Introduction

Thank you for choosing the BUBBLE-BOX bubble machine as part of your stage effects setup. This machine is
a high output, compact model and will provide consistent large area coverage. Please read and keep this
manual to ensure maximum performance and avoid damage through misuse.

Unpacking

Your BUBBLE-BOX should reach you in good condition and should be supplied with IEC mains lead(s) and
wired & wireless remote controls. If there are any signs of damage or items missing from the packaging,
contact your dealer immediately.

Warning

To prevent risk of fire or electric shock, do not expose electrical parts to rain or moisture.
If liquids are spilled on the housing or through the vents, disconnect the mains, allow the BUBBLE-BOX to dry
out and have it checked by qualified personnel before further use.
Avoid any impact, dropping or extreme pressure to the housing.
No user serviceable parts inside - do not open the case.
Refer all servicing to qualified service personnel.

Placement

The BUBBLE-BOX has an open front fluid tank and should be operated in an upright position.
Choose a position where the bubble output is facing the area to be filled.
Ensure easy access to the rear panel and to the bubble fluid tank for refilling and cleaning.
When moving the unit around, take care not to spill the contents of the tank inside the machine.

Safety

 Check for correct mains voltage and condition of IEC lead before connecting to power outlet
 Check the condition of the remote lead and ensure that it is not trapped
 This unit must be earthed

Cleaning

 Use a soft dry or slightly damp cloth to clean the casing
 Do not use strong solvents for cleaning the unit
 Empty contents and rinse the bubble fluid tanks after each use

Setting up

The BUBBLE-BOX requires bubble fluid to produce the effect.
It is recommended to use qtx bubble fluid for best results (160.574UK, 160.575UK)
For bubbles that glow in UV light, qtx UV bubble fluid may be used (160.576UK, 160.577UK)
A chart for recommended fluids is also provided.
 Pour bubble fluid directly into the front open tank, taking care not to spill on fans beneath the tank
 Connect the supplied remote control to the female IEC on the rear panel
 Connect the IEC mains plug
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
160.550UK User Manual
