  • Page 1 OWNER´S MANUAL 800.4...

  • Page 2: Table Of Contents

    Introduction..............................3 Package contents ............................3 Safety instructions ............................4 Panels description Audio inputs and controls .................... 5 Power inputs and audio outputs................6 Installation sequence..........................7 Electrical dimensioning ........................... 8 Audio inputs RCA inputs ..........................8 Crossovers set up ............................9 Wiring diagram Four channels wiring diagram ................

  • Page 3: Introduction

    INTRODUCTION Dear Consumer, Congratulations, you have just acquired a SounDigital product of the highest technology and quality, so we thank you for your trust. SounDigital products are made with raw materials of the highest quality standards, and the most modern processes, equipment and technology are used in their production.

  • Page 4: Safety Instructions

    Wear gloves, safety glasses firmly. Avoid fixing to metallic and all necessary PPE during parts of the vehicle, as this the installation of SounDigital procedure may cause ground amplifiers. looping (noise); THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE EQUIPMENT.

  • Page 5: Panels Description

    PANELS DESCRIPTION Audio inputs – RCA connectors CH1/CH2 Variable Gain control CH3/CH4 CH1/CH2 Crossover switch key Low Pass – Full – High Pass CH3/CH4...

  • Page 6: Power Inputs And Audio Outputs

    PANELS DESCRIPTION 10 11 13 14 15 16 18 19 20 Blue "POWER ON" LED indicador Positive power supply connector (+12VDC) Remote power supply connector (REM) Negative power supply connector (GND) Positive speaker connector (+) Negative speaker connector (-) Positive speaker connector (+) Negative speaker connector (-) Positive speaker connector (+) Negative speaker connector (-)

  • Page 7: Installation Sequence

    INSTALLATION SEQUENCE BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE USER HIMSELF. Warning! Ø Fix the amplifier so that the connectors can be easily accessed; Ø...

  • Page 8: Electrical Dimensioning

    ELECTRICAL DIMENSIONING AND AUDIO INPUTS ELECTRICAL DIMENSIONING For proper operation of your SounDigital amplifier, you need the proper dimensioning of the electrical system and the cables used. The table below shows the minimum section of GND cables, +12VDC cables and speaker output cables according to the power generated by the amplifier.

  • Page 9: Crossovers Set Up

    CROSSOVER SET UP "F" All the frequencies will be reproduced "LP" Frequencies below 80Hz will be reproduced "HP" Frequencies above 80Hz will be reproduced Change the switch to "F" position (Full Range) - All the frequencies will be Ø reproduced as in "Figure 1"; -3dB 20kHz Change the switch to "HP"...

  • Page 10: Wiring Diagram

    (PER CHANNEL) Per channel Model Bridge 800.4 EVO6 4Ω 3 CHANNELS WIRING DIAGRAM All RCA inputs must be connected for the amplifier to work properly. If the signal source is a mono type, use a "Y" cable at the input.

  • Page 11: Two Channel Wiring Diagram

    Minimum impedance of use according to the model (BRIDGE) (BRIDGE) Per channel Model Bridge 800.4 EVO6 4Ω GAIN SETTING Necessary equipament: Ø On the audio player, set the fader control Ø Digital AC voltmeter; to center position; Ø Media with sine wave test tone 60Hz Ø...

  • Page 12: Battery Connection Diagram

    BATTERY CONNECTION DIAGRAM When necessary the association of one or more battery banks to supply the necessary current to the amplifier, it is recommended to use batteries of the same brand, model, and if possible the same manufacturing lot so that the system has the maximum performance.

  • Page 13: Parameters

    The values presented are based on measurements performed in Updates of information made in this document will always be SounDigital's laboratories. All the equipment used in the assays, tests, published and made available for consumer consultation, free of measurements and gauging of the technical parameters of SounDigital charge, on the brand's websites.
