- Page 1 Instruction Manual MJ520 Mobile Hydraulic Scissor Lift Table 770 lbs. (350 kg)
-
Page 2: Daily Inspection
WARNING! Read this operation manual carefully and understand fully the operating instructions. Improper use of this unit could result in injury • DO NOT put foot or hand in scissor mechanism. • Keep neighbouring persons away from the unit when in use. • DO NOT stand in front or behind of lift table when it is in use. • DO NOT crawl under the table. • DO NOT put foot in front of rolling wheels. -
Page 3: Specifications
Capacity Table Table Height Wheel Weight to Elevate 350 kg. 910 x 500 mm 355-1300 mm 128 mm 105 kg. MJ520 770 lbs. 35.8"x 19.7" 14" - 51.2 5" 230 lbs. Service Instructions Change hydraulic oil every 12 months Lubricate the following areas every month: Fitting of Cylinder/oil, Roller Friction Surface/grease, Link Pin/oil, Pedal Fitting Point/oil, Grease Nipple/grease Troubleshooting If the table does not lift when pressing lifting pedal several times: • Adjust the control valve located on... - Page 4 LIFT TABLE PARTS LIST Part Order Part Order Part Order Description Qty. Description Qty. Description Qty. 101M MJ984 Handle Grip 126D MK005 Pump Unit MK027 Retaining Ring MK006 MJ985 Control Handle MK028 MJ986 Elastic Pin MK007 Washer MK029 Retaining Ring MK008 Retaining Ring MJ987...
- Page 5 HYDRAULIC CYLINDER PARTS LIST 211D 217D 217D 265 264 263 262 232 220D Part Order Part Order Part Order Description Qty. Description Qty. Description Qty. MK042 Seal Washer MK081 Piston Rod MK062 Adjusting Bolt MK043 Pump Cylinder MK082 Seal Washer MK063 O-Ring MK044...
