Summary of Contents for Soundigital POWER 20000.1D
- Page 1 20000.1D...
- Page 2 CONTEÚDO DA EMBALAGEM // PACKAGE CONTENTS 1 Amplificador 20000.1D POWER 1 20000.1D POWER Amplifier 1 Manual do Proprietário 1 Owner’s Manual 1 Chave Allen 2,5mm 1 Allen Wrench 2.5mm 1 Chave Allen 4mm 1 Allen Wrench 4mm 1 Adesivo Promocional 1 Promotional Sticker...
-
Page 3: Additional Information
You've just purchased a product of high quality and carefully. It contains extremely important information to have technology. The SounDigital products are developed to your amplifier working properly. If you feel the need to contact assure maximum efficiency and reliability to your sound our Tech Support, you can reach our technicians through the system. - Page 4 DESCRIPTION PANELS 20000.1D POWER POWER CLIP PROTECT INPUT OUTPUT +12V +12V R E M R E M +12V +12V Audio Input RCA connector; "CLIP" LED indicator (Yellow); Audio Output RCA connector; "Protection" LED indicator (Red); Variable bass boost control (0dB ~ +12dB); Negative speaker connector (-);...
- Page 5 Safety Instructions Electrical Dimensioning To prevent injuries to the user or damage to the For proper operation of your SounDigital amplifier, amplifier, read all the safety instructions written on this you need the proper sizing of the electrical system manual;...
-
Page 6: Input Connections
INSTALLATION Speaker Association Two Subwoofers with Parallel/Serial Coils: For a smooth operation of your SounDigital amplifier, it is POWER CLIP PROTECT important that the minimum working impedance is res- INPUT pected. OUTPUT POWER CLIP PROTECT INPUT Impedance Total OUTPUT per Coil Impedance 2Ω... -
Page 7: Power Connections
INSTALLATION Power Connections Remote Input Connections Simplified Wiring Diagram (Power) Connection Via Main Unit’s Remote Fuse Remote Output Main Unit Multiple Battery Connections For connection of multiple batteries, the use of copper busbars is recommended. These must have equidistant holes and a balanced distribution of the battery connections and the amplifiers, in order to avoid uneven heating of the bar. -
Page 8: Installation Sequence
INSTALLATION Installation Sequence: Check if remote-driven switch is in the Off position, and if the main unit is Off, then insert the fuses or drive the circuit breakers. Before installing the amplifier, disconnect the negative pole from all the batteries in the system; Procedures for Setting the Gain Secure the amplifier so that there is access to the con- To set the gain of your amplifier properly, follow the steps... -
Page 9: Crossover Adjustment
INSTALLATION Crossover Adjustment SounDigital POWER amplifiers feature high-precision adjustable crossovers that increase audio quality and speaker performance.The choice of frequency depends -3dB on the system design, if you have any questions about which crossover frequency to use, refer. If you have any questions about which frequency cut filter to use, refer to... - Page 10 INSTALLATION Table 1 - Power Cables - Recommendation Section 40.000W 2 x A* 2 x A* 4 x A* 4 x A* 6 x A* mm² mm² 6 x A* 67.4 35.000W 2 x A* 4 x A* 4 x A* 30.000W 2 x A* 4 x A*...
- Page 11 RMS Power - CTA 2006 @ 40Hz 4x300A ANL 5Hz ~ 500Hz Graphics Response 5Hz ~ 200Hz X: 19.5 Hz/div Marker 1 Vac vs Frequência Y: 2.0 dB/div X: --- Hz Y: --- dB 35.0 31.0 27.0 23.0 19.0 15.0 44.0 83.0 122.0...
- Page 12 LIMITED WARRANTY SounDigital warrants the original purchaser that this product shall be free of defects in materials an workmanship for a period of twelve (12) months from the original date of purchase. Some countries have extended warranty in case the product is installed by an authorized dealer.
