IntesisBox ME-AC-KNX-1i User Manual page 51

KNX – Mitsubishi Electric A.C.
®
IntesisBox
➢ Send telegram after bus recovery
This parameter lets select if the Binary Input "x" will send a telegram, or not, after a
bus recovery and the type of telegram sent (if enabled).
• When "No action" is selected, no telegram will be sent after a bus recovery.
• When "Fixed value" is selected, the binary input will send a telegram with
the same value configured in the "Value on rising edge" parameter. Also a
new parameter will appear (see below).
➢ Sending delay after a bus recovery (seconds)
This parameter lets configure a delay (in seconds) that will be applied after a
bus recovery and, after which, a telegram will be sent.
➢ DPT to be sent
This parameter lets select the DPT type for the value that will be defined in the next
parameter. This value will be sent on a rising edge (contact activated).
➢ Value on rising edge (when contact activated)
This parameter lets define a value for the DTP type configured in the "DPT to
be sent" parameter. This value will be sent on a rising edge (contact
activated).
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SLU
Figure 4.49 Parameter detail
Figure 4.50 Parameter detail
Figure 4.51 Parameter detail
User's manual r2.3 eng
