Phytec phyBOARD-Mira i.MX 6 HTML-Kit Quick Start Manual

-Mira i.MX 6 HTML-Kit
phyBOARD
®
Get your phyBOARD -Mira powered up and connected in just a few simple steps.
®
1) Preparing the Hardware
1. Check the kit content (see overview on the right hand side).
2. Have your connection cables at hand: You need a power supply and optionally a standard
Ethernet cable. Phytec offers an accessory kit which includes these cables.
3. Power up the phyBOARD-Mira. For the 24 V-kit version (A):
connector (included) to a 12 V-24 V ( ± 10%) DC power supply.
Please note the polarity of the connectors, see picture (A)!
If you have bought the optional power supply with your kit, it comes already with the 2-pin connector wired.
4. Turn your power supply on and plug the 2-pin PHOENIX connector into the green jack of your kit.
The Power LED D2 will light up.
