ME70-169 RF Module User Guide
1vv0301021 rev.3 – 2014-11-14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ME70-169 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telit Wireless Solutions ME70-169

Summary of Contents for Telit Wireless Solutions ME70-169

  • Page 1 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14...
  • Page 2 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 APPLICABILITY TABLE PRODUCT ME70-169 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 2 of 40...
  • Page 3 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Notice While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein.
  • Page 4 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Usage and Disclosure Restrictions License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement.

  • Page 5: Table Of Contents

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Contents Introduction ....................... 7 1.1. Scope ........................7 1.2. ME70-169 Product Description ................7 1.3. Contact Information, Support ................7 1.4. Text Conventions ....................8 1.5. Related Documents ....................9 Regulatory Conformance Information ..............10 2.1.
  • Page 6 Soldering Profile (RoHS Process) ............... 29 Board Mounting Recommendation ................ 31 6.1. Electrical environment ..................31 6.2. Power supply decoupling on ME70-169 module ..........31 6.3. RF layout considerations ..................32 6.4. Antenna connections on printed circuit boards ........... 33 6.5.

  • Page 7: Introduction

    1vv0301021 rev.3 – 2014-11-14 Introduction 1.1. Scope Scope of this document is to present the features and the application of the Telit ME70-169 radio modules (ME70-169). 1.2. ME70-169 Product Description The ME70-169 module is a multi-channel radio board, delivering up to 1W in the 169 MHz ISM band (unlicensed frequency band).

  • Page 8: Text Conventions

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 1.4. Text Conventions Danger – This information MUST be followed or catastrophic equipment failure or bodily injury may occur. Caution or Warning – Alerts the user to important points about integrating the module, if these points are not followed, the module and end user equipment may fail or malfunction.

  • Page 9: Related Documents

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 1.5. Related Documents • [1] EN 300 220-2 v2.4.1, ETSI Standards for SRD , May 2012 • [2] ERC Rec 70-03, ERC Recommendation for SRD, October 2012 • [3] 2002/95/EC, Directive of the European Parliament and of the Council, 27 January 2003 •...

  • Page 10: Regulatory Conformance Information

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Regulatory Conformance Information The module radio transmitter operations must be compliant with some regulatory requirements in terms of frequency bands and emitted power, as detailed below. 2.1. 169 MHz band Requirements The “ERC recommendation 70-03 Annex 2”...

  • Page 11: Other Regulatory Requirements

    Furthermore, the module complies with the ETSI 300 220-2 v2.4.1 standards (specific for SRD). ME70-169 also complies which EN 13757-4 standards (Wireless M-Bus Part4). Finally, the module complies with the new European Directive 2002/95/EC concerning the Restrictive Usage of Hazardous Substances (RoHS).

  • Page 12: General Features

    1vv0301021 rev.3 – 2014-11-14 General Features 3.1. Main Functionalities The ME70-169 module has a digital part and a RF part. The radio link is a Half Duplex bi- directional link. The digital part has the following functionalities: • Communication interface •...

  • Page 13: Mechanical Specifications

    Mounting : • LGA on the 4 external sides Number of pins : The metallic shield used on ME70-169 covers all the SMD components Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 13 of 40...

  • Page 14: Mechanical Drawing

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 3.5. Mechanical drawing Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 14 of 40...

  • Page 15: Dc Specifications

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 3.6. DC Specifications Characteristics ME70-169 Min. Typ. Max. Power Supply +2.3V +3.0V +3.6V (VDD): 0.2x V I/O low level : I/O high level : 0.8x V Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.

  • Page 16: Radio Specifications

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 3.7. Radio Specifications Measured on DIP interface with T = 25°C, Vdd = 3V, 50 ohm impedance and default power register setting if nothing else noted. Global ERC Rec 70-03 169.4 – 169,475 Mhz...
  • Page 17 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 ETSI EN 300 220 V2.3.1 (2009-12) Transmission +/- 6.25 kHz @ 12.5 kHz channelization Frequency error +/- 16.95 kHz (+/-100 ppm) > 25 kHz channelization - 37 dBm in 8.5 kHz BW under normal test conditions - 32 dBm in 8.5 kHz BW under extreme test conditions...

  • Page 18: Power Comsumption

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 3.8. Power comsumption Measured on DIP interface with T = 25°C, 50Ω impedance. Average current Operating mode Supply voltage (V) consumption Reception : 34mA Stand-by (32.768 khz On) : <2µA Sleep (wake up on interruption) : 1.5µA...

  • Page 19: Digital Specifications

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 3.9. Digital Specifications Function Characteristics • 128 kB + 8 kB in system programmable flash • µC 8 kB RAM • 2 kB E PROM • RS232 TTL Full Duplex •...

  • Page 20: Ordering Information

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 3.11. Ordering Information The following equipments can be ordered: • The SMD version (ME70-169) • The DIP interface version (ME70-169) • The Demo Case composed by: n.2 evaluation boards, o n.2 ME50 DIP interface boards, o n.2 ME70 DIP interface boards,...
  • Page 21 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Equipment and Part Number SMD Version B ME70-169/SMD DIP Version B ME70-169/DIP Demo Case D ME50_70-169/ Demo Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 21 of 40...

  • Page 22: Pin-Out And Signals Description

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Pin-out and signals description 4.1. Module Pin OUT (Top View) Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 22 of 40...

  • Page 23: Module Pin-Out Table

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 4.2. Module Pin-out table Pin name Pin type Signal level Function RF Ground connection for external antenna Ext_Antenna RF I/O connection to external antenna RF Ground connection for external antenna Ground...

  • Page 24: Pin-Out Of The Module Dip

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 4.3. Pin-out of the Module DIP Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 24 of 40...

  • Page 25: Dip-Module Pin-Out Correspondence Table

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 4.4. Dip-Module Pin-out correspondence table Pin-Out correspondence between ME70-169/DIP, ME70-169/SMD and internal µC port ME70-169/DIP ME70-169/SMD Comments Connector Name Pin Pin Name IO5_A IO9_I Reserved Pin STANDBY STATUS RADIO STATUS IO4_A...

  • Page 26: Signals Description

    I/O, configurable as input or as output. Input signal which indicates to the module to wake up from low-power WAKEUP mode. See reference document [7] for ME70-169 Output signal which indicates the status of the radio. Set to VCC during RADIO STATUS radio transmission or as soon as a radio frame is detected with correct synchronization word.

  • Page 27: Process Information

    5.1. Delivery ME70-169 modules are delivered in plastic tray packaging, each tray including 50 units. The dimensions of the tray are the following: 329 mm x 176 mm x 5.6 mm. Each unit is placed in a 26.6 mm x 16 mm location. An empty tray weights 45 g and a loaded tray weights around 130 g.

  • Page 28: Storage

    Soldering pad pattern The surface finished on the printed circuit board pads should be made of Nickel/Gold surface. The recommended soldering pad layout on the host board for the ME70-169 is shown in the diagram below: All dimensions in mm Neither via-holes nor wires are allowed on the PCB upper layer in area occupied by the module.

  • Page 29: Solder Past

    5.6. Soldering Profile (RoHS Process) It must be noted that ME70-169 module should not be allowed to be hanging upside down during the reflow operation. This means that the module has to be assembled on the side of the printed circuit board that is soldered last.
  • Page 30 CAUTION - It must also be noted that if the host board is submitted to a wave soldering after the reflow operation, a solder mask must be used in order to protect the ME70-169 radio module’s metal shield from being in contact with the solder wave.

  • Page 31: Board Mounting Recommendation

    6.2. Power supply decoupling on ME70-169 module The power supply of ME70-169 module must be nearby decoupled. A LC filter is strongly recommended in case of DC-DC conversion. It must be placed as close as possible to the radio module power supply pin, VDD.

  • Page 32: Rf Layout Considerations

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 6.3. RF layout considerations Basic recommendations must be followed to achieve a good RF layout: • It is recommended to fill all unused PCB area around the module with ground plane •...

  • Page 33: Antenna Connections On Printed Circuit Boards

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 6.4. Antenna connections on printed circuit boards Special care must be taken when connecting an antenna or a connector to the module. The RF output impedance is 50 ohms, so the strip between the pad and the antenna or connector must be 50 ohms following the tables below.

  • Page 34: Antenna Installation Guidelines

    6.6. ME70-169 Interfacing Example of a full RS-232 connection between a PC or an Automat (PLC) and ME50-169 It applies also for ME70-169, high power version. Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 34 of 40...
  • Page 35 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Example of a minimum PC connection with ME50-169. It applies also for ME70-169, high power version. Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 35 of 40...
  • Page 36 ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Example for sensor connection with ME50-169. It applies also for ME70-169, high power version. Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 36 of 40...

  • Page 37: Ec Declaration Of Conformity

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 EC Declaration of Conformity Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 37 of 40...

  • Page 38: Safety Recommendations

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Safety Recommendations READ CAREFULLY Be sure the use of this product is allowed in the country and in the environment required. The use of this product may be dangerous and has to be avoided in the following areas: •...

  • Page 39: Glossary

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Glossary Adjacent Channel Power Adaptive Frequency Agility Bits per second Bandwidth Decibel Power level in decibel milliwatt (10 log (P/1mW)) Electrically Erasable Programmable Read Only Memory PROM e.r.p Effective radiated power...

  • Page 40: Document History

    ME70-169 RF Module User Guide 1vv0301021 rev.3 – 2014-11-14 Document History Revision Date Changes 2012-10-02 First Release 2013-11-06 Inserted EC Declaration of Conformity 2014-01-31 Inserted clarification notes on table 4.4 Inserted new channel according to WMBUS part4 2013 2014-11-14 Changed overall document structure Added power consumption table in par 3.8...
