Celsi Accent Infusion Manual

16” ribbon mk2 electric fire
Hide thumbs
Table of Contents

Advertisement

Quick Links

Packing Checklist
• 16" Electric Fire
• Fascia
• Remote Control Handset
• 2 x AAA Batteries
• Pack of Coals
• Guarantee Card
• Instruction Manual
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION AND USE OF THIS ELECTRIC FIRE.
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED SPACES OR
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or learning disabilities, or lack of experience
and knowledge, unless given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
16" Ribbon Mk2 Electric Fire
IMPORTANT
RETAIN FOR FUTURE REFERENCE.
OCCASSIONAL USE.
B-1003819
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Accent Infusion and is the answer not in the manual?

Questions and answers

Related Manuals for Celsi Accent Infusion

Summary of Contents for Celsi Accent Infusion

  • Page 1 16” Ribbon Mk2 Electric Fire B-1003819 Packing Checklist • 16” Electric Fire • Fascia • Remote Control Handset • 2 x AAA Batteries • Pack of Coals • Guarantee Card • Instruction Manual IMPORTANT PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND USE OF THIS ELECTRIC FIRE.

  • Page 2: Important Safety Advice

    IMPORTANT SAFETY ADVICE WHEN USING AN ELECTRICAL APPLIANCE, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE FOLLOWING IMPORTANT SAFETY ADVICE. DO NOT cover or obstruct the airflow to the front of the heater. This is to avoid over-heating of the product.

  • Page 3: Technical Specification

    Technical Specification Voltage 230v AC 50HZ Fuse 13Amp Power Consumption General Power 10W to 2000W Heat Output 1000W to 2000W Flame Effect only 10W to 12W Unpacking Remove and discard the plastic bag. Be responsible when handling the packing materials. Keep the original packaging for future transportation and/or storage.

  • Page 4: Installation

    Installation Installation must be carried out by a qualified and competent person. The fireplace opening size required to install the fire Height: 560mm Width: 420mm Depth: 75mm Connect the appliance to single-phase AC supply of the voltage specified on the rating plate. Should the fire be connected directly into the mains supply, then a fused switched spur with a 13- amp fuse must be fitted.

  • Page 5: Operating The Fire

    Operating the Fire Manual Control This appliance can be operated manually using the controls situated under the upper canopy of the fire or by the included remote-control handset. ON / OFF Power Switch This switch is used to turn the mains supply to the appliance ON or OFF. This needs to be in the ON position for both manual and remote operation of the fire.

  • Page 6: Remote Control

    Remote Control Remove the battery cover on the back of the handset by sliding downwards and insert 2 x AAA batteries ensuring that the batteries are fitted correctly. Refit the battery cover. Ensure that the ON / OFF Power Switch on the fire is in the ON position. OPERATING INSTRUCTION WITH REMOTE CONTROL Point the remote-control handset directly towards the fire and press the appropriate button to operate the fire.
  • Page 7 HEAT When the heat icon is selected and blinking, pressing the Increase or Decrease buttons within 5 seconds, will adjust the heat output between Low Heat (1kW) , High Heat (2kW) , and OFF (OF) options. If no buttons are pressed within 5 seconds the heat icon will stop blinking and the heat output will be set to memory.

  • Page 8: Maintenance Instructions

    IMPORTANT This appliance is fitted with an automatic thermal cut-out safety feature to reduce the risk of damage to the appliance in the event of overheating e.g. when covered. If the thermal cut out has detected an abnormal temperature rise within the appliance it will shut off the fan heater and will prevent it from restarting.

  • Page 9: Warranty

    Warranty In the unlikely event of a problem occurring due to a manufacturing fault within 24 months from the date of purchase of the appliance it will be repaired or replaced free of charge. This warranty does not cover consumable items which have a limited lifespan. If a problem should occur, the nature of the problem together with the date of purchase and installer information should be immediately reported to the retailer that the appliance was purchased from.
