update by RS485-1 port is considered as emergency update which needs to be applied when CPR32-NET webpage cannot be accessed by any reason.

  • Page 20: Ordering Information

    Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.

  • Page 20: Ordering Information

    Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
