7.5 Attaching the sandals
Place the sandal so that
the attachment bolt goes
through the slot in the
footplate. To secure, on the
underside of the footplate
place the rubber washer
, followed by the metal
washer and then the knob
onto the attachment
bolt. To position the sandals
simply loosen the knob
under the footplate, select
the position you require
and re-fasten the knob.
7.6 Assemble the tray
To attached the arms to
the tray brackets, loosen the
knob, place the moulding to
the inside of the tray plate
so the plastic teeth mesh.
Replace the knob on the
outside and secure. Repeat
on other side. Ensure both
horizontal tubes are aligned
so they locate in the tray
bracket receivers.
Please be aware of a
gap on the underside of
the tray where a child
could insert their finger
between the metal
bracket and the base of
the plastic tray.
