Summary of Contents for Soundigital POWER 5500.1D
- Page 1 3300.1D / 5500.1D / 8800.1D...
- Page 2 CONTEÚDO DA EMBALAGEM // PACKAGE CONTENTS 1 Amplificador POWER 1 POWER Amplifier 1 Manual do Proprietário 1 Owner’s Manual 1 Chave Allen 2,5mm 1 Allen Wrench 2.5mm 1 Chave Allen 4mm 1 Allen Wrench 4mm 1 Adesivo Promocional 1 Promotional Sticker...
-
Page 3: Important Info
You've just purchased a product of high quality and contains extremely important information to have your technology. The SounDigital products are developed to amplifier working properly. If you feel the need to contact our assure maximum efficiency and reliability to your sound Tech Support, you can reach our technicians through the e- system. - Page 4 DESCRIPTION PANELS 3300.1D/5500.1D/8800.1D POWER 12 13 14 Audio input RCA connector; Minimum speaker load allowed (impedance); Audio output RCA connector; Negative speaker connector (-); Variable high pass filter control (5Hz ~ 80Hz); "Power On" LED indicator (Blue); Variable low pass filter control (80Hz ~ 16kHz); "CLIP"...
-
Page 5: Installation
Electrical Dimensioning Safety Instructions To prevent injuries to the user or damage to the For proper operation of your SounDigital amplifier, amplifier, read all the safety instructions written on this you need the proper sizing of the electrical system manual;... -
Page 6: Input Connections
INSTALLATION Speaker Association Two Subwoofers with Parallel/Serial Coils: For a smooth operation of your SounDigital amplifier, it is important that the minimum working impedance is res- pected. Impedance Total per Coil Impedance 2Ω + 2Ω 2Ω Never connect the speakers with a lower impedance than the amplifier nominal 4Ω... -
Page 7: Power Connections
INSTALLATION Power Connections Remote Input Connections Simplified Wiring Diagram (Power). Connection via Main Unit’s Remote. +12V R E M +12V R E M +12V +12V Fuse Remote Output Main Unit Multiple Battery Connections For connection of multiple batteries, the use of copper busbars is recommended. These must have equidistant holes and a balanced distribution of the battery connections and the amplifiers, in order to avoid uneven heating of the bar. -
Page 8: Installation Sequence
INSTALLATION Installation Sequence Procedures for Setting the Gain To set the gain of your amplifier properly, follow the steps Before proceding with the installation, unplug the below: negative from all of the batteries; Disconnect the output cables from the amplifier outputs; Affix the amplifier in such a way you have access to the connectors;... - Page 9 INSTALLATION Crossover Adjustment SounDigital POWER amplifiers feature high-precision adjustable crossovers that increase audio quality and speaker performance. The choice of frequency depends on the system design, if you have any questions about which crossover frequency to use refer. If you have any questions about which frequency cut filter to use, refer to the speaker technical manual, to which the amplifier will be connected.
- Page 10 INSTALLATION Table 1 - Power Cables - Recommendation Section 40.000W 2 x A* 2 x A* 4 x A* 4 x A* 6 x A* mm² 35.000W 2 x A* 4 x A* 4 x A* 6 x A* 67.4 30.000W 2 x A* 4 x A*...
- Page 11 TECHNICAL SPECS 3300.1D RMS Power - CTA 2006 @ 40Hz 3300.1D POWER 1Ω Impedance 1Ω 2Ω 4Ω Power Nominal @ 14.4V 3300W 1815W 998W Power Supply Input Signal and Filters 0.5V ~ 8V Input Sensivity Operating Voltage 9VDC ~ 16VDC Max Current Draw 294A Total Efficiency (Source+Output)
- Page 12 TECHNICAL SPECS 5500.1D RMS Power - CTA 2006 @ 40Hz 5500.1D POWER 1 Impedance 1Ω 2Ω 4Ω Power Nominal @ 14.4V 5500W 3025W 1664W Power Supply Input Signal and Filters 0.5V ~ 8V Input Sensivity Operating Voltage 9VDC ~ 16VDC Max Current Draw 460A Total Efficiency (Source+Output)
- Page 13 TECHNICAL SPECS 8800.1D RMS Power - CTA 2006 @ 40Hz 8800.1D POWER 1Ω Impedance 1Ω 2Ω 4Ω Power Nominal @ 14.4V 8800W 4840W 2662W Power Supply Input Signal and Filters 0.5V ~ 8V Input Sensivity Operating Voltage 9VDC ~ 16VDC Max Current Draw 737A Total Efficiency (Source+Output)
-
Page 14: Limited Warranty
LIMITED WARRANTY SounDigital warrants the original purchaser that this product shall be free of defects in materials an workmanship for a period of twelve (12) months from the original date of purchase. Some countries have extended warranty in case the product is installed by an authorized dealer.
