e-DLX 600XT Electric Fire
Model No's:
B-1043930
EDLXASRE-6XT
Packing Checklist - Pack 1 of 1
Electric Fire Engine
Remote Control Handset*
Bag of Vermiculite
Instruction Manual
Ceramic Log Set
*THIS PRODUCT REQUIRES 2 X AAA BATTERIES FOR USE IN THE HANDSET (NOT SUPPLIED)
IMPORTANT
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION AND USE OF THIS ELECTRIC FIRE AND
RETAIN FOR FUTURE REFERENCE.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or learning disabilities, or lack of experience and knowledge, unless
given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Celsi e-DLX 600XT
Summary of Contents for Celsi e-DLX 600XT
- Page 1 e-DLX 600XT Electric Fire Model No’s: B-1043930 EDLXASRE-6XT Packing Checklist - Pack 1 of 1 Electric Fire Engine Remote Control Handset* Bag of Vermiculite Instruction Manual Ceramic Log Set *THIS PRODUCT REQUIRES 2 X AAA BATTERIES FOR USE IN THE HANDSET (NOT SUPPLIED) IMPORTANT PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND USE OF THIS ELECTRIC FIRE AND...
- Page 2 IMPORTANT SAFETY ADVICE WHEN USING AN ELECTRICAL APPLIANCE, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE FOLLOWING IMPORTANT SAFETY ADVICE. DO NOT cover the heater, to avoid overheating of the product. DO NOT leave the heater unattended while it is in use.
- Page 3 PRODUCT TECHNICAL DATA SHEET Supplier Name / Trademark Celsi Supplier Model Identifier B-1043930 e-DLX 600XT Voltage 230v AC 50HZ Fuse 13 Amp Nominal Heat Output (Measured) 1.5kW Minimum Heat Output (Indicative) 0.8kW Maximum Continuous Heat Output 1.5kW Auxilliary Electrical Consumption 0.016kW...
-
Page 4: Choosing A Suitable Location
Unpacking Remove and discard the plastic bag. Be responsible when handling the packing materials. Keep the original packaging for future transportation and/or storage. Check all accessories are removed from the packaging before storing it away for future use. KEEP PLASTIC BAGS AWAY FROM CHILDREN! Choosing a Suitable Location This electric fire is designed to be fitted within an existing brick / masonry chimney breast which must be dry with the chimney capped off using a suitable chimney cap. -
Page 5: Installation
Installation Installation must be carried out by a qualified and competent person. The fireplace opening sizes required to install the fire are: e-DLX 600XT Height = 760 to 770mm Width = 610mm to 620mm* Depth = 185mm minimum *carrying handles on the side of the fire (as shown on the side view of figure 1) are removeable to increase clearance on minimum sized openings. - Page 6 e-DLX 600XT Wall Mounting The base of the fire opening must be solid, level and firmly fixed to safely support the weight of the fire. Fig. 2 The fire is held in place using 8 off suitable screws and fasteners in the 8 off fixing holes on thesides of the appliance as shown above in figure 2.
- Page 7 Fig. 3 e-DLX 600XT with Trim option Installation is the same principle as wall mounting but the fire is screwed to the plastered wall to ensure that the facing trims protrude from the fire. For fitting of the trim please refer to the instructions included with the trim.
-
Page 8: Operating The Fire
Manual Control using the controls on the fire Remote Control using the included remote-control handset Celsi App Control using smartphone or tablet voice control, Alexa or Google Assistant Manual Control This fire can be operated manually using the control panel as shown below in figure 5. -
Page 9: Remote Control
Remote Control Remove the battery cover on the rear and insert 2 x AAA batteries ensuring the batteries are fitted correctly. Refit the cover. Please ensure old batteries are disposed of responsibly by contacting your local authority about recycling schemes. Ensure that the ON / OFF Power Switch on the fire is in the ON position. -
Page 10: Clock Setting
To use the remote handset ensure it is pointed directly towards the fire and press the appropriate button to operate the fire. Operating the Fire and Child Lock mode Use the On/Off button to switch the fire On and Off. The remote will automatically lock if left for approximately 90 seconds. -
Page 11: Adaptive Mode
LED Colour Settings Press the Mode/Set button and use the selection wheel to select one of the 16 preset LED colour combinations (the preset number will be displayed flashing on the handset), press again to lock the selection (or the icon will stop flashing after 5 seconds) If preferred, the LED colour settings can be changed individually for Flame Logs... - Page 12 Celsi App Control The Celsi app can be downloaded from the IOS App Store or the Google Play Store by either searching for Celsi or by scanning the QR code using a smart phone or tablet. Page 12 of 21...
-
Page 13: App Setup
The Celsi app can be used alongside the remote handset and provides additional feature of 7 day Timer function. ** During the initial set up of the App, the fire needs to be in pairing mode ** Pairing Mode With the fire ON press the standby button to hear a beep and continue holding for 5 seconds to observe a red flashing light on the rear screen. - Page 14 Connection to Alexa Once you have set up your Celsi account and successfully paired your device you can now also connect to Alexa. Fig. 8 Fig. 9 To connect, open the Alexa App and select the “More” tab in the bottom right hand corner as shown in figure 8 above.
- Page 15 Then click the “search” icon in the top right hand corner as shown below in figure 10, then search for the “smart life” skill by typing “smart life” into the search box as shown below in figure 11. Fig. 10 Fig.
- Page 16 This will prompt you for your e-mail address and password that you used when registering the Celsi APP as shown below, enter the e-mail address and tick the user agreement box as indicated below in figure 14. Complete the verification puzzle as prompted, then enter your password and complete a second verification puzzle as requested.
- Page 17 Connection to Google Assistant Once you have set up your Celsi account and successfully paired your device you can now also connect to Google Assistant. Fig. 16 Fig. 17 To connect, open the Google Assistant App and select the “Device” tab on the left hand side as shown above in figure 16, then click the “add devices”...
- Page 18 Select the “link a smart home device” tab as indicated below in figure 18. Fig. 18 Fig. 19 Click the “search” icon in the top right hand corner as shown figure 19 above, then enter “smart life” as the searched for as shown in figure 20. Select the “smart life icon as shown in figure 21 below.
- Page 19 This will prompt you for your e-mail address and password that you used when registering the Celsi APP as shown below, enter the e-mail address and tick the user agreement box as indicated below in figure 22. Fig. 22 The product should then operate from voice activation, open the google assistant app, click then click the microphone logo at the bottom centre and give instruction i.e.
-
Page 20: Maintenance Instructions
IMPORTANT This fire is fitted with an automatic thermal cut-out safety feature to reduce the risk of dam- age to fire due to overheating. If the fire overheats the heater element will cut out whilst the fan will still continue to run to allow the fire to cool down sufficiently. Once the fire has cooled down the thermal cut-out will reset itself and switch the heater back on. -
Page 21: Warranty
If purchased in the EU please consult the guarantee card that is supplied with your product by the approved Celsi Fires retailer for warranty terms and conditions. This warranty does not cover consumable items which have a limited lifespan.
