HTP CGH-199O Series Installation, Start-Up, Maintenance, Parts And Warranty

Crossover outdoor water heaters
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation
Start-Up
Maintenance
Parts
Warranty
CGH-199O* Models
*O Denotes Outdoor Models; "LP" Denotes Propane Gas;
"F" Denotes Floor Models with Built-In Pump
The outdoor unit is intended for use in outdoor installations ONLY. DO NOT install the water heater indoors. Installing the
water heater indoors will result in improper water heater operation, property damage, serious personal injury, or death.
This manual must only be used by a qualified installer / service technician. Read all instructions in this manual before installing.
Perform steps in the given order. Failure to do so could result in substantial property damage, severe personal injury, or death.
Improper installation, adjustment, alteration, service, or maintenance could void product warranty and cause property
damage, severe personal injury, or death.
California Proposition 65 Warning: This product contains chemicals known to the State of California to cause cancer, birth
defects, or other reproductive harm.
The manufacturer reserves the right to make product changes or updates without notice and will not be held liable for
typographical errors in literature.
The surfaces of these products contacted by potable (consumable) water contain less than 0.25% lead by weight as required
by the Safe Drinking Water Act, Section 1417.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
272 Duchaine Blvd.
Outdoor Water Heaters
New Bedford, MA 02745
Crossover
www.htproducts.com
lp-673 Rev. 000 Rel. 001 Date 8.30.18
