Summary of Contents for Ultraflex T85
- Page 1 Installation and maintenance manual STEERING SYSTEM ULTRAFLEX page. 2 pag. 14 page. 27 PARTNER (Dr./Dis./Des. n° 15079/b 17/02/2015)
- Page 2 Products for pleasure boats are constantly tested to check their conformity with the 2013/53/EU. "ULTRAFLEX has over 80 years of experience in the marine industry and is a world leader in the production of mechanical, hydraulic and electronic steering systems, control boxes and steering wheels for any kind of pleasure, fishing or commercial boats.
-
Page 3: Table Of Contents
CONNECTION OF THE CABLE TO THE STEERING SYSTEM..............10 SECTION 4 - SAFETY WARNINGS SAFETY RULES DURING INSTALLATION AND USE...............12 CLOTHING..........................12 SECTION 5 - MAINTENANCE ROUTINE MAINTENANCE.........................13 EXTRAORDINARY MAINTENANCE.....................13 SECTION 6 - DISMANTLING DISMANTLING.........................13 page 3 OF 39 T85 STEERING SYSTEM... -
Page 4: Manual Use And Symbols Used
We recommend training the staff in charge of the product installation and checking their knowledge. STERN The picture aside explains the meaning of some STARBOARD PORT nautical words contained in this manual. page 4 of 39 - T85 STEERING SYSTEM... -
Page 5: Introduction
We remind you that only marked steering systems must be used on the boats marked . We inform you that the ULTRAFLEX warranty is null if some ULTRAFLEX components are installed on a steering system together with products of other brands. page 5... -
Page 6: Section 1 - Product Description
T85 steering system must be used with Ultraflex M66 steering cable PERICOLO WARNING WARNING T85 steering system is not to be used on boats equipped with engines that exceed the maximum horsepower rating of the boat or the speed of 50 knots (57.5 mph). PERICOLO DANGER DO NOT DISASSEMBLE ANY PART OF THE STEERING SYSTEM DURING THE INSTALLATION OF THE CABLE. -
Page 7: Section 2 - Transport
1 nut M12 2 self-threading screw s 1 w asher 4 screw s M6x12 1 tube 1 bushing 1 w oodruff key PERICOLO CAUTION The packaging must be disposed of according to the existing laws. page 7 OF 39 T85 STEERING SYSTEM... -
Page 8: Section 3 - Installation
4 holes of diameter 7 mm (0, indicated in the picture. 28") and one of diameter 67 mm (2,64") page 8 of 39 - T85 STEERING SYSTEM... - Page 9 35- 40Nm (310-354 lbs in). WARNING Do not use a steering wheel with diameter wider than 16" (406mm) and with depth exceeding 5" (127mm). page 9 OF 39 T85 STEERING SYSTEM...
-
Page 10: Connection Of The Cable To The Steering System
Determine the correct cable entry position into the helm according to the proper steering system. PUSH OR PULL TURNING DIRECTIONS Remove protective tube from Ultraflex M66 Turn the steering wheel so as to "pull" the cable end and insert the helix cable into the helm. - Page 11 WARNING Make sure the direction of the steering wheel rotation corresponds to the boat direction. This control must be performed before the boat is operated in the water. page 11 OF 39 T85 STEERING SYSTEM...
-
Page 12: Section 4 - Safety Warnings
4.1 Safety rules during installation and use OBSERVE STRICTLY the following safety rules: ULTRAFLEX declines all responsibility in case the user does not follow these rules and it is not responsible for negligence while using the system. DANGER DO NOT PUT YOUR HANDS BETWEEN MOVING PARTS. -
Page 13: Section 5 - Maintenance
When for any reason, the system is put out of service, it is necessary to follow some rules in order to respect the environment. Conduits, pipelines, plastic or non-metallic components must be disassembled and disposed of separately. page 13 OF 39 T85 STEERING SYSTEM...
