Roger PR821-CH User Manual

Access and hotel automation controllers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Roger Access Control System
User Manual for
PR821-CH access and hotel automation controllers
Firmware version: 2.18.9 or newer
Hardware version: 1.0
Document version: Rev. F
© 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at
the
www.roger.pl
website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR821-CH and is the answer not in the manual?

Questions and answers

Related Manuals for Roger PR821-CH

Summary of Contents for Roger PR821-CH

  • Page 1 Hardware version: 1.0 Document version: Rev. F © 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at www.roger.pl website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).

  • Page 2: Table Of Contents

    6.6 Air conditioning control ..................... 25 6.7 Intruder alarm system ...................... 26 6.8 Configuration of HRT82MF hall reader ................27 6.9 Configuration of HRT82FK function key panel ..............27 7. PR821-CH controller in third party applications ............28 8. Ordering information....................28 2/29...

  • Page 3: Introduction

    2. D ESCRIPTION AND SPECIFICATION PR821-CH is single room/door controller used in RACS 4 access control system and it additionally offers hotel automation and intruder alarm functionalities. PR821-CH is equipped with card holder and built-in two system EM125kHz/MIFARE® reader. Peripheral devices communicating in RACS CLK/DTA format such as HRT82MF hall reader, function key panel HRT82FK and XM-2 I/O expander can be connected to the controller.

  • Page 4: Installation

    PR821-CH User Manual.doc 2018-04-05 3. I NSTALLATION 3.1 Terminals and connection diagram Fig. 1 PR821-CH controller Table 2. PR821-CH terminals Terminal Description + 12V 12VDC power supply - 12 V Ground IN1 input line IN2 input line IN3 input line...

  • Page 5: Led Indicators

    PR821-CH User Manual.doc 2018-04-05 Fig. 2 Typical connection of PR821-CH controller 3.2 LED indicators Contrary to other PR series controllers, the controller PR821-CH is not equipped with LED indicators but it offers card holder backlight. 5/29...

  • Page 6: Power Supply

    PR821-CH User Manual.doc 2018-04-05 3.3 Power supply Controllers require 12VDC nominal power supply. The power must be connected to +12V and -12V terminals. Additionally, the -12V line can be used as reference potential for the RS485 bus, IN1-IN3 input lines and RACS CLK/DTA bus. The power supply can be provided by means of power supply unit (e.g.

  • Page 7: Communication Of Controller With Peripheral Devices

    CLK/DTA. RACS CLK/DTA is the addressable bidirectional communication standard developed by Roger company. Addresses of all devices connected to CLK and DTA lines must be properly configured in range of 0..15. Factory default address of peripheral devices can be changed according to procedures specified in their manuals but in majority of cases it is not necessary to modify the addresses at all.

  • Page 8: Wall Mounting

    PR821-CH User Manual.doc 2018-04-05 3.9 Wall mounting Fig. 4 Installation of PR821-CH controller 8/29...

  • Page 9: Installation Guidelines

    PR821-CH User Manual.doc 2018-04-05 3.10 Installation guidelines  Install devices in such way as to ensure easy access to screw terminals and jumpers (RST, FDM) located inside the controller – see fig. 5.  Prior to controller installation it is recommended to configure its address (ID number) – see 4.1 Controller address.

  • Page 10: Memory Reset Procedure

    PR821-CH User Manual.doc 2018-04-05 Therefore controller can be always detected on the communication bus with the same address by means of PR Master software. 4.1.2 Addressing during Memory Reset procedure Software address can be configured during Memory Reset procedure – see 4.2 Memory Reset procedure.

  • Page 11: Firmware Update

    2018-04-05 4.3 Firmware update The latest versions of firmware and Roger ISP software are available at www.roger.pl. In order to update firmware it is necessary to connect the device by means of RS485 bus to communication interface (UT-2USB or RUD-1) and then connect the interface to PC with installed Roger ISP software.
  • Page 12 (RS485 bus) equals to 1200m while maximal guaranteed distance from controller to the furthest peripheral device (RACS CLK/DTA bus) equals to 150m. The maximal number of users in the system is 1000 while every PR821-CH can operate with up to 8 guests, each with individual card.

  • Page 13: System Configuration

    PR821-CH User Manual.doc 2018-04-05 Fig. 6 Example diagram of hotel system based on RACS 4 system 5.2 System configuration Prior to connection of controllers to RS485 bus it is necessary to assign individual addresses to them (see section 4.1). Default address of every controller is ID=00.

  • Page 14: Users

    RUD-3 reader and Read card button, to assign hotel room selecting PR821-CH controller in Hotel room field and to assign number to the guest in Guest field. Guest first and last names are optional. Additionally access period can be specified in order to define guest stay time in hotel.

  • Page 15: Functionalities Of Pr821-Ch Controller

    6.1 Input functions PR821-CH controller is equipped with three inputs and XM-2 expander can be connected to the controller in order to increase the number of available inputs by two. Input lines can be configured in regard of their function and NC/NO triggering by means of PR Master software within properties of particular controller.

  • Page 16: Output Functions

    Flag is switched on/off. 6.2 Output functions PR821-CH controller is equipped with one relay and two transistor type outputs and XM-2 expander can be connected to the controller in order to increase the number of relay outputs by two. Output lines can be configured in regard of their function by means of PR Master software within properties of particular controller.

  • Page 17: Function Cards

    PR821-CH User Manual.doc 2018-04-05 Table 4 contains selected output functions of PR821-CH controller and remaining ones are described in the manual Functional description of PRxx1 series controllers. Table 4. Output functions of PR821-CH controller Function Description [41] AIR CONDITION The output represents the state of AIR CONDITION flag.

  • Page 18: System Flags And Timers

    Controller flags (see fig. 9). Some of the flags can be switched manually with toggle button. All flags displayed in Controller flags window are presented in table 5. Fig. 8 PR821-CH timers 18/29...
  • Page 19 Fig. 9 PR821-CH flags Table 5. System flags Flag Flag activation Flag deactivation Flag activation effect - Function cards: - Function cards: LIGTH flag is used to control lighting in hotel room. When the flag is activated then output with the function [64]:LIGHT is...
  • Page 20 - When flag time (timer) elapses - Remotely from PR Master software - Input: - Controller disarming INTRUDER flag is used for anti-burglary functions of PR821-CH controller. When the flag is activated then output with the function [08]:TAMPER - When flag time (timer) elapses...
  • Page 21 [06]:Low battery - Lost communication with XM-2 expander - Input: - Controller disarming ENTRY DELAY flag is used in anti-burglary functions of PR821-CH controller. If the controller is not disarmed by inserting authorized - When flag time (timer) elapses [15]:INTRUDER–delayed card into holder before ENTRY DELAY timer elapses then INTRUDER flag is activated.
  • Page 22 PR821-CH User Manual.doc 2018-04-05 - Function card: - Function card: AIR CONDITION flag is used for air conditioning control in hotel room. In standard scenario of operation the flag is switched on and [FP26]:Toggle AIR CONDITION [FP26]:Toggle AIR CONDITION off by authorized user card in holder. When the flag is activated...
  • Page 23 PR821-CH User Manual.doc 2018-04-05 - Input (activation): - Input (deactivation): WINDOW STATUS flag is used for signaling window opening and closing in hotel room and it is switched on as long as input with the [16]:Window contact [16]:Window contact function [16] is switched on. When the flag is activated then output with the function [49]:WINDOW STATUS is activated and event [200]:Window opened is generated.
  • Page 24 PR821-CH User Manual.doc 2018-04-05 - When hotel staff user card is placed in - When hotel staff user card is removed SERVICE IN PROGRESS flag is used for signalling hotel staff user holder from holder presence in hotel room and it enables 230VAC power supply and air conditioning activation in the room.

  • Page 25: Power Supply (230Vac) Control

    SUPPLY flag but such method has lower priority than switching with card. 6.6 Air conditioning control PR821-CH offers functionalities which enable air conditioning control in hotel room. For that purpose one of controller outputs with the function [41]:AIR CONDITION can be used. AIR CONDITION flag and associated output [41] can be activated in several ways according to table 5.

  • Page 26: Intruder Alarm System

    WINDOW STATUS flag is on plus 15 second. 6.7 Intruder alarm system PR821-CH offers intruder alarm functionalities in hotel room. In order to activate the system it is necessary to select the option Enable anti-burglary functions in controller properties in Options tab.

  • Page 27: Configuration Of Hrt82Mf Hall Reader

    Function Keys tab using PR Master software. Note: Default address of HRT82MF reader is ID=1. In order to use the reader with PR821-CH controller it is necessary to configure the address ID=0. Procedure for address modification is described in HRT82MF Installation Guide.

  • Page 28: Pr821-Ch Controller In Third Party Applications

    2018-04-05 7. PR821-CH CONTROLLER IN THIRD PARTY APPLICATIONS PR821-CH controller can be used in third party hotel systems using PR Master software API. Documentation and software example are available in Automation subfolder after PR Master installation. The PR Master enables following operations: ...
  • Page 29 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
