ESD events with industrial‑grade, shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and earth grounding must be used as conditions of product warranty. TOUGHCable ™...
Hardware Overview Power Reset Button GPS Antenna Connector Ethernet Port GPS Antenna Connector This is used to connect the included GPS Antenna. Power LED The LED will light blue when the device is connected to a power source. Ethernet Port This Gigabit Ethernet port is used to connect the power and should be connected to the LAN and DHCP server.
Page 4
Release Button Release Button Release Button The default horn (beamwidth: 45°) can be swapped out for an optional horn with a different beamwidth. To remove the attached horn, rotate the horn counterclockwise while depressing the Release Button. To reinstall the horn, align the arrow on the horn with the Release Button.
Hardware Installation There are two pole-mounting methods; follow the appropriate instructions for your selection. Metal Strap Use this option for quick mounting on a pole. Mounting Bracket Use this option for elevation adjustments. Metal Strap 1. Open the Metal Strap and feed it through the base of the PrismStation.
Mounting Bracket 1. Attach the Pole Clamp to the Mounting Bracket. a. Hold the Mounting Bracket with its clamps facing you and the head of the Tightening Bolt facing upward. b. Insert the two Carriage Bolts through the holes of the Mounting Bracket.
Page 7
3. Insert the PrismStation into the Mounting Bracket, and then tighten the bolt to lock the PrismStation in place. 4. Mount the PrismStation on the pole and secure it. a. Place the Mounting Bracket against the pole. b. Slide the slot of the Pole Clamp over the adjacent Carriage Bolt.
Page 8
5. Adjust the elevation angle. a. Loosen the Elevation Screw on the bottom of the bracket. Elevation Screw b. Pivot the PrismStation until the Elevation Indicator shows the desired elevation angle. Elevation Indicator c. Tighten the Elevation Screw to 15 N ∙ m. 6.
Page 9
Connecting to Power and GPS 1. Remove the port cover by pressing up the latch of the cover and sliding the cover out. 2. Remove the rubber gasket from the port cover.
Page 10
3. Connect an Ethernet cable to the Ethernet port. 4. Connect the GPS Antenna to the GPS Antenna Connector.
Page 11
5. Punch out the cutout for the GPS cable. 6. Replace the port cover.
