HTP SB Series Installation Start-Up Maintenance Parts

Superstor solar supplement sb series; se series;
Table of Contents

Advertisement

Installation
Start-Up
Maintenance
Parts
Warranty
For Residential and
Commercial Use
SB Series and SE Series
Models*
*SB Denotes Back-Up Heat Exchanger
SE Denotes Back-Up Electric Element
A Suffix of "DW" Denotes Double
Walled Heat Exchanger Models
The solar energy system described in this manual, when properly installed and maintained, meets the minimum
standards established by the SRCC. This certification does not imply endorsement or warranty of this product
by the SRCC.
This manual must only be used by a qualified installer /
service technician. Read all instructions in this manual
before installing. Perform steps in the given order.
Failure to do so could result in substantial property
damage, severe personal injury, or death.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
272 Duchaine Blvd.
Solar Supplement
HTP reserves the right to make product changes or
updates without notice and will not be held liable for
typographical errors in literature.
The surfaces of these products contacted by potable
(consumable) water contain less than 0.25% lead by weight
as required by the Safe Drinking Water Act, Section 1417.
New Bedford, MA 02745
SuperStor
www.htproducts.com
lp-199 Rev. 4.30.15
