Celsi B-1036317 Manual

22” & 33” ultiflame electric fire
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
22" & 33" Ultiflame Electric Fire
Model No's:
B-1036317, & B-1036318
CEUL22RE-RGB & CEUL33RE-RGB
Packing Checklist - Pack 1 of 1
Electric Fire
Remote Control Handset*
Black Chippings Set
Instruction Manual
Log Set
Log Layout Instruction Sheet
*THIS PRODUCT REQUIRES 3 X AAA BATTERIES FOR USE IN THE HANDSET (NOT SUPPLIED)
IMPORTANT
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION AND USE OF THIS ELECTRIC FIRE AND
RETAIN FOR FUTURE REFERENCE.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or learning disabilities, or lack of experience and knowledge, unless
given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-1036317 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Celsi B-1036317

Summary of Contents for Celsi B-1036317

  • Page 1 22” & 33” Ultiflame Electric Fire Model No’s: B-1036317, & B-1036318 CEUL22RE-RGB & CEUL33RE-RGB Packing Checklist - Pack 1 of 1 Electric Fire Remote Control Handset* Black Chippings Set Instruction Manual Log Set Log Layout Instruction Sheet *THIS PRODUCT REQUIRES 3 X AAA BATTERIES FOR USE IN THE HANDSET (NOT SUPPLIED)
  • Page 2 IMPORTANT SAFETY ADVICE WHEN USING AN ELECTRICAL APPLIANCE, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE FOLLOWING IMPORTANT SAFETY ADVICE. DO NOT cover the heater, to avoid overheating of the product. DO NOT leave the heater unattended while it is in use.
  • Page 3 PRODUCT TECHNICAL DATA SHEET Supplier Name / Trademark Celsi Supplier Model Identifier B-1036317 Ultiflame 22” B-1036318 Ultiflame 33” Voltage 230v AC 50HZ Fuse 13 Amp Nominal Heat Output (Measured) 1.6kW Minimum Heat Output (Indicative) 0.8kW Maximum Continuous Heat Output 1.6kW Auxilliary Electrical Consumption 0.016kW...

  • Page 4: Choosing A Suitable Location

    Unpacking Remove and discard the plastic bag. Be responsible when handling the packing materials. Keep the original packaging for future transportation and/or storage. Check all accessories are removed from the packaging before storing it away for future use. KEEP PLASTIC BAGS AWAY FROM CHILDREN! Choosing a Suitable Location This electric fire is designed to be fitted within an existing brick / masonry chimney breast which must be dry with the chimney capped off using a suitable chimney cap.
  • Page 5 Connect the appliance to single-phase AC supply of the voltage specified on the rating plate. Should the fire be connected directly into the mains supply, then a fused switched spur with a 13 amp fuse must be fitted. It is imperative that the power supply is capable of handling a load of 2000 watts (2kw).
  • Page 6 Fig. 3 Ultiflame 22” & 33” with Trim option Installation is the same principle as wall mounting but the fire is screwed to the plastered wall to ensure that the facing trims protrude from the fire. For fitting of the trim please refer to the instructions included with the trim.
  • Page 7 Rennes, Avignon & Lille Models (22”) Fireplace opening for Pablo, Boticelli & Angelo Surrounds, see figures 4, 5 & 6 When fitting this fire into a surround the fireplace opening needs to be prepared at differing heights dependent upon which surround type is to be installed. Fig.
  • Page 8 INSTALLING THE “PABLO” SURROUND 1. Unpack the surround from the wooden crate, check all parts are present and carefully store the components. Contents of Pablo surround:- 1 off hearth panel 1 off R/H leg 1 off L/H leg 1 off R/H infill section 1 off L/H infill section 1 off bottom infill section 1 off shelf...
  • Page 9 6. Fix the top infill and shelf infill into place again with suitable mastic adhesive. 7. Fit shelf into place ensuring it is correctly aligned with legs, mark the position of holes for securing brackets on wall, remove shelf and drill wall and insert fixings in accordance with Point 5, these brackets can be recessed if required.
  • Page 10 INSTALLING THE “BOTICELLI” SURROUND 1. Unpack the surround from the wooden crate, check all parts are present as per below and carefully store the components. Contents of Boticelli surround:- 1 off hearth panel 1 off R/H leg 1 off L/H leg 1 off R/H infill section 1 off L/H infill section 1 off bottom infill section...
  • Page 11 6. Fix the shelf top infill section and shelf infill into place again utilising the same procedure as for the legs, i.e. mark positions, drill holes to suit, remove brackets and secure brackets to wall with suitable fixings as detailed in Point 5. 7.
  • Page 12 INSTALLING THE “ANGELO” SURROUND 1. Unpack the surround from the wooden crate, check all parts are present as per below and carefully store the components. Contents of Angelo surround:- 1 off hearth panel 1 off R/H leg 1 off L/H leg 1 off R/H infill section 1 off L/H infill section 1 off bottom infill section...
  • Page 13 6. Fix the shelf top infill section and shelf infill into place again utilising the same procedure as for the legs, i.e. mark positions, drill holes to suit, remove brackets and secure brackets to wall with suitable fixings as detailed in Point 5. 7.
  • Page 14 Parada Illumia Elite & Avignon Elite Models (33”) Fireplace opening for Parada Illumia Elite & Avignon Elite Surrounds When fitting this fire into these surrounds the fireplace opening needs to be prepared at 103mm from the floor as shown below in figure 13. Fig.
  • Page 15 2. The underside of the hearth should be painted with a weak PVA (8 parts water to 1 part PVA). This will prevent staining penetrating through the stone. The hearth must be centred to the opening. If the fireplace is to be installed on a chimney breast ensure that the opening is also centred to the chimney breast.
  • Page 16 12. Fit shelf top section into place ensuring it is correctly centred, mark the position of holes for securing brackets on wall, remove shelf and drill wall and insert fixings in accordance with Point 5, these brackets can be recessed if required. 13.
  • Page 17 INSTALLING THE “AVIGNON ELITE” SURROUND 1. Unpack the surround from the wooden crate, check all parts are present as per below and carefully store the components. Contents of Avignon surround:- 1 off hearth panel 1 off R/H leg 1 off L/H leg 1 off R/H infill section 1 off L/H infill section 1 off bottom infill section...
  • Page 18 6. Fix the shelf top infill section and shelf infill into place again utilising the same procedure as for the legs, i.e. mark positions, drill holes to suit, remove brackets and secure brackets to wall with suitable fixings as detailed in Point 5. 7.

  • Page 19: Operating The Fire

    Manual Control using the controls on the fire Remote Control using the included remote-control handset Celsi App Control using smartphone or tablet voice control, Alexa or Google Assistant Manual Control This fire can be operated manually using the control panel as shown below in figure 16.

  • Page 20: Remote Control

    Remote Control Remove the battery cover on the rear and insert 3 x AAA batteries ensuring the batteries are fitted correctly. Refit the cover. Please ensure old batteries are disposed of responsibly by contacting your local authority about recycling schemes. Ensure that the ON / OFF Power Switch on the fire is in the ON position.

  • Page 21: Clock Setting

    o use the remote handset ensure it is pointed directly towards the fire and press the appropriate button to operate the fire. Operating the Fire and Child Lock mode Use the On/Off button to switch the fire On and Off. Holding the button in for 5 seconds will enable the Child Lock mode (a padlock will appear on the handset display).

  • Page 22: Adaptive Mode

    Celsi App Control The Celsi app can be downloaded from the IOS App Store or the Google Play Store by either searching for Celsi or by scanning the QR code using a smart phone or tablet. Page 21 of 30...

  • Page 23: App Setup

    The Celsi app can be used alongside the remote handset and provides additional feature of 7 day Timer function. ** During the initial set up of the App, the fire needs to be in pairing mode ** Pairing Mode With the fire off and in Standby mode press and hold the Standby button on the fire to hear a beep and continue holding for 5 seconds to observe a red flashing light on the rear screen.
  • Page 24 Connection to Alexa Once you have set up your Celsi account and successfully paired your device you can now also connect to Alexa. Fig. 19 Fig. 20 To connect, open the Alexa App and select the “More” tab in the bottom right hand corner as shown in figure 19 above.
  • Page 25 Then click the “search” icon in the top right hand corner as shown below in figure 21, then search for the “smart life” skill by typing “smart life” into the search box as shown below in figure 22. Fig. 21 Fig.
  • Page 26 This will prompt you for your e-mail address and password that you used when registering the Celsi APP as shown below, enter the e-mail address and tick the user agreement box as indicated below in figure 25. Complete the verification puzzle as prompted, then enter your password and complete a second verification puzzle as requested.
  • Page 27 Connection to Google Assistant Once you have set up your Celsi account and successfully paired your device you can now also connect to Google Assistant. Fig. 27 Fig. 28 To connect, open the Google Assistant App and select the “Device” tab on the left hand side as shown above in figure 27, then click the “add devices”...
  • Page 28 Select the “link a smart home device” tab as indicated below in figure 29. Fig. 29 Fig. 30 Click the “search” icon in the top right hand corner as shown figure 30 above, then enter “smart life” as the searched for as shown in figure 31. Select the “smart life icon as shown in figure 32 below.
  • Page 29 This will prompt you for your e-mail address and password that you used when registering the Celsi APP as shown below, enter the e-mail address and tick the user agreement box as indicated below in figure 33. Fig. 33 The product should then operate from voice activation, open the google assistant app, click then click the microphone logo at the bottom centre and give instruction i.e.

  • Page 30: Maintenance Instructions

    IMPORTANT This fire is fitted with an automatic thermal cut-out safety feature to reduce the risk of dam- age to fire due to overheating. If the fire overheats the heater element will cut out whilst the fan will still continue to run to allow the fire to cool down sufficiently. Once the fire has cooled down the thermal cut-out will reset itself and switch the heater back on.

  • Page 31: Warranty

    Warranty Congratulations on the purchase of your electric fire. This fire by BFM Europe Ltd is guaranteed for 5 years from the date of purchase against faulty materials or workmanship. Please note the 5 year guarantee comprises of 24 months of parts and labour with an extended 36 months of parts only.

This manual is also suitable for:

B-1036318Ceul22re-rgbCeul33re-rgb
