Leckey Squiggles+ User Manual page 25

10.4 Adjusting the
height of the tray in
prone and supine
The height adjustment
knobs for the tray are
located on either side of
the central spine. Loosen
the 2 knobs , select
the required height
and re-tighten.
10.5 Adjusting the depth
and angle of the tray
Loosen the adjustment knob
on either side, slide the
tubes along the receiving
brackets to achieve the
desired depth and re-tighten
the knobs. To adjust the
angle of the tray loosen the
knobs on either side of
the tray, set the tray to
the required angle and
re-tighten securely.
Never use the tray to steer
or push the chair.
Do not place hot objects
on the tray, greater than
40 degrees Celsius.
Please note that the tray
is for the use of the user
only. Do not lean or place
heavy objects on the
tray greater than 8kgs
(17.6lbs)
Squiggles + Stander User Manual
p.25
