  • Page 1 NUR ORIGINAL MIT DER RAUTE® WITA U 25 | U 35 | U 55 | U 75 ORIGINAL EINBAU- UND BETRIEBSANLEITUNG SEITE 2–15 TRANSLATION OF THE ORIGINAL INSTALLATION AND OPERATING INSTRUCTIONS PAGE 16–29 www.wita.de...
  • Page 2: Table Of Contents

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 Inhalt Konformitätserklärung ........................3 Sicherheitshinweise ........................4 2.1 Allgemeines ..............................4 2.2 Kennzeichnung von Hinweisen in der Betriebsanleitung ..............4 2.3 Personalqualifikation ............................5 2.4 Gefahren bei Nichtbeachtung der Sicherheitshinweise ..............6 2.5 Sicherheitsbewusstes Arbeiten .........................6...
  • Page 3: Konformitätserklärung

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 EU KONFORMITÄTSERKLÄRUNG Name des Ausstellers: WITA-Wilhelm Taake GmbH Display HE Pumpen Pumpen-, Armaturen- und Regeltechnik Böllingshöfen 85 D-32549 Bad Oeynhausen Gegenstand der Erklärung: Brauchwasserumwälzpumpe Typ: Ausführung: 25-xx, 35-xx, 55-xx, 75-xx Wir erklären in alleiniger Verantwortung, dass die oben genannten Produkte, auf...
  • Page 4: Sicherheitshinweise

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 2 Sicherheitshinweise 2.1 Allgemeines Diese Einbau- und Betriebsanleitung ist Bestandteil des Produktes und enthält grundlegende Informationen, die bei Montage, Betrieb und Wartung zu beachten sind. Aus diesem Grund muss sie unbedingt vor der Aufstellung vom Monteur und dem zuständigen Fachpersonal bzw.
  • Page 5: Personalqualifikation

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 Hier stehen nützliche Hinweise zur Hinweis Handhabung des Produktes. Sie machen auf mögliche Schwierigkeiten aufmerk- sam und sollen für einen sicheren Be- trieb sorgen. Direkt am Produkt angebrachte Hinweise wie zum Beispiel: •...
  • Page 6: Gefahren Bei Nichtbeachtung Der Sicherheitshinweise

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 2.4 Gefahren bei Nichtbeachtung der Sicherheitshinweise Werden die Sicherheitshinweise nicht beachtet, kann dies eine Gefährdung von Personen, Umwelt und Anlage zur Folge haben. Die Nichtbeachtung der Sicherheitshinweise führt zum Verlust jeglicher Schadenersatzansprüche.
  • Page 7: Sicherheitshinweise Für Montage Und Wartungsarbeiten

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 • Gefährdungen durch elektrische Energie müssen ausgeschlossen werden. Hierzu sind z. B. die Vorschriften des VDE und der lokalen Energieversorgungsunternehmen zu beachten. Display HE Pumpen • Sollten an der Anlage Gefahren durch heiße oder kalte Teile auftreten, so müssen diese mit einem Berührungsschutz ver-...
  • Page 8: Transport Und Lagerung

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 zugelassenes Zubehör verwendet werden. Werden andere Teile verwendet, so ist eine Haftung des Herstellers für die daraus entstehenden Folgen ausgeschlossen. 3 Transport und Lagerung Das Produkt ist sofort nach Erhalt auf etwaige Transportschäden hin zu untersuchen. Sollten Transportschäden festgestellt werden, so sind diese beim Spediteur geltend zu machen.
  • Page 9: Bestimmungsgemäße Verwendung

    Anlagen konzipiert und eignen sich auch zur Förderung dünnflüssiger Medien Display HE Pumpen im Bereich Industrie und Gewerbe. 5 Angaben über das Erzeugnis Technische Daten U 25 | U 35 | U 55 | U 75 Kennlinie U 25 Kennlinie U 35 U 25 U 35 Maximale Förderhöhe...
  • Page 10: Lieferumfang

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 Kennlinie U 55 Kennlinie U 75 U 55 U 75 Maximale Förderhöhe 6,0 m 7,5 m Maximaler Durchfluss 3.700 l/h 6.700 l/h Leistungsaufnahme P1 (W) 39 - 80...
  • Page 11: Beschreibung Der Pumpe

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 6 Beschreibung der Pumpe Diese Pumpe ist für das Umwälzen von Wasser/Glykol Gemischen in Solar Anlagen konzipiert. Sie verfügt über drei umschaltbare Leistungsstufen mit denen sie sich optimal an das Rohrnetz Display HE Pumpen anpassen lässt.
  • Page 12: Montage

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 8 Montage Fig. 1 Spannungsfreie Montage mit waagerecht liegendem Pumpenmotor durchführen (Richtungspfeil auf dem Pumpengehäuse zeigt die Flussrichtung an) (Fig.1). Bei Wärmedämmarbeiten darauf achten, dass der Pumpenmotor und das Elektronikgehäuse nicht gedämmt werden.
  • Page 13: Elektrischer Anschluss

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 9 Elektrischer Anschluss Achtung Lebensgefahr! Display HE Pumpen Unsachgemäße Installation und unsachgemäßer elektrischer Anschluss können lebensgefährlich sein. Gefährdungen durch elektrische Energie sind auszuschließen. • Installation und elektrischen Anschluss nur durch Fachpersonal und gemäß der geltenden Vorschriften (z.
  • Page 14: Anlage Füllen Und Entlüften

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 10 Anlage füllen und entlüften Vor Inbetriebnahme der Pumpe ist die Anlage Entlüftungs- Hinweis gründlich zu spülen, damit keine Verunreini- schraube gungen oder Fremdkörper in der Anlage verblei- ben.
  • Page 15: Störungen, Ursachen Und Beseitigungen

    Bedienungsanleitung WITA U 25 | U 35 | U 55 | U 75 12 Störungen, Ursachen und Beseitigungen Wartungsarbeiten oder Reparaturversuche dürfen nur von Fachpersonal unternommen werden. Vor Wartungs-, Reinigungs- und Reparaturarbeiten Anlage spannungsfrei schalten und gegen unbefugtes Wiedereinschalten sichern. Bei hohen Wassertemperaturen und Systemdrücken Pumpe vorher abkühlen lassen.
  • Page 16 Transport and Storage ........................ 22 Intended Use ..........................23 Specifications related to the product ..................23 5.1 Technical data U 25, U 35, U 55, U 75 ....................23 5.2 Scope of delivery ............................23 Description of the Pump ......................25 Pump Settings and Output ......................
  • Page 17: Declaration Of Conformity

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 EC Declaration of Conformity Name of the issuer: WITA-Wilhelm Taake GmbH Display HE Pumpen Pump, valve and control technology Böllingshöfen 85 D-32549 Bad Oeynhausen Subject of the declaration:...
  • Page 18: Safety Instructions

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 2 Safety Instructions 2.1 General These installation and operating instructions are a part of the product, and contain basic information that must be observed during installation, operation and maintenance. For this reason, the installer and specialist personnel or operators must read these instructions prior to set-up.
  • Page 19: Personnel Qualification

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 This symbol indicates useful information Note for handling the product. It indicates potential difficulties and aims to ensure safe operation. Signs attached directly on the product, such as: •...
  • Page 20: Danger Of Not Observing Savety Instructions

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 2.4 Danger of not observing safety instructions Not observing the safety information can endanger persons, the environment and the system. Not observing the safety instructions shall result in the loss of any and all claims to warranty.
  • Page 21: Savety Instructions For Installation An Maintenance Work

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 • Observe the instructions in local or general regulations (e.g. IEC, VDE, etc.), and those of the local energy supplier. • In the event of hazards arising from the system due to Display HE Pumpen contact with hot or cold parts, these parts must be fitted...
  • Page 22: Transport And Storage

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 bear no liability for any consequences resulting from the use of other parts. 3 Transport and Storage After receiving the product, inspect it immediately for damage caused in transport.
  • Page 23: Intended Use

    Display HE Pumpen conveying thin liquid media in industry and commerce. 5 Specifications related to the product Technical data U 25 | U 35 | U 55 | U 75 Characteristic Characteristic U 25...
  • Page 24: Scope Of Delivery

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 Characteristic Characteristic U 55 U 75 U 55 U 75 Maximum delivery head 6.0 m 7.5 m Maximum flow 3.700 l/h 6.700 l/h Power consumption P1 (W)
  • Page 25: Description Of The Pump

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 6 Description of the Pump The pump is designed for the circulation of water / glycol mixtures in solar systems. Because of its three switchable power stages it can be optimally adapted to the pipe network.
  • Page 26: Installation

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 8 Installation Fig. 1 Install the device with the power supply disconnected and with the pump motor lying horizon- tally (the arrow on the pump housing shows the direction of flow) (Fig. 1).
  • Page 27: Electrical Connection

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 9 Electrical connection Warning: Risk of death! Improper installation and improper electrical connection can present a fatal hazard. Hazards posed by electrical power must be eliminated.
  • Page 28: Filling And Bleeding The System

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 10 Filling and Venting the System bleed screw The system must be thoroughly flushed before Note the pump is started up to prevent contami- nants or foreign bodies from remaining in the system.
  • Page 29: Faults, Causes And Remedies

    Operating instrutions WITA U 25 | U 35 | U 55 | U 75 12 Faults, Causes and Remedies Maintenance work or repair attempts may only be undertaken by qualified persons. Switch off the power to the system before performing maintenance, cleaning or repair work, and secure it against unauthorised reactivation.
  • Page 30 Notizen | Notes...
  • Page 31 Notizen | Notes...
  • Page 32 NUR ORIGINAL MIT DER RAUTE® WITA - Wilhelm Taake GmbH HEL-WITA Sp. z o.o. Böllingshöfen 85 | D-32549 Bad Oeynhausen Zielonka, ul. Biznesowa 22 | 86-005 Białe Błota Tel.: +49 5734 512380 | Fax: +49 5734 1752 Tel.: + 52 564 09 00 | Fax: + 52 564 09 22 www.wita.de | info@wita.de...
